[Audio] UNIT III SCHOOL SHOPS AND HAND TOOLS Patrick Neil Santiago Ph.D.

[Audio] Objectives Define and deliberate School Shops; Discuss types of school shops, planning the shop, and shop arrangement; Describe Hand Tools; and Demarcate the different classification of hand tools. At the end of the session, students should be able to: 1. 2. 3. 4..

[Audio] The hand is the tool of tools. ~ Aristotle.

[Audio] Analysis What are the types of school shops? How to plan and arrange shop? What is Hand Tool? What are the classifications of hand tool? How to be safe when using hand tools? What is School Shop? 1. 2. 3. 4. 5..

[Audio] School Shops 03.. . . School Shops. 03.. .

[Audio] School Shops School shops is utilized for developing occupational skills. Therefore, school administrators must allot a budget to provide and equipped them with necessary tools and equipment. They are planned and furnished in accordance with the courses to be taken in them..

[Audio] Planning the Shop: Planning the school shop must considers some factors like budgets, location, features or attributes, workspaces and dimensions, etc….

This diagram shows the sample layout of the school shop.

[Audio] Demonstration Room: it is an area in school shops where the teacher demonstrates the skill to be acquired by the students. Planning Room: it is an area in school shops where the students will study and analyze their shopwork, make their job plans and prepare working drawings..

[Audio] Assembly Room: it is an area in school shops where the students assembles their shopwork based on job plans and working drawings. Tool Room: it is an area in school shops where the different hand tools and equipment are in placed..

[Audio] Storage Room: it is an area in school shops where supplies and materials are kept. It is advisable that this room must have a wider door openings to facilitate the delivery of supplies and materials. Teacher's Room: it is an area in school shops where the teachers' kept their records, books, journals and magazines..

[Audio] Shop Arrangement Laboratory-in -charge must arrange the shop to maximize its full features. They must considered the flexibility of shop attributes, and the convenience of its users as well. Furthermore, they should be the one who will plan upon the laying out of the equipment. 1..

[Audio] Shop Arrangement 2. School shops must be stationed on the place where other school activities must not be interrupted nor distracted. 3. School shops must be provided lockers to be utilized by its users to secure their personal belongings and it should be supervise by the laboratory-in-charge..

[Audio] Shop Arrangement 4. School shops must have washing station and drinking fountain facilities to be utilized by their users. 5. School shops must be provided a first aid kit and medicine cabinet with sufficient essential supplies and it must be placed in the office of the laboratory-in-charge..

[Audio] HAND TOOLS A hand tool is any tool that is powered by hand rather than a motor..

[Audio] Hand Tools Classification Measuring Fastening – Wrenches Fastening – Screwdrivers Fastening – Pliers Cutting Striking/ Driving.

[Audio] Hand Tools ( Measuring) Feeler Gauges Micrometer Dial Caliper Protractor / L-Square Measuring Tape/ Ruler Tape Measure Measuring Cup Measuring Spoon.

[Audio] Feeler Gauge- it is use to measure the distance between parts Measuring: Automotive Technology.

[Audio] Measuring: Micrometer – it is use to measure the diameter and thickness Automotive Technology.

[Audio] Measuring: Dial Caliper – it is use to measure inside, outside and depth of parts Automotive Technology.

[Audio] Measuring: Protractor / L-Square – it is use to measure linear and angles Carpentry & Drafting Technology.

[Audio] Measuring: Measuring Tape / Ruler – it is use to measure linear distance Carpentry & Drafting Technology.

[Audio] Measuring: Tape Measure– it is use to measure body parts Apparel and Fashion Technology.

[Audio] Measuring: Measuring Cup – it is use to measure liquid ingredients Food Technology.

[Audio] Measuring: Measuring Spoon – it is use to measure solid ingredients Food Technology.

[Audio] Hand Tools ( Fastening - Wrenches) Open End Box End Combination Ratchet and Socket Adjustable Hex Key / Allen Impact Torque.

[Audio] Fastening - Wrenches: Open End – it is use to loosen/tighten bolt or nut with contact on two flats Automotive Technology.

[Audio] Fastening - Wrenches: Box End – it is use to loosen/tighten bolt or nut; less likely to slip off than open end wrench Automotive Technology.

[Audio] Fastening - Wrenches: Combination – it is use to loosen/tighten bolt or nut with convenience of open end and box end on same wrench Automotive Technology.

[Audio] Fastening - Wrenches: Ratchet and Socket – it is use to loosen/tighten bolt or nut in tight locations Automotive Technology.

[Audio] Fastening - Wrenches: Adjustable – it is use to loosen/tighten bolt or nut in tight locations Automotive Technology.

[Audio] Fastening - Wrenches: Hex Key / Allen – it is use to loosen/tighten hexagon screws Automotive Technology.

[Audio] Fastening - Wrenches: Impact – it is use to loosen/tighten with air or electric power with short, rapid impulses to socket Automotive Technology.

[Audio] Fastening - Wrenches: Torque – it is use to loosen/tighten specified torque Automotive Technology.

[Audio] Hand Tools (Fastening - Screwdrivers) Flat Head / Slotted Philipps Torx / Star Hex Pozidriv Robertson / Square Tri Wing.

[Audio] Fastening - Screwdrivers: Flat Head / Slotted – it is use to loosen/tighten screws with a straight linear intrusion across the head Automotive, Electrical & Electronics Technology.

[Audio] Fastening - Screwdrivers: Philipps – it is use to loosen/tighten Philipps head screws which have a cross shape recess Automotive, Electrical & Electronics Technology.

[Audio] Fastening - Screwdrivers: Torx / Star – it is use to loosen/tighten screw head with a six-point star intrusion Automotive, Electrical & Electronics Technology.

[Audio] Fastening - Screwdrivers: Hex – it is use to loosen/tighten hex screw head Automotive, Electrical & Electronics Technology.

[Audio] Fastening - Screwdrivers: Pozidriv – this is an upgraded version of Philipps designed to reduce slips out of the screw Automotive, Electrical & Electronics Technology.

[Audio] Fastening - Screwdrivers: Robertson / Square – it is use to loosen/tighten screw head with a square-shaped recess Automotive, Electrical & Electronics Technology.

[Audio] Fastening - Screwdrivers: Tri Wing – it is use to loosen/tighten screw head in console, mobile phone and camera devices Automotive, Electrical & Electronics Technology.

[Audio] Hand Tools (Fastening - Pliers) Slip Joint Adjustable Locking Needle Nose Snap Ring.

[Audio] Fastening - Pliers: Slip Joint – it is use to grip fasteners and parts Automotive, Electrical & Electronics Technology.

[Audio] Fastening - Pliers: Adjustable – it is use to grip large fasteners and parts Automotive, Electrical & Electronics Technology.

[Audio] Fastening - Pliers: Locking – it is use to lock on fasteners and/or hold parts Automotive, Electrical & Electronics Technology.

[Audio] Fastening - Pliers: Needle Nose – it is use to grip fasteners and/or parts in tight locations Automotive, Electrical & Electronics Technology.

[Audio] Fastening - Pliers: Snap Ring – it is use to install and remove snap ring fasteners Automotive, Electrical & Electronics Technology.

[Audio] Hand Tools ( Cutting) Hacksaw Drill Cold Chisel File Scissor Handsaw Snip Diagonal Cutting Pliers.

[Audio] Cutting: Saw – it is use to cut wood Carpentry.
