Scene 1 (0s)
GSPublisherVersion 0.0.100.100 Drawing Scale VARIES Drawn by Date Checked by Date Drawing Status 01/09/2022 Kara.Ceesay Final Drawings Company Name PROPOSED STOREY BUILDING TO BE ERRECTED AT SUKUTA NEMA FOR SUKAI BANGURA CHAM Mr.B. Sowe 01/09/2022.
Scene 2 (12s)
GSPublisherVersion 0.0.100.100 Drawing Status Pre-Liminary Drawing Name SITE PLAN Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 15/05/2022 15/05/2022 Drawing Scale 1:1 Layout ID A.03.5 Client Name Mr. L. Mass Location Farato 13.325 11.007 13.606 1.215 1.150 1.215 1.150 3.865 5180 8.650 Access Road Access Road Access Road Access Road ccess Road Proposed Building Existing Building Walk-way Walk-way SITE PLAN.
Scene 3 (31s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name GROUND FLOOR LAYOUT Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.1 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 DOWN UP 21R x 0.155 20G x 0.325 Living room Kitchen Dinning Bedroom Toilet Exit Porch Entrance Store GROUND FLOOR.
Scene 4 (47s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name GROUND FLOOR DIM Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.2 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 DOWN UP 21R x 0.155 20G x 0.325 4.500 4.000 8.500 0.925 4.318 3.607 8.850 4.500 4.000 8.500 3.925 1.500 2.150 1.275 8.850 0.150 4.250 0.150 3.950 0.150 0.150 4.350 0.150 3.850 0.150 5.550 0.150 2.650 0.150 4.350 0.150 3.850 0.150 4.168 3.457 0.150 3.775 0.150 1.350 0.150 2.000 0.150 1.275 1.350 Living room Kitchen Dinning Bedroom Toilet Exit Porch Entrance Store GROUND FLOOR.
Scene 5 (1m 20s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name G.FLOOR DOORS & WINDOWS SCHED Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.6 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 DOWN UP 21R x 0.155 20G x 0.325 WD - 002 WHD 2.000x1.500 WD - 002 WHD 0.600x0.600 WD - 002 WHD 0.600x0.600 WD - 011 WHD 0.400x4.150 WD - 002 WHD 2.500x1.500 DOO - 006 WHD 2.300x2.100 DOO - 001 WHD 1.000x2.100 DOO - 002 WHD 0.900x2.100 DOO - 003 WHD 0.800x2.100 DOO - 003 WHD 0.800x2.100 WD - 002 WHD 2.500x1.500 WD - 010 WHD 0.500x2.100 WD - 009 WHD 0.500x2.100 DOO - 003 WHD 0.800x2.100 S-10 S-10 Living room Kitchen Dinning Bedroom Toilet Exit Porch Entrance Store GROUND FLOOR.
Scene 6 (1m 54s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name G.FLOOR DOORS & WINDOWS SCHED Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.04.6 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 DOWN UP 21R x 0.155 20G x 0.325 WD - 002 WHD 2.000x1.500 WD - 002 WHD 0.600x0.600 WD - 002 WHD 0.600x0.600 WD - 011 WHD 0.400x4.150 WD - 002 WHD 2.500x1.500 DOO - 006 WHD 2.300x2.100 DOO - 001 WHD 1.000x2.100 DOO - 002 WHD 0.900x2.100 DOO - 003 WHD 0.800x2.100 DOO - 003 WHD 0.800x2.100 WD - 002 WHD 2.500x1.500 WD - 010 WHD 0.500x2.100 WD - 009 WHD 0.500x2.100 DOO - 003 WHD 0.800x2.100 S-10 S-10 Living room Kitchen Dinning Bedroom Toilet Exit Porch Entrance Store GROUND FLOOR.
Scene 7 (2m 28s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name FIRST FLOOR LAYOUT Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.4 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 DOWN UP 21R x 0.155 20G x 0.325 S-29 S-29 Master Bedroom Bedroom Toilet Toilet Closet Balcony Balcony Lobby FIRST FLOOR.
Scene 8 (2m 44s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name FIRST FLOOR DIM Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.3 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 DOWN UP 21R x 0.155 20G x 0.325 0.150 3.070 0.150 0.150 3.070 0.150 2.330 0.150 2.650 0.150 0.150 4.350 0.150 3.850 0.150 0.150 4.350 0.150 3.850 0.150 0.150 1.125 0.150 3.565 0.150 1.711 0.150 2.199 0.150 0.150 1.125 0.150 2.850 0.150 3.500 0.150 1.125 0.150 0.150 3.775 0.150 1.350 0.150 0.150 3.775 0.150 1.350 0.150 0.150 5.130 0.150 0.150 2.150 0.918 0.898 S-28 S-28 Master Bedroom Bedroom Toilet Toilet Closet Balcony Balcony Lobby FIRST FLOOR.
Scene 9 (3m 22s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name F.FLOOR DOORS & WINDOWS SCHED Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.7 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 DOWN UP 21R x 0.155 20G x 0.325 WD - 002 WHD 2.500x1.500 DOO - 001 WHD 1.000x2.100 DOO - 006 WHD 2.300x2.100 WD - 001 WHD 2.500x1.500 WD - 004 WHD 0.600x0.600 DOO - 002 WHD 0.900x2.100 DOO - 003 WHD 0.800x2.100 WD - 011 WHD 0.350x2.100 WD - 012 WHD 0.350x2.100 DOO - 003 WHD 0.800x2.100 DOO - 004 WHD 2.200x2.100 DOO - 002 WHD 0.800x2.100 WD - 005 WHD 0.600x0.600 DOO - 005 WHD 0.900x2.100 WD - 003 WHD 0.600x0.600 WD - 002 WHD 2.000x1.500 S-09 S-09 Master Bedroom Bedroom Toilet Toilet Closet Balcony Balcony Lobby FIRST FLOOR.
Scene 10 (3m 58s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name F.FLOOR DOORS & WINDOWS SCHED Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.04.7 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 DOWN UP 21R x 0.155 20G x 0.325 WD - 002 WHD 2.500x1.500 DOO - 001 WHD 1.000x2.100 DOO - 006 WHD 2.300x2.100 WD - 001 WHD 2.500x1.500 WD - 004 WHD 0.600x0.600 DOO - 002 WHD 0.900x2.100 DOO - 003 WHD 0.800x2.100 WD - 011 WHD 0.350x2.100 WD - 012 WHD 0.350x2.100 DOO - 003 WHD 0.800x2.100 DOO - 004 WHD 2.200x2.100 DOO - 002 WHD 0.800x2.100 WD - 005 WHD 0.600x0.600 DOO - 005 WHD 0.900x2.100 WD - 003 WHD 0.600x0.600 WD - 002 WHD 2.000x1.500 S-09 S-09 Master Bedroom Bedroom Toilet Toilet Closet Balcony Balcony Lobby FIRST FLOOR.
Scene 11 (4m 34s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name SLAB ROOF Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.9 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 8.400 9.100 2.995 5.105 0.350 0.150 3.095 0.150 5.105 0.150 0.150 1.125 0.150 0.150 7.425 0.150 0.150 0.200 0.150 0.150 3.095 0.150 4.650 S-07 S-07 FIRST FLOOR.
Scene 12 (4m 57s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name FOUNDATION PLAN Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.11 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 1 2 4 A B C D E F G H 3 0.925 3.000 0.790 0.710 1.075 1.075 1.275 8.850 4.500 1.200 2.800 8.500 0.925 3.000 0.790 0.710 1.075 1.075 1.275 8.850 4.500 1.200 2.800 8.500 S-08 S-08 1000mmx600mm foundation trench 200mm thick foundation block work. 1000X1000x350mm REINFORCED CONCRETE FOOTING @ 350kg/m3 200mm DEPTH MASS CONCRETE STRIP FOUNDATION 200mmx150mm concrete pillar FOUNDATION PLAN.
Scene 13 (5m 26s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name GROUND BEAM LAYOUT Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.8 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 0.15 m Masonry blockwork 0.15 x 0.25 m RC. Ground Beam 0.12 m Concrete slab 0.38 m Well compacted hardcore 0.25 0.05 0.12 INTERIOR EXTERIOR DPM 0.65 0.45 0.35 0.100 1.0 STRIP FOUNDATION DETAIL S-25 1 2 4 A B C D E F G H 3 8.850 4.500 1.200 2.800 8.500 0.925 3.000 0.790 0.710 1.075 1.075 1.275 8.850 4.500 1.200 2.800 8.500 S-26 S-26 S-27 S-27 GROUND BEAM LAYOUT.
Scene 14 (5m 57s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name SECTION PLAN Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.10 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema 0.050 0.250 1.073 0.327 0.300 0.600 1.500 0.150 0.900 0.300 0.450 1.500 0.900 0.300 1.100 0.250 1.073 0.627 3.450 3.150 1.100 1.950 7.700 0.450 0.650 1.000 2.850 Gymson ceiling on galvanised wire hangers. Ground level procelain tile on 40mm thick cement/sand mix on 100mm thick R.C floor concrete @ c:20 EARTH COMPACTED HARCORE FILLING IN LAYERS MASS CONCRETE STRIP FOUNATION @250kg/m3 VIBRATED SOLID BLOCK WORK 200mm THICK REINFORCED C ONCRETE LINTEL 200mm THICK REINFORCED CONCRETE SLAB BEAM Gymson ceiling on galvanised wire hangers. Bedroom Bedroom Bedroom Living SECTION S-06 400mm thick well compacted hardcore filling compacted in layers of 200mm thick 150mm thick Reinforced concrete floor slab. reinforce with 6mm rod @ 200c/ c 1000x1000x300mm thick Reinforce concrete footing foundation.
Scene 15 (6m 39s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name FRONT VIEW ELEVATION Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.12 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema FRONT VIEW ELEVATION.
Scene 16 (6m 53s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name LEFT ELEVATION Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.15 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema LEFT VIEW ELEVATION.
Scene 17 (7m 7s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name RIGHT ELEVATION Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.14 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema RIGHT VIEW ELEVATION.
Scene 18 (7m 21s)
GSPublisherVersion 0.0.100.100 Drawing Status Final Drawing Name BACK ELEVATION Drawn by Mr. Kara Ceesay Checked by Mr. Sowe 01/09/2022 01/09/2022 Drawing Scale 1:1 Layout ID A.03.13 Client Name Mrs. Sukai Bangura Cham Location Sukuta Nema BACK VIEW ELEVATION.
Scene 20 (7m 40s)
BALUSTRADE DETAILS.
Scene 21 (7m 46s)
GSPublisherVersion 0.3.100.100 Drawing Status FINAL Drawing Name FOOTING DETAIL Drawn by Mr. Kara Ceesay Checked by Mr. Sowe Drawing Scale 1:1 Layout ID A.06 6T12-02 100 T6-03-0.15 100 0.45 0.35 0.100 0.38 0.12 8T12-01-0.15 8T12-01-0.15 0.375 0.25 0.375 120 120 0.425 0.15 0.425 FOOTING DETAIL F1 (03 Nos.) 1 T6-03-0.15 02 02 02 02 0.40 0.20 SECTION 1 6T12-03-0.15 6T12-02 1000 T6-03-0.15 100 0.45 0.35 0.100 0.38 0.12 6T12-01-0.15 6T12-01-0.15 0.425 0.15 0.425 1000 1000 0.325 0.15 0.325 FOOTING DETAIL F1 (22 Nos.) 1 T6-03-0.15 02 02 02 02 0.20 0.15 SECTION 1 4T12-03-0.15 01/09/2022 01/09/2022 Client Name Mrs, sukai B. Cham Location SUKUT Ag.
Scene 22 (8m 20s)
3nn , 150..
Scene 24 (8m 31s)
4T12 E30mm hp.
