SMART CIRCUIT BREAKER. E027 RUSHIKESH AAGLAVE E028 RUPAL RASKAR E029 LOCHANA CHAUDHARI E030 NIKUNJ SATPUTE E031 SHREYAS PATIL.

INTRODUCTION What is a circuit breaker? A circuit breaker is a device that automatically stops the flow of electricity when there is too much current or a fault in the current to protect electric appliances. What is a smart circuit breaker? A smart circuit breaker is an advanced type of circuit breaker that not only protects an electrical system from overloads, short circuits, and faults, but also integrates digital technology and communication features. It can monitor, control, and manage electrical power in real time, often through mobile apps or building management systems..

OBJECTIVE OF SMART CURCUIT BREAKER. To automatically detect and respond to electrical faults. To enable remote monitoring and control. To improve energy efficiency and safety. To integrate IoT, automation, and Power Systems..

CONSTRUCTION. Design of a microcontroller-based electronic card that can communicate with a BLE 4.0 module and be able to broadcast using Bluetooth technology. Controlling unit: Microcontroller based on a controlling card which can work under 220 volt grid voltage and 12 volt dry accumulator, suggested to use MAC filtering to prevent data breaches. Controlling module software: master and slave relationship, specified configurations are done with AT commands on Rx/Tx..

WORKING. Current and voltage sensing: The breaker continuously monitors current, voltage and power using sensors. The data is sent to the microcontroller for analysis. The microcontroller compares the measured values with preset safety limits; if any abnormal condition occurs, it instantly detects the fault..

FLOWCHART.

ADVANTAGES. Enhance safety and reliability Remote control and monitoring Protects devices Energy savings and analytics available Compatible with smart home systems Simple energy monitoring.

PARAMETERS TRADITIONAL CIRCUIT BREAKER SMART CURCUIT BREAKER Control Manually operated Remotely controlled via smartphone app or voice command Safety Features Protection against overload and short circuits Additional protections like arc fault and ground fault detection Monittoring No Real time Monittoring Real-time energy usage and fault monitoring Cost Lower upfront cost Higher cost but offers advanced features.

Google Perplexity International conference on technology, engineering & science>Home electricity automation via IoT Chat GPT Canva.
