Scene 2 (7s)

abstract

MADAM MUNIRAH BINTI SHAMSUDDIN KOLEJ KEMAHIRAN TINGGI MARA, LENGGONG

Prepared for

Prepared by

SITI MAISARAH BINTI MOHD AZIZI LG 2002755

TECHNICAL MATHEMATIC

OBLIQUE TRIANGLES (COSINE RULE) & AREA OF TRIANGLES

Green Start Button - Start Button No Background PNG Image | Transparent PNG Free Download on SeekPNG

Click La Sole Sticker by Soledad Pastorutti for iOS & Android | GIPHY

Click La Sole Sticker by Soledad Pastorutti for iOS & Android | GIPHY

Scene 3 (31s)

INTRODUCTION

HOME

HOME

This video lesson will show you how you can use the   Law of Cosines , a formula to help you find the missing side or angle of any kind of triangle.

In this video lesson, we are specifically looking at  Oblique Triangles to use the Law of Cosines and to finding the Area of Triangles.

Then, we will explore the steps to finding the Area of Triangles.

1.

2.

NEXT

NEXT

Scene 4 (1m 0s)

NEXT

NEXT

OBLIQUE TRIANGLE

Any kind of triangle that is not a right triangle is an Oblique Triangle .

oblique triangle

Example

HOME

HOME

Scene 5 (1m 12s)

LAW OF COSINES

In any triangle, the square of any side is equal to the sum of the squares of the other two sides minus twice the product of these two sides multiplied by the cosine of the included angle.

a 2  = b 2  + c  2  – 2bc.cos A b 2  = a 2  + c  2  – 2ac.cos B c 2  = a 2  + b  2  – 2ab.cos C

cos A  = b 2  + c 2   – a 2 2bc cos B  = a 2  + c 2  – b 2 2ac cos C  = a 2  + b 2  – c 2 2ab

OR

In reference to the triangle shown in Figure A, the   Law of Cosines , for any triangle ABC is :

Figure A

Cosine Rule is defined as:

The  Law of Cosine is also known as Cosine Rule .

NEXT

NEXT

HOME

Scene 6 (2m 3s)

Three sides are given.

HOW TO USE COSINE RULES?

T wo sides and one included angle is given.

Cosine Rule can be used when the following values are given:

NEXT

NEXT

Let’s look the examples…

Penguin Walkcycle | Motion design animation, Animation walk cycle, Walking animation

HOME

Scene 7 (2m 22s)

HOW TO USE COSINE RULES?

Figure 1 shows the triangle ABC. Given that ∡B = 68 ° , AB = 20.5 cm, BC = 12.2 cm. Find the length of AC.

Example 1: Given 2 sides and included angle.

Figure 1

Cosine Rule can be used when the following values are given:

NEXT

NEXT

HOME

Solution 1

b2 = (20.5)2 + (12.2)2 - 680 = 408.04 + 148.84 + 187.38 = 369.5 = 19.22 cm

T wo sides and one included angle is given.

Scene 8 (4m 11s)

HOW TO USE COSINE RULES?

Figure 2 shows the triangle PQR. Given that ∡R = 111.4 ° , PR = 20 cm, RQ = 25 cm. Find : a) Length PQ b) ∡ Q

Example 2: Given 2 sides and included angle.

Figure 2

Cosine Rule can be used when the following values are given:

NEXT

NEXT

HOME

Solution 2

20 25 cm

a) b) r2 sin Q 20cm sin Q = 202 + 252 - cos 111.40 = 400 + 625 + 364.87 = 1389.87 = 37.28 cm sin 111.4 37.92cm 37.9cm = 0.4913 = 29.430

T wo sides and one included angle is given.

Scene 9 (6m 56s)

HOW TO USE COSINE RULES?

Figure 2 shows the triangle ABC. Given that AB = 6.4 cm, BC = 4.7 cm and AC = 7.8 cm. Find : a) ∡A b) ∡C

Example 3: Given 3 sides.

Figure 3

Cosine Rule can be used when the following values are given:

NEXT

NEXT

Solution 3

4.7 cm 6.4 cm 7.8 cm

sin LC b) 6.4 sin sin sin37.20 4.7 6.4sin37.020 4.7 = 0.8199 = 55.070

Three sides are given.

HOME

Scene 10 (9m 57s)

We have done looking at…

Check Box Gif GIFs | Tenor

Check Box Gif GIFs | Tenor

What is Oblique Triangle ?

Now let’s continue our lesson to finding Area of Triangle …

How to use Law of Cosine or Cosine Rules ?

Click La Sole Sticker by Soledad Pastorutti for iOS & Android | GIPHY

Fitness Keep Going Sticker by triangirlsocial for iOS & Android | GIPHY

NEXT

Check Box Gif GIFs | Tenor

What is Law of Cosine or Cosine Rules ?

HOME

Scene 11 (10m 23s)

Figure B

Area of Triangle is an any space that is inside the borders of a triangle shape.

The measurement or size of a surface on a shape is called the area .

NEXT

NEXT

Area of a Triangle 1

AREA OF TRIANGLE

HOME

Scene 12 (10m 48s)

AREA OF TRIANGLE

Figure C

In reference to the Area of Triangle shown in Figure C, the formula for finding the Area of Triangle is:

NEXT

NEXT

1 ax bx sin C 2 1 bxcx sin A 2 1 ax c x sin B 2

To find the area of a shape, we need to use a formula.

HOME

Scene 13 (11m 8s)

FINDING THE AREA OF TRIANGLE

Figure 4

NEXT

NEXT

13 cm 57.80 10 cm

Example 4

Solution 4

In Figure 4 shows Δ PQR. Such that PQ = 13 cm, QR = 10 cm and ∡ Q = 57.8 ° . Find the area of the triangle Δ PQR.

The area of the triangle PQR 1 x 13 x 10 sin 57.80 2 = 55.00 cm2

HOME

Scene 14 (11m 47s)

FINDING THE AREA OF TRIANGLE

Figure 5

NEXT

NEXT

Example 5

Solution 5

In figure 5 shows Δ ABC such that AC = 14 cm, BC = 11 cm and ∡ C = 125 ° . Find: AB ∡ B c) The area of the triangle ABC

1250

a) b) c) A 82 = (14)2+ = 196 + 121 + 176.7 A 82 sin ZB 14 sin XB = cos 1250 = 22.22 cm sin 1250 22.22 14xsin1250 22.22 = 31.10 Area of the triangle ABC 1 x 14 x 11 x sin 1250 2 = 63.1 cm2 = 0.5161

HOME

Scene 15 (14m 4s)

Autumn Frame Wood Mushrooms - Free image on Pixabay

Confetti Sticker by jubileemedia for iOS & Android | GIPHY

NEXT

NEXT

Click Next to continue

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

Hello Kitty Good Luck GIF - HelloKitty GoodLuck - Discover & Share GIFs | Good luck gif, Hello kitty pictures, Hello kitty

HOME

Scene 16 (17m 33s)

abstract

47 images about sanario gif on We Heart It | See more about gif, kawaii and my melody

Click here take a lesson again

Click here to take a Quiz

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

Arrow Click Through Sticker for iOS & Android | GIPHY

HOME

Activated Integrated Security - Electric Fencing

Activated Integrated Security - Electric Fencing

Scene 17 (18m 0s)

HOME

LAW OF COSINE

Choose the correct answer.

Hand Click Sticker by SHEDEVR for iOS & Android | GIPHY

Using the Cosine Rule, solve triangle PQR in which p = 6.5 cm, q = 7.4 cm and ∠R = 58 °. What is the approximate length of side r ?

Question 1

6.5

A. r = 6.70 cm

A. r = 6.70 cm

B. r = 5.70 cm

B. r = 5.70 cm

C. r = 6.78 cm

C. r = 6.78 cm

D. r = 5.78 cm

D. r = 5.78 cm

Scene 18 (18m 30s)

HOME

LAW OF COSINE

Choose the correct answer.

Hand Click Sticker by SHEDEVR for iOS & Android | GIPHY

Question 2

Use the information given in the figure to determine the value of c to the nearest tenth of a meter. a = 12.3 , b = 17.6.

A. 7.9 m

A. 7.9 m

B. 7.8 m

B. 7.8 m

C. 8.9 m

C. 8.9 m

D. 8.6 m

D. 8.6 m

A picture containing diagram Description automatically generated

Scene 19 (18m 55s)

LAW OF COSINE

Choose the correct answer.

Hand Click Sticker by SHEDEVR for iOS & Android | GIPHY

Find the missing side.

Question 3

A. 15.9 in

A. 15.9 in

B. 19.2 in

B. 19.2 in

C. 521.2 in

C. 521.2 in

D. 22.8 in

D. 22.8 in

15 in. 1150 12 in.

HOME

Scene 20 (19m 12s)

LAW OF COSINE

Choose the correct answer.

Hand Click Sticker by SHEDEVR for iOS & Android | GIPHY

Which Law would you use to find AB?

Question 4

A. Law of Sines

A. Law of Sines

B. Law of Cosine

B. Law of Cosine

C. Law of Gravity

C. Law of Gravity

D. Law of the Jungle

D. Law of the Jungle

26.3 92.20 27.2

HOME

Scene 21 (19m 32s)

LAW OF COSINE

Choose the correct answer.

Hand Click Sticker by SHEDEVR for iOS & Android | GIPHY

Question 5

A. ∡ A = 27.9 °

A. ∡ A = 27.9 °

B. ∡ A = 37.8 °

B. ∡ A = 37.8 °

C. ∡ A = 37.02 °

C. ∡ A = 37.02 °

D. ∡ A = 18.6 °

D. ∡ A = 18.6 °

Solve the triangle ABC. Given that AB = 6.4 cm, BC = 4.7 cm and AC = 7.8 cm. Find ∡A.

4.7 cm 6.4 cm 7.8 cm

HOME

Scene 22 (20m 2s)

LAW OF COSINE

Choose the correct answer.

Hand Click Sticker by SHEDEVR for iOS & Android | GIPHY

Question 6

A. 27.9 cm, 29 °

A. 27.9 cm, 29 °

B. 28 cm, 33.8 °

B. 28 cm, 33.8 °

C. 22.22 cm, 31.1 °

C. 22.22 cm, 31.1 °

D. 20.21 cm, 15.6 °

D. 20.21 cm, 15.6 °

In Δ ABC given that AC = 14 cm, BC = 11 cm and ∡ C = 125 ° . Find: AB ∡ B

1250

HOME

Scene 23 (20m 29s)

Choose the correct answer.

Hand Click Sticker by SHEDEVR for iOS & Android | GIPHY

Question 7

37 cm 1070 43 cm

Find: the area of the triangle PQR .

A. 220.76 cm 2

A. 220.76 cm 2

B. 560.34 cm 2

B. 560.34 cm 2

C. 760.74 cm 2

C. 760.74 cm 2

D. 64.41 cm 2

D. 64.41 cm 2

AREA OF TRIANGLE

HOME

Scene 24 (20m 51s)

Choose the correct answer.

Hand Click Sticker by SHEDEVR for iOS & Android | GIPHY

Question 8

Which a = 27.2 cm, b = 26.3 cm, and ∠ C = 92.2 °. Find the area of a triangle ABC.

A. 300.42 cm 2

A. 300.42 cm 2

B. 357.42 cm 2

B. 357.42 cm 2

C. 200.42 cm 2

C. 200.42 cm 2

D. 257.42 cm 2

D. 257.42 cm 2

26.3 92.20 27.2

AREA OF TRIANGLE

HOME

Scene 25 (21m 16s)

Choose the correct answer.

Hand Click Sticker by SHEDEVR for iOS & Android | GIPHY

What is the area of this triangle?

Question 9

A. 12 cm

A. 12 cm

B. 12 cm 2

B. 12 cm 2

C. 63.1 cm

C. 63.1 cm

D. 63.1 cm 2

D. 63.1 cm 2

1250

AREA OF TRIANGLE

HOME

Scene 26 (21m 35s)

Choose the correct answer.

Hand Click Sticker by SHEDEVR for iOS & Android | GIPHY

Which j = 6.9 cm, k = 9.7 cm, l = 14 cm and ∠ L = 113.93 °. What is the area of this triangle JKL ?

Question 10

A. 39.29 cm

A. 39.29 cm

B. 38 cm 2

B. 38 cm 2

C. 30 cm

C. 30 cm

D. 30.59 cm 2

D. 30.59 cm 2

14 cm 9.7 cm 6.9 cm

AREA OF TRIANGLE

HOME

Scene 27 (22m 0s)

Happy Flowers Sticker by B.Duck for iOS & Android | GIPHY

Effects confetti GIF on GIFER - by Coimand

Effects confetti GIF on GIFER - by Coimand

That’s Right!

HOME

HOME

Effects confetti GIF on GIFER - by Coimand

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

Click here

Scene 28 (22m 19s)

That’s Right!

Check Mark Gif 8 - 1500 X 1500 - WebComicms.Net

Happy Laugh Sticker by B.Duck for iOS & Android | GIPHY

Sun Look Sticker by stephlamdesign for iOS & Android | GIPHY

HOME

HOME

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

Click here

Scene 29 (22m 35s)

That’s Right!

Bondonshop | Home of Best Product | Sharee | Dress | Panjabi

Image result for thumb vector

HOME

HOME

Scene 30 (22m 45s)

Glitter Explosion Sticker by Chris for iOS & Android | GIPHY

Glitter Explosion Sticker by Chris for iOS & Android | GIPHY

That’s Right!

Well Done Good Job Sticker by Michael Shillingburg for iOS & Android | GIPHY

Transparent Stock Right Check Mark Pencil And In Color - Pencil Check Mark Gif - 960x553 PNG Download - PNGkit

HOME

HOME

Scene 31 (23m 5s)

That’s Right!

Check Mark Gif 8 - 1500 X 1500 - WebComicms.Net

Happy Laugh Sticker by B.Duck for iOS & Android | GIPHY

Sun Look Sticker by stephlamdesign for iOS & Android | GIPHY

HOME

HOME

Scene 32 (23m 21s)

That’s Right!

LINE Official Stickers - My Melody: Eyes On Me! Example with GIF Animation

Check Box Gif GIFs | Tenor

HOME

HOME

Scene 33 (23m 32s)

Mim Congrats GIF - Mim Congrats Congratulations - Discover & Share GIFs | Congratulations gif, Cute gif, Cute cartoon images

That’s Right!

Check Box Gif GIFs | Tenor

HOME

HOME

Scene 34 (23m 45s)

Glitter Explosion Sticker by Chris for iOS & Android | GIPHY

Glitter Explosion Sticker by Chris for iOS & Android | GIPHY

That’s Right!

Well Done Good Job Sticker by Michael Shillingburg for iOS & Android | GIPHY

Transparent Stock Right Check Mark Pencil And In Color - Pencil Check Mark Gif - 960x553 PNG Download - PNGkit

HOME

HOME

Scene 35 (24m 5s)

That’s Right!

LINE Official Stickers - My Melody: Eyes On Me! Example with GIF Animation

Check Box Gif GIFs | Tenor

HOME

HOME

Scene 36 (24m 17s)

Mim Congrats GIF - Mim Congrats Congratulations - Discover & Share GIFs | Congratulations gif, Cute gif, Cute cartoon images

That’s Right!

Check Box Gif GIFs | Tenor

HOME

HOME

Scene 37 (24m 31s)

Oops, that’s wrong!

Stop No Sticker by imoji for iOS & Android | GIPHY

Sticker of B.Duck on Behance

Don’t give up! Let’s try again

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

HOME

HOME

Red illuminated TRY AGAIN push button for pinball or arcade

Red illuminated TRY AGAIN push button for pinball or arcade

Scene 38 (24m 49s)

Oops, that’s wrong!

Stop No Sticker by imoji for iOS & Android | GIPHY

Don’t give up! Let’s try again

B.Duck Sticker for iOS & Android | GIPHY

HOME

HOME

Red illuminated TRY AGAIN push button for pinball or arcade

Red illuminated TRY AGAIN push button for pinball or arcade

Scene 39 (25m 0s)

Sparkle Blinking Sticker for iOS & Android | GIPHY

Oops, that’s wrong!

Stop No Sticker by imoji for iOS & Android | GIPHY

Let’s try again

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

Motivation Keep Going Sticker by Russell Taysom for iOS & Android | GIPHY

HOME

HOME

Red illuminated TRY AGAIN push button for pinball or arcade

Red illuminated TRY AGAIN push button for pinball or arcade

Scene 40 (25m 16s)

Sparkle Blinking Sticker for iOS & Android | GIPHY

Oops, that’s wrong!

Stop No Sticker by imoji for iOS & Android | GIPHY

Don’t give up! Let’s try again

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

Fitness Keep Going Sticker by triangirlsocial for iOS & Android | GIPHY

HOME

HOME

Red illuminated TRY AGAIN push button for pinball or arcade

Red illuminated TRY AGAIN push button for pinball or arcade

Scene 41 (25m 30s)

Oops, that’s wrong!

Stop No Sticker by imoji for iOS & Android | GIPHY

Don’t give up! Let’s try again

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

Payment unsuccessful — FESTKA

Laugh Smile Sticker by B.Duck for iOS & Android | GIPHY

HOME

HOME

Red illuminated TRY AGAIN push button for pinball or arcade

Red illuminated TRY AGAIN push button for pinball or arcade

Scene 42 (25m 45s)

Oops, that’s wrong!

Stop No Sticker by imoji for iOS & Android | GIPHY

Sticker of B.Duck on Behance

Don’t give up! Let’s try again

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

HOME

HOME

Red illuminated TRY AGAIN push button for pinball or arcade

Red illuminated TRY AGAIN push button for pinball or arcade

Scene 43 (25m 58s)

Oops, that’s wrong!

Stop No Sticker by imoji for iOS & Android | GIPHY

Don’t give up! Let’s try again

B.Duck Sticker for iOS & Android | GIPHY

HOME

HOME

Red illuminated TRY AGAIN push button for pinball or arcade

Red illuminated TRY AGAIN push button for pinball or arcade

Scene 44 (26m 8s)

Sparkle Blinking Sticker for iOS & Android | GIPHY

Oops, that’s wrong!

Stop No Sticker by imoji for iOS & Android | GIPHY

Let’s try again

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

Motivation Keep Going Sticker by Russell Taysom for iOS & Android | GIPHY

HOME

HOME

Red illuminated TRY AGAIN push button for pinball or arcade

Red illuminated TRY AGAIN push button for pinball or arcade

Scene 45 (26m 24s)

Sparkle Blinking Sticker for iOS & Android | GIPHY

Oops, that’s wrong!

Stop No Sticker by imoji for iOS & Android | GIPHY

Don’t give up! Let’s try again

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

Fitness Keep Going Sticker by triangirlsocial for iOS & Android | GIPHY

HOME

HOME

Red illuminated TRY AGAIN push button for pinball or arcade

Red illuminated TRY AGAIN push button for pinball or arcade

Scene 46 (26m 38s)

Oops, that’s wrong!

Stop No Sticker by imoji for iOS & Android | GIPHY

Don’t give up! Let’s try again

Arrow Swipe Up Sticker by Nickelodeon for iOS & Android | GIPHY

Payment unsuccessful — FESTKA

Laugh Smile Sticker by B.Duck for iOS & Android | GIPHY

HOME

HOME

Red illuminated TRY AGAIN push button for pinball or arcade

Red illuminated TRY AGAIN push button for pinball or arcade

Scene 47 (26m 53s)

Glitter Explosion Sticker by Chris for iOS & Android | GIPHY

Glitter Explosion Sticker by Chris for iOS & Android | GIPHY

Glitter Explosion Sticker by Chris for iOS & Android | GIPHY

Let’s start again

Congrats GIF by Reactions | Gfycat

I Like It Arrow Sticker by Linzie Hunter for iOS & Android | GIPHY

Mental Health Good Job Sticker by Ana Lu for iOS & Android | GIPHY

HOME

Happy Laugh Sticker by B.Duck for iOS & Android | GIPHY

Related image

Enquiry: sitimaisarah320.dpd@lenggong.kktm.edu.my
