[Virtual Presenter] Welcome to the ultra ray 3000 Training. This presentation will focus on the use and functionality of the ultra ray 3000 instrument. The purpose is to provide a comprehensive understanding of the ultra ray 3000 and its capabilities. Our first objective is to understand what a PID is and how it works. Next, we will cover the basic features of the ultra ray 3000. Then, we will explore specific techniques for using the instrument to sample for different compounds. Finally, we will learn how to perform calibrations and change settings. Let's begin and expand our knowledge of the ultra ray 3000..

[Audio] photoionization detectors (PIDs) and their functionality.

[Audio] The third slide of the UltraRAE 3000 training presentation focuses on the use of Photoionization Detectors, or PIDs. These detectors are crucial for the instrument, allowing for real-time measurement of organic and inorganic vapor concentrations in low levels, ranging from parts-per-billion to 10000 parts-per-million. The PID works by using an ultraviolet (UV) lamp to ionize molecules, causing them to release an electron and form a positive ion. This occurs when the Ionization Potential (IP) of the molecule is less than the output of the UV lamp, which can range from 9.8 electron volts (eV) to 11.8 eV. The resulting ions are then guided and collected, with the ion current amplified and converted into a digital meter readout, giving us the concentration of the compound in parts-per-million. The most commonly used UV lamps for field work are the 9.8 eV, 10.6 eV, 11.7 eV, and 11.8 eV lamps. It's important to note that these lamps can have varying lifespans, with the 10.6 eV lamp lasting around 3000 hours, the 11.7 eV lamp lasting around 200 hours, and the 11.8 eV lamp lasting around 500 hours. However, the actual lifespan will depend on proper use and maintenance. To conclude, PIDs are essential for accurate measurements with the UltraRAE 3000, utilizing UV lamps to create ions and provide precise readings in parts-per-million. Knowing the features and limitations of PIDs is important for their effective use in the field. This concludes the overview of PIDs, and the next slide will cover the various applications of the UltraRAE 3000..

[Audio] Slide number 4 discusses the largest group of compounds that can be measured by a PID, or photoionization detector, which are known as organics. These compounds contain carbon atoms and include aromatic compounds like benzene, toluene, ethyl benzene, and xylene. Other types of compounds in this category include ketones and aldehydes, which have a C=O bond, such as acetone, methyl ethyl ketone, and acetaldehyde. Amines and amides, which are carbon compounds containing nitrogen, such as diethylamine, are also included. Additionally, chlorinated hydrocarbons like trichloroethylene and perchloroethylene, sulfur compounds like mercaptans and sulfides, unsaturated hydrocarbons like butadiene and isobutylene, alcohols like isopropanol and ethanol, and saturated hydrocarbons like butane and octane can also be measured using a PID. PIDs can also be used to measure some inorganics, which do not contain carbon. These include compounds like ammonia, certain semiconductor gases like arsine and phosphine, as well as hydrogen sulfide, nitric oxide, and bromine and iodine. With this understanding of the range of compounds that can be measured by a PID, we will continue our training on the UltraRAE 3000 instrument..

[Audio] Slide number five discusses the importance of understanding PID Correction Factors. The Correction Factor, also known as CF, measures the sensitivity of a PID to a specific gas and is only relevant when using an instrument calibrated for one compound while sampling for another. To determine the sensitivity, the relationship between the calibration gas and the alternative compound is considered, giving the Correction Factor. An Isobutylene-calibrated instrument will show a higher reading when sampling for toluene due to the difference in the PID's response to toluene compared to Isobutylene, as shown in the response/correction factor. For example, toluene has a correction factor of 0.5, meaning that if the instrument reads 100 ppm, the correct value for toluene would be 100 ppm multiplied by 0.5, which is 50 ppm. Most manufacturers have published lists of response/correction factors for various compounds, which are now commonly integrated into PIDs for easy correction of readings. Here are a few examples of correction factors for common compounds: Acetone - 0.7, Ammonia - 8.5, Benzene - 0.5, Butadiene - 0.85, Diesel Fuel - 0.75, Ethanol - 8.7, Gasoline - 1.1, n-Hexane - 3.3, Styrene - 0.45, Toluene - 0.51, Vinyl Chloride - 2.2, and Xylene - 0.43. Understanding PID Correction Factors is crucial for accurately interpreting instrument readings, and we will delve into this in further detail in the following slides..

[Audio] We will be discussing the example correction factors for the UltraRAE 3000 instrument. The list includes various compounds and their corresponding correction factors, which are used to adjust the readings on the screen to accurately reflect the actual concentration of the compound in the air. For example, Acetone has a correction factor of 0.7, meaning that if the instrument detects a concentration of 1 ppm, the reading on the screen will be adjusted to 0.7 ppm. Some correction factors may be greater than 1, resulting in a lower reading on the screen compared to the actual concentration of the compound in the air. It is important to consider these factors when interpreting the results from the UltraRAE 3000 instrument. Understanding the correction factors for each compound is essential. In summary, we have discussed the example correction factors for the UltraRAE 3000 instrument and their role in accurately reflecting the concentration of compounds in the air. It is important to be aware of correction factors greater than 1 when interpreting results. Let's continue to the next slide to learn more about the features and limitations of the UltraRAE 3000 instrument..

[Audio] The UltraRAE 3000 is a versatile and powerful instrument designed to sample a wide range of compounds. It has advanced sensor technology and an intuitive interface for accurate and reliable results. We will discuss the basic features and usage of this instrument in this training. It is important to understand the limitations of the UltraRAE 3000 and refer to the user manual when using it. The instrument can detect and measure various compounds, making it useful for many industries. Its easy-to-use controls and ability to store and download data make sampling efficient. Our training will teach you how to effectively use the UltraRAE 3000. We will now move on to a more in-depth look at its features and usage..

[Audio] We will discuss the UltraRAE 3000 instrument and its effective use for sampling different compounds. This hand-held, programmable monitor is designed for instantaneous exposure monitoring of specific organic gases, using a gas separation tube and photoionization detector with a 9.8 eV gas discharge lamp. Additionally, the UltraRAE 3000 can function as a broadband monitor by utilizing a PID and 9.8 eV, 10.6 eV, or 11.7 eV lamps to measure total volatile organic compound levels. This makes it a versatile and essential tool for professionals working with organic gases. Understanding its features and limitations will aid in accurate sampling. Let's proceed to the next slide to learn more about this powerful instrument..

[Audio] Slide number 9 covers the user interface of the UltraRAE 3000 instrument. It includes the display, LEDs, alarm transducer, and four keys. These keys not only have designated functions but also act as "soft keys" within the instrument's menus. Each key controls different parameters or selections depending on the menu. It is important to familiarize yourself with the functions and capabilities of each key to use the UltraRAE 3000 effectively. Let's move on to the next slide to explore the instrument's features for sampling different compounds..

[Audio] This section of our UltraRAE 3000 training video discusses the three panes located at the bottom of the instrument's display. These panes are essential for navigating through menus and understanding the key functions of the UltraRAE 3000. As seen on the display, the panes are mapped to specific keys on the instrument - the left pane to the [Y/+] key, the center pane to the [MODE] key, and the right pane to the [N/-] key. This consistency in mapping makes it easy to remember and use the keys in various menus. The following examples show how the panes are connected to the keys in different menus. By understanding this relationship, you can efficiently navigate and control the UltraRAE 3000. This is crucial for effectively using the instrument and its features, which you will learn about in this training. Keep watching for more information on sampling for various compounds with the UltraRAE 3000..

[Audio] This session will focus on proper use of the UltraRAE 3000 instrument for sampling various compounds. Slide 11 will cover the instrument's features and limitations. The gas info table displays the correction factor and required calibration gas for accurate readings. The reading column indicates gas concentration. The calibration/bump section has dark and light icons, indicating when a calibration or bump test is needed. The radio power and signal columns show connection status. The battery column has 3 bars for easy monitoring and the pump column indicates pump functioning. The datalog column shows if it is on or off and the Y/+ and N/- keys serve specific functions on this screen. Understanding slide 11 is crucial for proper use and accurate results. Let's move on to the next slide for further training..

[Audio] In this module, we will cover how to turn on and off the UltraRAE 3000 instrument. Understanding the correct method is crucial for accurate readings and proper functioning. To turn the instrument on, hold down the "Mode" button on the top of the instrument until the screen lights up. Release the button to begin the self test, which ensures all components are functioning properly. It is important to wait for the self test to complete before using the instrument. When turning it off, hold down the "Mode" button until the screen turns off. Properly turning off the instrument after each use is important for battery conservation and readiness for the next use. Remember, this process is essential for the accuracy and performance of the UltraRAE 3000. Next, we will cover how to sample for various compounds and understand the features and limitations of the instrument..

[Audio] In this segment, we will be discussing the pump status of the UltraRAE 3000 and its importance during operation. It is crucial to ensure that the probe inlet and gas outlet are free of any obstructions as this can lead to false readings or stalling of the pump. The pump icon on the screen will alternate between inflow and outflow during normal operation, but during duty cycling or PID lamp cleaning, the display will show alternating icons. If there is a pump failure or obstruction, the alarm will sound and a blinking icon will appear on the display. Consult the Troubleshooting section of the User Manual for further instructions. To test for leaks, place your finger over the end of the inlet probe while the UltraRAE 3000 is turned on. The alarm and pump-stall icon should sound, indicating that the seals are in good condition. Press [Y/+] to stop the alarm. If the pump does not respond or show the stalled-pump icon, check that all inlet parts are securely tightened and inspect the O-ring for damage. Replace the O-ring if needed. Stay tuned for the next slide to learn another important aspect of using the instrument..

[Audio] Today, we will be discussing how to enter Programming Mode on the UltraRAE 3000 instrument. The UltraRAE 3000 is a highly versatile instrument that is used to sample for various compounds. It has a Programming Mode that allows you to customize and adjust its settings. To enter Programming Mode, make sure the monitor is turned on and hold down the [MODE] and [N/-] buttons together for 3 seconds. This will take you to the password screen. Please note that the [MODE] and [N/-] buttons are located on the top of the instrument and pressing them simultaneously will activate Programming Mode. In this mode, you can access different menus and submenus to change settings such as alarm thresholds, calibration gas options, and other features. It is important to remember that Programming Mode should only be accessed by trained and authorized personnel to avoid altering the instrument's accuracy and reliability. Thank you and we will continue with more training on other features and capabilities in the next slide..

[Audio] During training on the UltraRAE 3000 instrument, the focus will now be on Programming Mode. When successfully entering this mode, the Calibration label and its corresponding icon will be highlighted on the screen. The [N/-] button can be used to navigate through the programming menus, with the name of each menu and its corresponding icon displayed at the top of the screen. Each press of the button will move the selection from left to right, displaying different programming menus on the screen..

[Audio] On slide 16, the UltraRAE 3000 instrument offers a variety of menus. These menus provide access to important functions for sampling and understanding the instrument's features and limitations. The Calibration menu allows for zero and span calibrations to ensure accurate readings. The Bump menu is used for a quick bump test to check the instrument's functionality. The Measurement menu shows real-time measurements of various compounds. The Meas. Gas menu lets you choose the sampled gas, while the Meas. Unit menu allows you to select the unit of measurement for readings. Tube Selection menu is for choosing the type of tube used for sampling. Alarm Setting menu allows you to set alarms for high, low, STEL, and TWA levels. The Alarm Mode menu determines how alarms are indicated. The Measurement Clear menu clears current data. The Data Log Interval menu sets how often the instrument records and stores data. The Data Selection menu lets you choose what type of data is logged. The Datalog Type menu allows for continuous or event-based data logging. The Monitor Setup menu configures settings such as radio power and user information. The Date Time menu sets the current date and time. The Pump Duty Cycle menu adjusts the pump's duty cycle for battery conservation. The Pump Speed menu adjusts the pump's speed. The Temperature Unit menu selects the unit for temperature readings. The Language menu changes the display language. The Real Time Protocol menu selects the communication protocol with a PC. Lastly, the Power On menu..

[Audio] In this section, we will be focusing on the compound-specific operation of the UltraRAE 3000 instrument. To ensure accurate and reliable results, it is important to have the UltraRAE 3000 in Tube Mode and to select the appropriate tube type before performing a compound-specific measurement for Benzene or Butadiene. The UltraRAE 3000 will only function as a compound-specific measurement device when equipped with a 9.8eV lamp. To select the appropriate tube type, enter Programming Mode and then choose Measurement and Tube Selection. You can choose between Benzene or Butadiene and remember to save your selection. This step is crucial in preparing the UltraRAE 3000 for compound-specific measurements. Proper use and understanding of the UltraRAE 3000 instrument is essential in accurately sampling for various compounds. Thank you for your attention and we will continue with our UltraRAE 3000 Training in the following slides..

[Audio] To take measurements with the UltraRAE 3000, turn on the instrument and a screen will appear displaying the correction factor and gas type for calibration reference. Press the [N/-] button to proceed to the next screen, but do not begin sampling yet. Prior to sampling, it is necessary to insert a RAE-Sep separation tube into the inlet or holder for accurate readings. Once inserted, press the [Y/+] button to begin the 60-second measurement. It is crucial to note that sampling should not begin until the RAE-Sep tube is correctly inserted, to ensure precise and reliable results. Understanding and properly using the UltraRAE 3000's features and limitations is essential for successful measurements. Keep an eye out for the next part of the training..

[Audio] In this section of our UltraRAE 3000 training, we will demonstrate the proper method for opening the separation tubes to sample different compounds with this instrument. It is crucial to be familiar with the features and limitations of the UltraRAE 3000 in order to use it efficiently. To begin, open the package of RAE-Sep separation tubes and select one. Place the tip in the package's tube tip breaker, which is located on the front, making sure it is perpendicular to the container. Carefully push the tube downward until the tip breaks off. Then, remove the tube from the hole. Next, turn the tube around and repeat the same process for the other side. It is important to handle the tubes with care, as the broken ends can be sharp. Lastly, place the unbroken tip in the tube tip breaker, ensuring it is still perpendicular to the container. Gently push the tube downward until the tip breaks off, and then remove the tube from the hole. Remember to always handle the tubes carefully and follow these steps precisely when opening them. This will ensure the safe and effective use of the UltraRAE 3000 instrument. Stay tuned for more training on how to use this device..

[Audio] We will now discuss the process of inserting separation tubes into the UltraRAE 3000 instrument on slide number twenty. This is an important step in sampling for various compounds with the UltraRAE 3000. To begin, the front of the sampling probe must be unscrewed from the base. Then, the tube can be slipped into the rubber holder at the front of the probe, making sure the arrow on the tube is pointing towards the instrument. This is necessary for proper functionality and accurate results. Next, the other end of the tube must be inserted into the middle of the base and the front portion must be turned to tighten it onto the base's threads. It is essential not to overtighten any part of the sampling assembly to avoid damage and ensure accurate readings. This concludes our discussion on inserting separation tubes into the UltraRAE 3000 instrument. Please follow these steps carefully for the best results. Thank you and stay tuned for more information on using the UltraRAE 3000..

[Audio] In slide number 21, we will focus on the calibration and bump testing of the UltraRAE 3000 instrument. This step is crucial for accurate and reliable results. The instrument is designed to sample for various compounds, and it is important to understand its features and limitations for proper use. During calibration, we set the instrument to a known reference point to accurately detect target compounds. This is achieved through zero and span calibrations. The zero calibration establishes the baseline, while the span calibration adjusts sensitivity for specific compounds. Regular bump testing is also necessary to verify proper functioning and identify any potential issues. Bump testing involves exposing the instrument to a known concentration of a target compound and ensuring appropriate response. It is highly recommended to perform both calibration and bump testing on a regular schedule to maintain accuracy and reliability. It is important to follow the manufacturer's guidelines and document all calibrations and bump tests for the safety and effectiveness of your measurements. Let's continue our training on the UltraRAE 3000 instrument in the next slide..

[Audio] To calibrate the UltraRAE 3000 instrument, navigate to the Programming menus and select "Calibration" before pressing the [Y/+] button to choose the desired type (Zero Calib, Span Calib, or Bump). Use the [N/-] button to view additional options and select the appropriate type. Press the [MODE] button to exit and return to the main display for continued measurement. To change the calibration type, use the [N/-] button to toggle to the desired option. Remember, proper calibration is crucial for accurate and reliable sampling results. Our UltraRAE 3000 Training will continue on the following slides..

[Audio] Slide number 23 of our UltraRAE 3000 Training covers the Zero (Fresh Air) Calibration process for the instrument. If the button [Y/+] has been pressed to enter Zero calibration, a message will appear on the screen to turn on the Zero calibration gas. Press [Y/+] again to start the calibration process. The instrument will display a 30-second countdown and the message "Zeroing..." indicating it is taking a reading of fresh air and adjusting the measurements. Once the calibration is complete, a message will appear stating "Zeroing is done!" with a reading of 0.0 ppm, indicating the instrument is calibrated for fresh air. The Calibration menu will then appear on the screen with Span Calib highlighted, indicating the instrument is ready for Span calibration. Please continue to the next slide for more information on this process..

[Audio] This slide covers Span Calibration for the UltraRAE 3000 instrument. It is a crucial process in obtaining precise readings. To begin, if you have entered span calibration by pressing Y or + on the instrument, a prompt will appear asking you to turn on your span calibration gas. Once the gas is on, press Y or + again to initiate the calibration process. The instrument will then display "Calibrating..." to indicate that it is in progress. Once completed, a message will appear stating "Span 1 is done!" along with the corresponding calibration reading specific to the span gas used. It is recommended to use benzene calibration gas for benzene measurements. After calibration, the instrument will display the Calibration menu with Zero Calib highlighted, allowing for any potential offsets in the readings to be zeroed out. This ensures accurate and reliable readings from the UltraRAE 3000. Stay tuned for the final section of our training video, slide 25..

[Audio] On slide number 25, it is important to perform a bump test before using the UltraRAE 3000 instrument. Bump testing is crucial for ensuring the instrument's proper functioning and accuracy of readings. It is highly recommended to conduct a bump test before every use. The purpose of a bump test is to confirm the response of the sensors to gas and to check if all alarms are working. If the test fails, a full calibration is necessary. To conduct a bump test, follow these steps: From the Calibration menu, select "Bump," then install the calibration adapter and connect it to a source of calibration gas. Verify that the displayed value meets the gas cylinder's specified concentration and start the flow of calibration gas. Initiate the bump test by pressing [Y/+] and it can be aborted at any time by pressing [N/-]. If not aborted, the display will show a reading and indicate whether the test has passed or failed. If it fails, the instrument will automatically move to the Calibration screen. Performing a bump test is a simple and efficient method to ensure the accuracy and reliability of the UltraRAE 3000 instrument. It is essential for maintaining the safety and efficiency of the workplace. Let's continue to the next slide for more information on using the UltraRAE 3000 instrument..

[Audio] This training segment will cover important information about the capabilities and limitations of the UltraRAE 3000 instrument. It is crucial for users to have a thorough understanding of the features and restrictions in order to ensure accurate and reliable results. The UltraRAE 3000 can sample for volatile organic compounds (VOCs), toxic gases like hydrogen sulfide and carbon monoxide, as well as detect radiation levels and measure dust particles in the air. However, the instrument is not suitable for detecting all types of chemical and gas compounds and is primarily designed for use in industrial and hazardous environments. Regular calibration and maintenance, following the manufacturer's instructions, is recommended to ensure accurate and reliable results. The environment in which the UltraRAE 3000 is used can also affect its performance, so factors such as temperature, humidity, and potential interference from other air contaminants should be taken into consideration. In summary, the UltraRAE 3000 is a powerful and versatile instrument with limitations that must be acknowledged. Regular maintenance and careful consideration of the environment are necessary for obtaining accurate results..

[Audio] This section of the UltraRAE 3000 Training covers the gas detection ranges and lamp range and resolution of the instrument. The UltraRAE 3000 has three ranges for VOCs, with respective resolutions of 0.025 ppm, 0.1 ppm, and 1 ppm and a response time of less than 3 seconds. Benzene and butadiene have a gas detection range of 0 to 200 ppm with a resolution of 0.025 ppm and a response time of less than 60 seconds. The instrument has three lamp options: 10.6 eV, 9.8 eV, and 11.7 eV. The 10.6 eV lamp has a range of 50 ppb to 10000 ppm with a resolution of 25 ppb, the 9.8 eV lamp has a range of 50 ppb to 200 ppm for benzene and butadiene and 50 ppb to 5000 ppm in VOC mode with a resolution of 25 ppb, and the 11.7 eV lamp has a range of 50 ppb to 2000 ppm in VOC mode with a resolution of 25 ppb. By understanding these ranges and resolutions, you will be able to effectively use the instrument for sampling various compounds. This concludes our discussion on this topic. In the next section, we will cover another aspect of the UltraRAE 3000..

[Audio] Slide 28 of our UltraRAE 3000 training discusses the limitations of the instrument. Despite its humidity sensor and compensation circuitry, the UltraRAE 3000 can still be affected by high levels of humidity and atmospheric moisture, which can compromise its accuracy. The operating temperature range is between -4 °F to 120 °F, and inserting the instrument into a vessel with internal temperature above 120 °F can cause damage. To ensure reliable results, it is important to carefully monitor and follow these limitations. Please proceed to slide 29 for more information on the UltraRAE 3000..

[Audio] This is the user manual for the UltraRAE 3000. It contains detailed information on troubleshooting and special and advanced uses for the instrument. It is important to refer to this manual for a better understanding of the UltraRAE 3000. The comprehensive guide provides instructions for sampling various compounds and explains the instrument's features and limitations. It is a valuable resource for addressing any performance issues. The key benefit of the manual is its troubleshooting instructions, which can save time and effort in resolving technical issues. It also covers special uses, important for achieving accurate and reliable results. Advanced users can benefit from the manual's detailed information on utilizing the full capabilities of the UltraRAE 3000, including advanced settings and features for more precise sampling. Overall, the user manual is essential for anyone using the UltraRAE 3000 and should be referenced to maximize the instrument's potential..

[Audio] The UltraRAE 3000 Training has come to a close. We trust that this presentation has been beneficial in guiding you through the operation of the UltraRAE 3000 instrument. Throughout the training, we covered the various compounds that the instrument can detect, as well as its features and limitations. Now that you are acquainted with the UltraRAE 3000, you have the necessary understanding and abilities to use it efficiently. Thank you for watching this training and we hope it has given you valuable knowledge..
