Safety Induction

[Audio] Hi, today I am going to Talk about Kim Heng Safety Induction.

[Audio] Please be reminded to silence your mobile phone.

[Audio] Site map @ number 9 pandan Crescent. Site Map @ 09 Pandan Crescent.

[Audio] Emergency Assembly. Emergency Assembly. SECURITY" GUARD uster Point.

[Audio] We are going to go through the above content..

[Audio] Safety & Health Policy. 44 Gsuæ 9 €eye-&2S FD KO!10d.

[Audio] Alcohol & Drag Policy. Alcohol & Drug Policy.

[Audio] Safety Objective. Safety Objective. Zero Incident Zero Loss Injury No Harm to People No Damage to Property & Environment.

[Audio] Stop Work Policy. Stop Work order shall be invoked if any situation arises due to an unsafe action /behaviour /omission or non-action of any party involved in the operation. Any personnel has the right and duty to invoke the Stop Work policy if in his opinion or judgment, such activity is deemed to be a potential incident. No employee shall be faulted or disciplined for invoking the Stop Work order when, upon investigation, it (Stop Work order) was found to be unnecessary. The Stop Work order must be applied in good faith. Timing is critical. There should not be any delay in calling for a Stop Work order if a potential risk or threat is imminent or the need arises All activity that has ceased due to this policy shall not resumed until it has met all safety protocol inline with the satisfaction of all at work.

[Audio] No Smoking Policy. No Smoking Policy. No smoking is allowed in the yard except at designated locations : The corner of KH-1888 Barge W/S A near Female wash room Outside Worker’s wash room.

[Audio] In- House Safety Rules & Regulation. IN-HOUSE SAFETY RULES & REGULATION.

Safety footwear Always at all working locations outside offices Hard hat Always at all working locations outside offices Safety Glasses Always at all working locations outside offices Coverall Long Sleeves Always at all working locations outside offices Gloves Always when hazard for hand injury: e.g. manual works, use of abrasive tools Hearing Protection Where indicated, in areas with high noise levels.

Personal Protective Equipment. FULL BODY HARNESS WHILE WORKING ON HANGING SCAFFOLD > 2M PERMIT TO WORK FOR WORKING AT HEIGHT > 3M.

Access Control Procedures. Exchange of pass from Security post Compulsory QHSSE induction before entry into work areas Two tag card system for vessel access.

Access Control Procedures. Tag 1 (Gangway) – Place onto tag board before boarding vessel.

Access Control Procedures. Tag 2 (Confine space) – Place onto tag board before entering confine space.

Permit To Work. Cold Work permit (non routine hazardous work that do not involve ignition danger) Hot Work permit Maintenance work on pumps, process equipment, lifeboats, fire pumps All works that may result in danger of flames or other types of ignition such as welding, burning and cutting, works on electrical systems, excavation, bunkering, use of electrical items, etc. (Gas testing will be conducted prior work commencement) Electrical works up to 50V in non-hazardous areas, such as isolated and grounded instruments or equipments Maintenance work on critical safety systems, including fire and gas detection system, life saving equipment, fire fighting equipment Works that may cause an unintended or uncontrolled hazardous material release. Engine room maintenance Pressure testing of plant and equipment, hand and spray painting.

Permit To Work. Enclosed confine space Work on energize system Hot work form Working at height High risk activity Lock out tag out All permits are only valid for 12hrs!!.

STAGE 1 Trade foremen / Supervisors apply. STAGE 2 Safety Assessor endorse.

MVC-075S. Permit To Work. PERMITS MUST BE DISPLAYED AT THE WORK LOCATION PRIOR TO COMMENCE TO PREVENT INCOMPITIBLE WORK.

Risk Assessment. Screen Clipping. Screen Clipping.

Risk Assessment. Risk Assessment Methodology Identify the hazards Assess the Risk (refer to Risk Matrix) Control the Risk (Elimination, Substitution, Engineering, Administrative, PPE) Record the Risk Assessment Review periodically & alter if necessary..

JAN FEB MAR APR. MAY JUN JUL AUG. SEP OCT NOV DEC.

Picture 004. Picture 009. Lifting Machines (LM) – Inspect yearly for all crane and winch Lifting Appliance (LA) – inspect yearly for all chain blocks and pulley blocks Lifting Gear (LG) – Inspect yearly for all chain slings and wire rope Lifting Platform (LP) – Inspect every 6months for all cherry picker and dock arm.

MVC-078S. MVC-076S. Safe Work Procedures. Air Receiver (AR) – Inspected every 24months for all air compressor and pressure vessels Hot work tools: Welding/Electrical cables – Inspected every 30 days Gas Hoses – Inspected every 14 days.

MVC-093S. HPIM6074. HPIM6091. All scaffold must be inspected and endorsed every 7 days by a qualified scaffold supervisor.

N-UNATH$. NOFLAME$. NOSMOKE$. N-UNATH$. NOFLAME$.

CONFINE SPACE ENTRY Must obtain valid entry permit Adequate lighting & ventilation Ensure buddy system and a gas meter is being carried by competent gas meter carrier in the confine space Ensure gas test result is valid before entering O 2 – 20.9 ( 19.5% ~ 23.5% ) CO – 0% H2S – 0%.

Safe Work Procedures. Hot Work Activity Must obtain valid permit Ensure all flammables are away and protected Ensure hot sparks are contained Ensure availability of fire watchman and suitable firefighting medium.

Usage of Forklift and Self propelled Platform Designated and Qualified operator only. Machine to be registered and approved for use in yard. Use “approved checklist” for daily checking. DO NOT exceed safe working load and safe working capacity. Note : Forklift (headlight and beacon light compulsory) Self-propelled platform (overhead guard and outrigger fully extended compulsory).

Traffic Safety. Traffic Safety Only Land Transport Authority (LTA) registered and yard authorized ‘restricted use’ vehicles are allowed in the yard moving at 20km/ hr No entry to the work area unless issued with security vehicle pass Reverse parking at all times Walk along designated walkway.

Traffic Safety. Traffic Safety Do not walk below suspended loads Do not walk into suspended load working radius.

Traffic Safety Walkway To Office & Waterfront. 0.101 / H.

Traffic Safety Walkway To Office & Guard House. Designated Walkway to Office & Guard House.

Use only designated refuse bin. No disposal of hazardous and toxic waste.

iN10d wunv N\0d O. Emergency Response. In an emergency, evacuate to the nearest muster area. Do note of the following: 3 mins continuous siren To alert those around you and proceed to Muster point Remove confine space card from tag board before proceeding to muster point. Walk briskly to the muster point in an orderly manner Head count by Supervisor and report to the warden / safety personnel Wait for Further instruction from Safety Personnel.

Hazard & Incident reporting. ALL INCIDENT INCLUDING NEAR-MISS MUST BE REPORTED TO QHSSE DEPARTMENT IMMEDIATELY & NOT LATER THAN 24 HOURS. Supervisor to follow up with an incident report upon completion of required first aid..

Vaccination shall be at least 3 doses. Practice Personal Hygiene.

Yard Operations Henry Yeo (Head of Operations Shipyard – 8716 4483 ) Billy Ho (Project Manager) – 8285 7816 QHSSE Department Myo (Assistant QHSSE Manager ) – 9178 0514 Security Guard house – 6777 9990 (Ext: 703).

TOWARDS ZERO INCIDENT. KIM HENG.
