Description: . wel BMS BATTERY SENSOR. Smart IoT Integration Compact Patentable Outstanding features Customizable.

. wel BMS BATTERY SENSOR. Smart IoT Integration Compact Patentable Outstanding features Customizable.

Scene 1

Smart IoT  Integration Compact  Patentable Outstanding features Customizable

Automobile Marine  UPS BESS Cells assembly Battery tester

. What is a welBMS battery sensor ?. welBMS Battery Sensor is a smart device of a battery (single/pack/system) responsible for advanced monitoring, management and optimization. welBMS Battery Sensor plays a role as the CPU of the battery which monitors the voltage, internal resistance, current and temperature and optimize the battery so that it can work efficiently, durably and safely..

Scene 2

welBMS Battery Sensor is a smart device of a battery (single/pack/system) responsible for advanced monitoring, management and optimization. welBMS Battery Sensor  plays a role as  the CPU of the battery  which  monitors the voltage, internal resistance, current and temperature and optimize the battery so that it can work efficiently, durably and safely.

A picture containing text, jack, electronics

Description automatically generated

. How has the battery sensor been developed?. Welgun’s team has developed the battery sensor for a battery management system (BMS) in order to meet the requirements from Electricity of Vietnam Company (EVN) since 2019 for battery management systems at their high voltage switchgears..

Scene 3

How has the battery sensor been developed?

Welgun’s  team has developed the battery sensor for a battery management system (BMS) in order to meet the requirements from Electricity of Vietnam Company (EVN) since 2019 for battery management systems at their high voltage switchgears.

At the present, we have fully finished the R&D process and prototyped with hard wares as well as the soft-wares (IoT platform).  In which, there are advanced and patentable features: 		 Single cell voltage balance                                     By-pass function (filing for the patent) 		 Internal resistance meter (filed and pending for patent) 		 Anti-sulfation  		 Wireless assembly & connection (by IoT)

. 1. Advanced voltage balance by single cell. What are the outstanding features of welBMS sensor?.

Scene 4

1. Advanced voltage balance by single cell

What are the outstanding features of welBMS sensor?

Through ourself advanced balance, welBMS battery sensor actively regulates the float charging current of each battery ensuring that all batteries charge at the optimal voltage. Continuously monitoring and balancing the individual charging/float voltage of each battery enables the full capacity of the entire battery system to be available at all times.  welBMS battery sensor actively manages batteries to increase reliability and extend life, whereas other battery monitoring systems simply monitor batteries as they deteriorate.

2. By-pass to protect the batteries from mass death

Our patentable bypass function to help stationary battery systems not to be shut down unintentionally by bypassing any dead cell in the battery system. It’s very important to protect the battery system.

. www.welgun.com. 3. Precise internal resistance meter.

Scene 5

Internal resistance is the key parameter to present the battery health. Our patentable function can measure exactly the internal resistance at m Ω  range. Especially, It can apply online when the batteries in operation that less competitors’ solutions can do.

4. Anti-sulfation to increase battery life

Sulfation occurs when a battery is deprived of a full charge, it builds up and remains on battery plates. When too much sulfation occurs, it can impede the chemical to electrical conversion and greatly impact battery performance. welBMS battery sensor can generate electrical impulses against the sulfation then reverse it. This function could not be found from other competitor’s products.

5. Wireless assembly & connection (by IoT)

welBMS battery sensor is an compact IoT-based device. As it is wireless-connected. The battery temperature sensor is also integrated and it does not need a separate power supply wire, instead  it is from that battery.  It could not be found from other competitor’s products.

. www.welgun.com. What are the applications?. Diagram Description automatically generated.

Scene 6

Diagram

Description automatically generated

. 2019-2020 Frist prototypes (hard wares & soft wares) & in-house testing 2021 In-house testing for applications: Battery backup system & Car battery (*) 2022 Finished products for testing at customer’s sites (**).

Scene 7

2019-2020 Frist prototypes (hard wares & soft wares) & in-house testing  2021 In-house testing for applications: Battery backup system & Car battery (*) 2022 Finished products for testing at customer’s sites (**)

(*)  1.  EVN-SPC : to install BMS for 86 back-up batteries at Tan An 110KV switchgear in July 2022 2. Viettel:  to install BMS for 24 back-up batteries at HCMC office station in August 2022 3.  Mobifone : just had a first contact & discussion for testing installation    4. Filed for “by-pass function in stationery battery system” -> pending for the acceptance letter

(*)  Filed for patent of “Internal resistance meter function using induction resonance  technique” -> granted for the acceptance letter, pending for the patent

Logo, company name

Description automatically generated

. www.welgun.com. VIETNAM MARKET & OPPORTUNITIES.

Scene 8

ELECTRICITY (high voltage switchgears 110-500KV):  ~  2,000 stations * 02 battery back-up systems (around 70 batteries/ each)  TELECOM 250,000 stations x   02 battery back-up systems ( arond  24 batteries/ each)  AUTOMOTIVE Cars & truck (petrol, diesel engines): ~ 4 million units  MARINE  ~400,000 units ( with battery)  ELECTRIC VEHICLES (EV): highly growing  BATTERY ENERGY STORAGE SYSTEM (BESS): very big future demand

. www.welgun.com. About us. Quoc Le Bao (Mr.) - CEO 20 years experience in procurement, trading & business management App & web programming Gia Tai Hua (Mr.) – Technology University graduation in IT & Electronics Huy Xuan Le (Mr.) – Production University graduation in mechanics University graduation in International trade 10 years experience in telecom as an engineer for Saigon Postel 10 years experience in IoT products development 10 years experience in production 10 years experience in 3D designing, product modelling.

Scene 9

Quoc Le Bao (Mr.) - CEO 20 years experience in procurement, trading & business management App & web programming  Gia Tai Hua  (Mr.) – Technology  University graduation in IT & Electronics Huy  Xuan Le  (Mr.) – Production  University graduation in mechanics  University graduation in International trade  10 years experience in telecom as an engineer for Saigon  Postel   10 years experience in IoT products development 10 years experience in production  10 years experience in 3D designing, product modelling

WELGUN  TECHNOLOGY CORPORATION                                                              Established: Nov 2021                             Co-founders: 03
