Know Your Instruments. VBOX-4 + IMU05 100 HZ DAQ SYSTEM 100 Hz GPS based system 24 bit 04 Analog channels,02 digital channels Interface: Bluetooth, RS232, USB CAN Bus for data input and output Brake test. Acceleration/Deceleration Pass by noise measurement Vehicle Dynamic Testing CAN data logging. FLUKE 1587 FC INSULATION MULTIMETER Voltage (AC/DC): Up to 1000 V Current (AC/DC): Up to 400 mA Resistance: Up to 50 MΩ Resistance Range: 0.01 MΩ to 2GΩ Insulation Testing of Wiring Harnesses & Motors.(EV) Troubleshooting Electrical Faults. Testing Electric Vehicle (EV) Components Charging System Diagnostics MULTI-FUNCTION CALIBRATOR-CA71 & VIR CALIBRATOR AC/DC Voltage : Up to 100V AC/DC amps : Up to 100mA Resistance : 0-400Ω Power source During the calibrations. Measure AC/DC voltages. Measure AC/DC current..

Know Your Instruments. DM70 Dew Point Meter Accuracy: ±2 °C for dew point measurements. Measures environmental moisture and Humidity. Data logging. Output: Dew point temperature, humidity. Measurement type: Physical, thermodynamic GAS FLOW METER Capacity: 21.2 – 60.0 kg/hr Linearity: +0.25 - 0.50% Accuracy: +1 -2.5% Output interface RS232/RS485 digital communications. Measure the accurate real-time gas flow monitoring Variants from 13KG to 15KG. ULTRASONIC THICKNESS GAUGE Range: 0.080 mm to 635mm Accuracy: +0.01mm Measures thickness of metal and composite parts for quality control. Ensures uniform thickness in metal sheets, plastic, glass, and composite materials.

Know Your Instruments. INCLINOMETER Axes : 1, 2 & 3 Axes Range : +45° to +60° Accuracy : +0.01° Measure the tilt angle or inclination angles various testing. Dynamic Vehicle Control. Trailer and Load Monitoring. DIGIMATIC LOW FORCE CALIPER MITUTOYO Range : 0-180mm. Accuracy : ±0.05mm. Low measuring force : 0.5-1mm. Plastic interior and exterior parts Measure Rubber, Gasket, Plastic Fittings, Tubes Measure Dimensional equipment verifications CALIPER CHECKER Range: 0 to 600mm. Accuracy: +0.005mm SLIP GAUGE SET Range : 1-100 mm Make : CCCP Calibration of all kind of Calipers & Height Gauges & Vernier ranges: 150mm,300mm, 600mm. micrometers, Vernier calipers, dial gauges, and other precision tools..

Know Your Instruments. REFRACTOMETER Range : Brix 0.0–53.0% Resolution : 0.2% Accuracy: ±0.2% within 10–30°C Repeatability : ±0.1% Coolant and Ad- Blue Testing check essential fluid concentrations. indicating dilution or contamination, crucial for engine health, performance, and emissions compliance NON-CONTACT CAN SENSOR-HIOKI Communication Speeds: SP7001: CAN FD (125 kbps to 3 Mbps). SP7002: CAN (125 kbps to 1 Mbps). Easy CAN Acquisition Simply Pinch Over Wire Insulation automotive diagnostics, non-contact acquisition reconstruction of CAN/CAN FD signals CHAVLIN ARNOUX CURRENT PROBE PAC-27 Range AC/DC : Upto 1000 A Accuracy: ±1% To check the High current range in field testing. Check current draw during startup and operation. Identify abnormal current patterns indicating faults..

Know Your Instruments. FUNCTION GE FUNCTION GENERATOR Make : SIGLENT Model : SDG1062X Standard Waveforms: Sine, Square, Ramp, Pulse, Noise. Pulse, Noise. Can measure resistance, DC current, AC current, fre Arbitrary Waveforms: User-defined (2 to 16 kpts) Modulation Types: AM, DSB-AM, FM, PM, ASK, FSK, PSK, PWM Sweep, Burst Modes & Harmonics Generator Waveform Combining 6 ½ DIGIT DIGITAL MULTIMETER-SIGLENT AC/DC current:200 μA – 10 A DC Voltage : 200mV-1000V AC Voltage : 200mV-750V Resistance: 200 Ω – 100 MΩ Can measure resistance, DC current, AC current, frequency, time period etc. Capacitance: 2 nF – 100 mF Frequency: 3 Hz – 1 MHz Period: 1 μs – 333 ms Resolution : 0.00001.

Know Your Instruments. SHUNT RESISTANCE Range: 10A to 100A Current sensing on hybrid & electric vehicles Current measuring devices monitoring the current of the motor control circuit and battery systems. POWER ANALYZER YOKOWAVA- 600A HIOKI – 1000A FLUKE – 600A, 1000A Basic power accuracy: 0.04% Electrical vehicle Power measurement Advanced computation function: Waveform computation, FFT analysis, waveform sampling data. Measuring Harmonic / Voltage fluctuation / flicker and consuming power details in entire power system CLAMP ON METER AC/DC clamp on meter Range : 2A to 2000A Resolution : 0.1mA to 1A EV and Fuel cell vehicle. Current and voltage parameters in a cable of wiring harness.

Know Your Instruments. V BOX system 100 Hz GPS based system 24 bit 04 Analog channels,02 digital channels Interface: Bluetooth, RS232, USB CAN Bus for data input and output Brake test CTL GPS based test Vehicle Performance Testing ADAS (Advanced Driver Assistance Systems SPEED MINI – SLF GPS based system USB & LAN support 02 Analog inputs Speed limiting test GPS based test analysis Automated system VEHICLE SPEED SENSOR Optical based system 02 analog channels CAN & USB support Speedo & Odo test Speed related tests like SLF, AC performance, CSFC.

Know Your Instruments. IPETRONIK LOGGER Analog channels : 4+ Expandable Counter channels : 4+ Expandable Temp channels : 8+ Expandable Can Nodes : 4 In built GPS : 1 Vehicle CAN data recording Cooling test Thermal mapping test GRAPTECH LOGGER Analog channels : 60 Recording of Voltage and temperature Cooling test Thermal mapping test AC Performance test Exhaust temperature measurement N-I LOGGER WITH STEERING WHEEL Analog channels : 4 Steering wheel angle & Torque measurement.

Know Your Instruments. FUEL FLOW METER CALIBRATION SYSTEM Range : 10 Lph to 200 Lph Automated system This system use as reference under the traceability of NABL accredited lab Variants are 60Lph, 80Lph, 120Lph and 200Lph DFL 150Lph Flowmeter system PRESSURE CALIBRATION SYSTEM Pneumatic Calibrator: Negative Pr.(Suction) : Upto -1 Bar Positive pressure : 0 to 20 Bar Hydraulic Calibrator : 0 to 1000 Bar This system use as reference under the traceability of NABL accredited lab Variants are 2 , 16 bar, 200 bar, 500 & 700 bar Differential Pressure Transmitter (-1 to 1bar, -1 to 3 Bar) TEMPERATURE CALIBRATION SYSTEM Dry bath Calibrator: Range: -30° to 600°C Oil bath Calibrator: Range: 30° to 200°C This system use as reference under the traceability of NABL accredited lab Variants are Closed type, button type and open type Thermocouples.

Know Your Instruments. TEMPERATURE INDI & IR GUN Measures up to 1000°C TEMPERATURE INDICATOR - Configurable with different types of thermocouples and RTD with Voltage o/p Ambient temp measurements Oil related temp measurements Surface temp measurements THERMAL IMAGER & POCKET IMAGER Manual focus infra-red camera with 260x195 resolution Captures optimal images from as close as 0.15m (6in) Offers temperature measurement range from -20 °C to 550 °C Measure high temperature in Various location with images. Non contract type.

Know Your Instruments. RF COMBINATION ANALYSER N9914A- 30 kHz to 6.5 GHz Dynamic range: 100 dB RF source: 30 kHz to 6.5 GHz, CW, CW coupled, and tracking For EMI and EMC test in vehicle FOG MACHINE 1200 watt Power 1.5 Litre smoke fluid volume 8m shooting distance AC leakage inside the cabin Air leakage in closed chamber PORTABLE GAS DETECTOR CNG gas leak detection Model : PG-100-D & PG-100-S CNG vehicle Gas leakage checking. Engine Test bed application for gas leakage detector..
