Description: BUILDING SERVICES & ENGINEERING I BGN 223 TITLE: PROPOSAL OF BUILDING SERVICES SYSTEM.

Scene 1

BUILDING SERVICES & ENGINEERING I BGN 223 TITLE:  PROPOSAL OF BUILDING SERVICES SYSTEM

A picture containing drawing

Description automatically generated

Scene 2

Building services are the systems installed in buildings to make them comfortable, functional, efficient and safe.

To make people comfortable in the building.

To create a safe & comfortable indoor environment.

To create and improve the facilities and the utility of the building.

Scene 3

Graphical user interface, website

Description automatically generated

Scene 4

Scene 5

SERVICE PIPE
DISTRIBUTION PIPE/ SUPPLY PIPE
RISER
FIXTURE BRANCH
FIXTURE SUPPLY
ap
Rising Main

The water being distributed into the elevated tank using pump and valves.

The water from the main pipes stored in this tank and the tank water level controlled by ball valve.

The water being distribute using the distribution pipe and channel it according to the zone and level of the hospital.

Scene 6

WHY CHOOSE DOWN-FEED DISTRIBUTION SYSTEM ?

MULTI-STORY BUILDING DIVIDED IN MANY ZONES HOSPITAL USE HIGH WATER PRESSURE CONTINUOUS WATER SUPPLY HOSPITAL OPERATING 24 HOURS REDUCE BACKSIPHONAGE

Scene 7

Diagram

Description automatically generated

Scene 8

The cold water from the elevated tank being delivered to the boiler through distribution pipe. The hot water produce and process in the boiler.  The hot water going to calorifier which is a storage water cylinder by pump. The hot water being stored in the calorifier. The hot water ready to be pump through the distribution pipe. The hot water been distributed to the sanitary appliances (bath, sinks, basins)

Scene 9

MORE EFFICIENT ( REDUCE HEAT LOSS) LESS MAINTENANCE  SUPPLY HOT WATER QUICKLY SUPPLY HIGH AMOUNT OF HOT WATER INSTALLATION PROCESS IS EASY
