Scene 1 (0s)
Welcome To our presentation.
Scene 2 (5s)
Non-Traditional Machining 06.
Scene 3 (11s)
̴INTRODUCTION ̴ Non-conventional machining processes are methods that use energy other than physical force from a cutting tool to remove material from a workpiece..
Scene 4 (21s)
Comparison:- Traditional Machining ➢ Physical contact between tool and workpiece. ➢ Mechanical cutting (shearing). ➢ Tool wears out due to contact. ➢ Maintenance cost is low. ➢ Faster material removal in general. Non-Traditional machining ➢ No physical contact between tool and workpiece. ➢ Uses electrical,chemical,thermal etc. ➢ Minimal or no tool wear. ➢ High setup or operational cost. ➢ Slower in many processes..
Scene 5 (40s)
Non Traditional Machining Processes Classification Non Traditional Machining Processes Mechanical Energy Electrical Energy Electrochemical Energy Thermal Energy.
Scene 6 (48s)
Types of Non-traditional process:- ➢Electric Discharge Machining (EDM) ➢Electro Chemical Machining (ECM) ➢Ultrasonic Machining (USM) ➢Laser Beam Machining (LBM).
Scene 7 (57s)
Flushin Nozzle Filter Pump EDM Machining Electrode Tank Dielectric Fluid Spark Gap.
Scene 8 (1m 3s)
Advantages of Non-Conventional Machining:- ➢ No direct contact between tool and work piece. ➢ Material is removed using energy sources like mechanical,thermal,chemical and electro chemical. ➢ Minimal or no mechanical force is applied during machining. ➢ Suitable for hard and brittle material. ➢ It can produce complex shapes and fine surface finishes..
Scene 9 (1m 19s)
Limitations of Non- Traditional Machining:- ➢High initial cost of equipments. ➢Slower material removal rate. ➢Required skilled operators. ➢High energy consumption. ➢High operating cost..
Scene 10 (1m 31s)
Applications of Non Traditional Machining :- ➢Aerospace ➢Medical ➢Electronics ➢Automotive ➢Tool and Die.
Scene 11 (1m 38s)
Future Scope of NTM 1 2 3 A1 Optimization Micro-Machining Hybrid Processes Future NTM will achieve improved material removal rates and efficiency..
Scene 12 (1m 47s)
Conclusion N TM enables manufacturing of advanced products. Continuous development drives efficiency and accuracy. Essential for modern industries. References: • Kalpakjian, S. & Schmid, S. R. (2014). Manufacturing Engineering and Technology. Pearson Education. • Ghosh, A. & Mallik, A. K. (2010). Manufacturing Science. Affiliated East-West Press..
