Clear view, day and night Observe, identify and finally aim: Snipers / Marksmen have tough calls to make, and the great distances to targets do not make these decisions any easier. These marksmen must remain motionless despite all the discomforts and often challenging weather that can turn a mission into a nerve-racking trial of endurance. Their concentration may never falter and they must always gather as much intelligence as they can through unflagging observation. Anything that wins time and helps collect information is good for the mission. The earlier a threat can be identified, the more options are available to address it. Security forces today save lives, rescue hostages and conduct surveillance from afar. Police or military, all these units need visors and observation instruments of the highest optical and optronic quality to do their duty. Observing, identifying and making good decisions at a moment’s notice are no easy tasks. Reliance Sights offer the perfect kit to get the job done for every mission posture. Equipped with latest modular attachments and state-of-the-art night sights, snipers, infantrymen, forward observers and special forces can focus on what matters most – their mission.

abstract

abstract

Scene 2 (12s)

Robust & Reliable

Easy to Use

RES – TIMG is a Night (TI) Sight designed for Medium Machine Gun ‘MAG 2A1 7.62x51mm’ This sight helps to target acquisition and improves the fighting power of the Indian troop during Day and Night operation. RES-TIMG is lightweight and compact sized Thermal Weapon Sight, optimizing firing capabilities for MMG. High Ergonomic Design makes it extremely user friendly.

abstract

abstract

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Modern Design

Truly Ergonomic Design

Precise Images

Advance Technology

Scene 3 (1m 20s)

Dimension

M6.o

86.0

293.0

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 4 (1m 34s)

Exterior

Joystick

Battery Assembly

Eye Guard

Eyepiece Assembly - Diopter Control

abstract

Power Switch

Connector

Mount Assembly

Objective Lens Cover

Objective Lens and Assembly

Main Body Assembly

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 5 (2m 4s)

Description of Each Main Module

Objective Lens Assembly

abstract

- Objective Housing - Objective Lens Cell

Main Body Assembly Module

Main Housing Focusing SA Mount IR Detector Module Battery Cell

Eye Piece Assembly Module

Eyepiece Lens Digital OLED Power ON/OFF Switch

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 6 (2m 29s)

Battery Installation

Turn the battery cover release button to counterclockwise

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 7 (2m 45s)

Battery Installation

Insert two 18650 batteries into the battery housing so that the terminal orientation of the 18650 batteries matches the +/- direction marked on the back of the battery housing.

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 8 (3m 4s)

Replacement of Objective Lens Cover

abstract

When removing or installing an objective lens cover, fasten and assemble the two screws and guides on both sides using a + driver.

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 9 (3m 23s)

Replacement of Eye Guard and Lens Cab

When removing eye guard and eyepiece lens cap , remove it by turning it slowly counterclockwise. When installing, check the threads of the eye guard and eyepiece lens cap , do not apply excessive force, and rotate clockwise to install. When not in use the sight, install a lens cap and store it.

Eye Guard

Eyepiece Lens Cab

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 10 (3m 57s)

Diopter adjustment

For the clear target observation at day and night, you can focus User's eyesight by rotating Eye Diopter Ring to the left or right. Eye focus adjustment [counterclockwise (-): near focus / clockwise (+): far focus]

“+”

“-”

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 11 (4m 26s)

Power On/Off

abstract

After inserting the 18650 battery, check the power switch located under the eyepiece lens and turn it on/off.

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 12 (4m 50s)

Battery Status

Full Battery

~ 75%

~ 50%

E:\01.극비(ILS)\024. 인도조준경(인도 수출)\10. 열상매뉴얼\001. 형상\battery_25.bmp

~ 25%

E:\01.극비(ILS)\024. 인도조준경(인도 수출)\10. 열상매뉴얼\001. 형상\battery_low.bmp

Low Battery / 5% (Battery Should be changed)

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 13 (5m 24s)

Hot Key

abstract

Up

Right

Down

Left

Center

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 14 (5m 42s)

Hot key functions

Key button Contents 1 Up Short Push Increase Range Only MIL Type Reticle (200~1.1km / 100m) Long Push Reticle color change red / blue / white / Black / reticle off 2 Down Short Push Decrease Range Only MIL Type Reticle (200~1.1km / 100m) Long Push Enter to Zeroing Adjustment Mode Left/ Right: -25 ~ +25 Move Up/Down: -50 ~ +50 Move 3 Left Short Push E-Zoom Digital zoom 1X / 2X / 4X switch 4 Right Short Push White/Black Hot Black / White switch @Thermal mode Long Push BIT I-BIT 5 Center Short Push NUC Calibration (Image Clear) @Thermal mode Long Push Enter Menu MENU IN/OUT

RES – TIMG “ Night (TI) Sight”

REL-logotype3D_100-80_FM

Scene 15 (6m 17s)

abstract

Specification

640 x 480, 17um Thermal Detector

Optical 3X, E-Zoom: 4X

FOV: 7.68° x 5.76°

Diopter Correction: -3D ~ +4D

Operation Hour: ≥ 5hrs

Environmental Condition: MIL-STD-810G

EMC/EMI: MIL-STD-461F (NABL Certified)

Weight: ≤ 1.3kg (With Battery)

Detection: 2.3km Recognition: 0.94km Identification: 0.49km

FOR UPGRADING NIGHT OPERATION CAPABILITY YOU SHOULD BE WITH RES-TIMG
