undefined. Water Pump. 24/10/62. 2. Types of Water Pumps Automatic Water Pump Submersible Pump Centrifugal Pump Groundwater Pump.

undefined. Automatic Water Pump. Automatic Water Pump consists of Use to pump water from well / tap water with pump range not exceeding 8-9 meters.

undefined. Automatic Water Pump. Auto Water Pump – Constant Pressure Provide constant water pressure and water amount. Reduce problem with water shortage during use. Contain automatic switch that turns on-off according to the usage of water tap. Suitable for homes that have shower heater / water heater..

[Audio] Auto Water Pump – Constant Pressure Inverter Save energy. Provide consistent water pressure. The motor adjusts its rotation according to the pattern of water usage. Water pressure remains constant even when water is turned on at multiple spots..

[Audio] Auto Water Pump – Regular (Inconstant Pressure) Turn on automatically when a water tap is turned on. Suitable for general water usage. Increase water pressure inside the pipe. Water pressure can be inconsistent when turning on water at multiple spots at the same time. Steel Body Stainless Interior.

[Audio] How to choose an Auto Water Pump How to choose an appropriate water pump Home Type Usage Pump (Watt) 2-story or less Simultaneously at 2 spots or less 100 Watt Simultaneously at 2 spots or less with 1 shower heater 150 Watt 3-story or less Simultaneously at 2 spots or less with 1 shower heater 200 Watt 4-story or less Simultaneously at 3 spots or less with 1 shower heater 250 Watt Simultaneously at 3 spots or less with 1 shower heaters 300 Watt Remark: Average waster usage of 8 Liter/minute/tap at the same time..

[Audio] Water Pump Installation There are many water pump installation types depending on the housing type For receiving water from on-ground water tank: Installation can be classified into 4 systems. Example Water level should not exceed 2 M Valve Valve Water Meter Valve Recommend avoiding using water directly from tap water supply Check the valve to prevent back flow Ground Wire.

[Audio] System 1 : Connect water pump directly to tap water supply Water supply from tap water goes into the water pump directly (When water pressure is low): Turn on Valves 1 and 2 Then turn on the water pump. Water supply goes into the house directly without going through water pump (When water pressure is high): Turn off Valves 1 and 2 Then turn off the water pump. Not Popular Valve Valve Incoming tap water supply Water Outlet Check Valve.

[Audio] System 2 : Connect water pump to water tank Tap water goes into water tank for storage then pumped out and into the house by water pump. Tap water goes directly into the house without passing through water tank or water pump. (Bypass) 2-System Installation (When there is a water tank) Valve Valve Valve Water Outlet Incoming tap water supply Check Valve.

[Audio] System 3 : Connect water pump to water tank and tap water supply directly Tap water goes into water tank for storage first then pumped out and into the house by water pump. Tap water goes directly into the house without passing through water tank or water pump. (Bypass) Tap water goes directly into the house with passing through water tank but also gets pumped by water pump. 3-System Installation Valve Valve Valve Water Outlet Incoming tap water supply Valve Check Valve.

[Audio] System 4 : In case water pressure is too weak to go into water tank (Add to System 3) Use water pump to pump water from direct tap water supply into water tank. 4-System Installation Valve Valve Valve Valve Incoming tap Water supply Valve Water Outlet Check Valve.

[Audio] Submersible Pump Features: For special activity for example pumping water during a flood; cleaning a well fish pond swimming pool. Wattage: 250 watt – 1000 watt Pipe size: 1 inch – 3 inches Submersible pumps are available for water and for mud. Some model comes with a float ball to help cut the power when the water level drops below a specific point. Pump range : 6 meters Image for ปั๊มจุ่ม lucky PRO LP-SGS400F 400 watt from DirectToShop.com For Mud Image for ปั๊มจุ่ม fujiwa FAIR-500500 watt from DirectToShop.com For Water.

[Audio] How to recommend submersible pump to customer: Find product feature label on the pump. Product specification How to choose a submersible pump: Higher wattage pumps water faster and more in volume. Continuous use limit : 7 consecutive hours..

[Audio] Centrifugal Pump Features: Suitable for water passage for example pumping water into a facility long-distance water transport agricultural use water fountain Horse Power: 0.5 Hp – 3 Hp Pipe Size : 1 Inch – 3 Inches Usage 0.5 -1 HP : For water fountain / Pumping water up a building not taller than 18 meters Good for continuous use. 2 3 HP : For water fountain / Pumping water up a building not taller than 25 meters / Agricultural use that requires 1000 – 20000 liters of water. 3 HP and above : For long-distance water transport / Agricultural use that requires more than 20000 liters of water..

[Audio] Ground Water Pump Features: For places that do not have tap water supply Pump range : 20 40 meters Pipe size : At least 4 inches Controlled with circuit breaker.

[Audio] Basic Knowledge Wattage of Motor (Watt) 1 HP (Horse Power) = 746 Watt Water Pressure 1 bar = 14.50 psi (Pound per square inch) 1 bar = 10 Meter (Inside the pipe vertically).
