Rancher-Managed-EKS-Architecture (1)

[Audio] Rancher-Managed EKS Architecture A comprehensive deployment workflow integrating CI/CD pipelines, Rancher platform management, and AWS EKS clusters for scalable container orchestration. We're introducing the Rancher-Managed EKS Architecture—the blueprint for highly scalable, governed container orchestration. This solution seamlessly integrates continuous deployment with the robust framework of AWS EKS.

[Audio] Application Deployment Workflow GitHub Source code repository triggers the pipeline Jenkins Build and test automation Docker Container image building Nexus Container registry storage Rancher Platform Features Key Capabilities User Management with RBAC & Authentication Helm Chart Catalog GitOps Deployments EKS Cluster Import & Integration Multi-Cluster Management Workload Deployment Management Policy Management & Backup Health & Metrics Monitoring Our deployment pipeline ensures speed and reliability. Development begins in GitHub, triggering Jenkins for automated build and stringent testing. Docker then finalizes the standardized container image, which is securely cataloged in the Nexus registry, establishing version control for every application component..

[Audio] AWS EKS Cluster Infrastructure EKS Control Plane Worker Nodes AWS Managed: API Server, etcd state store, and scheduler for pod management Auto Scaling: Frontend (nginx), API (node), Load Balancing Traffic Routing: AWS ALB with NGINX Ingress controller Build Code pushed to GitHub triggers Jenkins build Package Docker image created and pushed to Nexus Deploy Rancher deploys to EKS worker nodes Monitor Splunk & AppDynamics track performance Rancher serves as our unified control plane, delivering centralized governance through RBAC and policy management, offering a single interface to manage all EKS clusters. Our key steps: One: Build is verified. Two: Package is registered. Three: Deploy! Rancher automates the deployment manifest directly to our EKS worker nodes, ensuring consistent workload placement..

[Audio] Splunk & AppDynamics track performance Health & Metrics Monitoring:- The applications run on the high-availability AWS EKS Infrastructure, utilizing AWS-managed control plane services, auto-scaling worker nodes, and an ALB & NGINX for precise traffic routing. Finally, Step Four: Monitor. Tools like Splunk and AppDynamics provide comprehensive visibility, guaranteeing operational health and stability..
