Scene 1 (0s)
TYPES OF VENTS. Jessica D. Reyes.
Scene 2 (14s)
BRANCH VENT. is a vent pipe that connects one or more individual vents to either a vent stack or stack vent..
Scene 3 (55s)
CIRCUIT VENT. connects between the two most upstream fixtures. As few as 2 fixtures or a maximum of 8 fixtures may be served by the circuit vent..
Scene 4 (2m 29s)
COMBINATION WASTE AND VENT SYSTEM. A specially designed system of waste piping embodying the horizontal wet venting of one or more sinks or floor drains by means of a common waste and vent pipe adequately sized to provide free movement of air above the flow line of the drain..
Scene 5 (3m 51s)
COMMON VENT. is an individual vent that connects at the intersection of two trap arms..
Scene 6 (4m 49s)
INDIVIDUAL VENT. is a single pipe that vents a plumbing fixtures trap..
Scene 7 (5m 40s)
STACK VENT. The extension of a soil or waste stack above the highest horizontal drain connected to the stack..
Scene 8 (7m 2s)
VENT STACK. A vertical vent pipe installed primarily for the purpose of providing circulation of air to and from any part of the drainage system..
Scene 9 (8m 18s)
THANK YOU AND GODBLESS!.
