[Audio] Oxygen Concentrators. Oxygen Concentrators.

Scene 1

Scene 2

[Audio] A close-up shot of a large oxygen concentrator in use, showing its control panel with clear indicators, buttons, and oxygen output levels. In the background, a patient is seated using a nasal cannula connected to the machine, with the focus on the larger oxygen concentrator and blurred patient details for privacy. The concentrator should be bulky, with visible wheels for mobility, in a clean clinical setting, well-lit to emphasize the device's size and functionality.
A close-up shot of a large oxygen concentrator in use, showing its control panel with clear indicators, buttons, and oxygen output levels. In the background, a patient is seated using a nasal cannula connected to the machine, with the focus on the larger oxygen concentrator and blurred patient details for privacy. The concentrator should be bulky, with visible wheels for mobility, in a clean clinical setting, well-lit to emphasize the device's size and functionality.
A close-up shot of a large oxygen concentrator in use, showing its control panel with clear indicators, buttons, and oxygen output levels. In the background, a patient is seated using a nasal cannula connected to the machine, with the focus on the larger oxygen concentrator and blurred patient details for privacy. The concentrator should be bulky, with visible wheels for mobility, in a clean clinical setting, well-lit to emphasize the device's size and functionality.
A close-up shot of a large oxygen concentrator in use, showing its control panel with clear indicators, buttons, and oxygen output levels. In the background, a patient is seated using a nasal cannula connected to the machine, with the focus on the larger oxygen concentrator and blurred patient details for privacy. The concentrator should be bulky, with visible wheels for mobility, in a clean clinical setting, well-lit to emphasize the device's size and functionality. What is Oxygen Concentartor An oxygen concentrator is a medical device that delivers concentrated oxygen to patients who have low blood oxygen levels. It’s a safer, more economical alternative to oxygen tanks because it extracts oxygen directly from the surrounding air instead of storing it. These devices are used in hospitals, clinics, and even in-home care settings..

Scene 3

An oxygen concentrator is a medical device that delivers concentrated oxygen to patients who have low blood oxygen levels. It’s a safer, more economical alternative to oxygen tanks because it extracts oxygen directly from the surrounding air instead of storing it. These devices are used in hospitals, clinics, and even in-home care settings.

A close-up shot of a large oxygen concentrator in use, showing its control panel with clear indicators, buttons, and oxygen output levels. In the background, a patient is seated using a nasal cannula connected to the machine, with the focus on the larger oxygen concentrator and blurred patient details for privacy. The concentrator should be bulky, with visible wheels for mobility, in a clean clinical setting, well-lit to emphasize the device's size and functionality.

[Audio] How Does an Oxygen Concentrator Work? So, how does it work? The concentrator takes in air from the room, which is about 21% oxygen and 78% nitrogen. The key process behind this device is Pressure Swing Adsorption (P-S-A--). Inside the concentrator, the air is compressed, and a material called zeolite absorbs the nitrogen, leaving behind concentrated oxygen—usually around 90-95%. This oxygen is then delivered to the patient via a nasal cannula or mask..

Scene 4

So, how does it work? The concentrator takes in air from the room, which is about 21% oxygen and 78% nitrogen. The key process behind this device is Pressure Swing Adsorption (PSA). Inside the concentrator, the air is compressed, and a material called zeolite absorbs the nitrogen, leaving behind concentrated oxygen—usually around 90-95%. This oxygen is then delivered to the patient via a nasal cannula or mask.

o
How an
Oxygen
AIR
ENTERS
souk WAY
SELENOIO VALVE
PURE
Oxygen
VLOW METER
ADJUSTING
Concentrator
COMPRESSOR .
1. Takes air from the room.
2. Compresses the oxygen.
3. Takes out nitrogen from the air.
4. Adjusts the way the air is delivered.
5. Delivers the pwitied air.
EXCHANGER
SURGE TANK
VALVE
PRESSURE
REGULATOR
PROD ucr
TANK
MOLECULAR
SEIVE BEOS

[Audio] Key Components: Air Intake Filter Compressor Zeolite Molecular Sieve Oxygen Outlet".

Scene 5

Key Components: Air Intake Filter Compressor Zeolite Molecular Sieve Oxygen Outlet"

AIR
ZEOLITE
SIEVE
OXYGEN
CONCENTRATOR
o
OXYGEN
OXYGEN
FILTER
CROMPRESSER
COMPRESSER
COMPRESSER
ZEOLITE SIEVE
OXYGEN OUTLET

[Audio] Principle of Operation: Pressure Swing Adsorption "The core of this device is the Pressure Swing Adsorption (P-S-A--) principle. In P-S-A--, compressed air passes through two chambers filled with zeolite. One chamber adsorbs nitrogen, while the other regenerates the zeolite by releasing the captured nitrogen back into the air. This alternating process ensures a continuous supply of concentrated oxygen to the patient.".

Scene 6

Principle of Operation: Pressure Swing Adsorption

"The core of this device is the Pressure Swing Adsorption (PSA) principle. In PSA, compressed air passes through two chambers filled with zeolite. One chamber adsorbs nitrogen, while the other regenerates the zeolite by releasing the captured nitrogen back into the air. This alternating process ensures a continuous supply of concentrated oxygen to the patient."

Filter impurities
Filter
Filte«nesh
Pure high concentration
Compressed air
muffler
NTROGEN
I-mt sir*
Adsorb nitrogen
Molecular
sleve
Controller
Flow meter
Ext-nust silencer
Filter
Pressure regumng Oxygen
tank
Filter oxygen

Scene 7

[Audio] When is an Oxygen Concentrator Used? Oxygen concentrators are used when patients suffer from respiratory conditions that lower blood oxygen levels. Common medical conditions include C-O-P-D-, pneumonia, COVID-19, asthma, and even sleep apnea. They’re especially useful in home-care settings where patients need long-term oxygen therapy.".

Scene 8

Oxygen concentrators are used when patients suffer from respiratory conditions that lower blood oxygen levels. Common medical conditions include COPD, pneumonia, COVID-19, asthma, and even sleep apnea. They’re especially useful in home-care settings where patients need long-term oxygen therapy."

[Audio] Types of Oxygen Concentrators "Now, let’s talk about the two main types of oxygen concentrators: 1.stationary 2.portable. side-by-side comparison image clearly showing the differences between a stationary and a portable oxygen concentrator. The stationary unit is larger and used indoors, while the portable unit is smaller and designed for outdoor use..

Scene 9

"Now, let’s talk about the two main types of oxygen concentrators:

 1.stationary   2.portable.




 side-by-side comparison image clearly showing the differences between a stationary and a portable oxygen concentrator. The stationary unit is larger and used indoors, while the portable unit is smaller and designed for outdoor use.

[Audio] "Stationary Oxygen Concentrators" Stationary oxygen concentrators are larger units designed for home or hospital use. They offer high oxygen flow rates, up to 10 liters per minute, and run on electricity. They’re ideal for patients who are bedridden or don’t need to move around much..

Scene 10

Stationary oxygen concentrators are larger units designed for home or hospital use. They offer high oxygen flow rates, up to 10 liters per minute, and run on electricity. They’re ideal for patients who are bedridden or don’t need to move around much.

[Audio] "Portable Oxygen Concentrators" Portable oxygen concentrators are lightweight, battery-operated devices designed for patients who need oxygen on the go. While they typically provide lower flow rates, they allow patients more mobility and independence.“ Portable Pros: Lightweight, Battery-powered Stationary Pros: Higher flow rates, Continuous supply".

Scene 11

Portable oxygen concentrators are lightweight, battery-operated devices designed for patients who need oxygen on the go. While they typically provide lower flow rates, they allow patients more mobility and independence.“

Portable Pros: Lightweight, Battery-powered Stationary Pros: Higher flow rates, Continuous supply"

[Audio] Troubleshooting for Biomedical Engineers "Now, for the biomedical engineers out there, let’s talk about troubleshooting common issues with oxygen concentrators. Here are the most frequent problems you’ll encounter and how to solve them.“ 1.Low Oxygen Purity 2.No Oxygen Flow 3.Power issues or Alarms.

Scene 12

"Now, for the biomedical engineers out there, let’s talk about troubleshooting common issues with oxygen concentrators. Here are the most frequent problems you’ll encounter and how to solve them.“                           1.Low Oxygen Purity                        2.No Oxygen Flow                        3.Power issues or Alarms

[Audio] 1.Low Oxygen Purity 1.Low Oxygen Purity If the oxygen purity drops below 90%, the machine might have a problem with the filters, zeolite sieve, or compressor. Solution: Start by cleaning or replacing the filters. If that doesn’t work, check the zeolite sieve beds and replace them if necessary.“.

Scene 13

1.Low Oxygen Purity If the oxygen purity drops below 90%, the machine might have a problem with the filters, zeolite sieve, or compressor. Solution:  Start by cleaning or replacing the filters. If that doesn’t work, check the zeolite sieve beds and replace them if necessary.“

[Audio] 2.No Oxygen Flow 2.No Oxygen Flow If there’s no oxygen flow, it could be due to blockages in the tubing or a problem with the flow meter Solution: Inspect the tubing for kinks or leaks and ensure the flow meter is set correctly.“.

Scene 14

2.No Oxygen Flow  If there’s no oxygen flow, it could be due to blockages in the tubing or a problem with the flow meter Solution:  Inspect the tubing for kinks or leaks and ensure the flow meter is set correctly.“

[Audio] 3.Power Issues or Alarms" "Issue: If the device won’t power on or is showing alarms, it could be a power supply issue or an internal fault.
Solution: First, check the power source and connections. If the alarm persists, refer to the error code and manual for guidance.".

Scene 15

"Issue: If the device won’t power on or is showing alarms, it could be a power supply issue or an internal fault.
Solution: First, check the power source and connections. If the alarm persists, refer to the error code and manual for guidance."

[Audio] Stay Tuned for More "And that’s a comprehensive overview of oxygen concentrators, their workings, and how to troubleshoot common issues. As a biomedical engineer, your role in maintaining these life-saving devices is crucial. Thanks for watching! Be sure to like, subscribe, and hit the bell for more insightful videos here on Biomedical Diaries!".

Scene 16

"And that’s a comprehensive overview of oxygen concentrators, their workings, and how to troubleshoot common issues. As a biomedical engineer, your role in maintaining these life-saving devices is crucial. Thanks for watching! Be sure to like, subscribe, and hit the bell for more insightful videos here on Biomedical Diaries!"

[Audio] Subscribe for More Biomedical Engineering content.

Scene 17

Subscribe for More Biomedical Engineering content

Oxygen Concentrators

avatar

A close-up shot of a large oxygen concentrator in use, showing its control panel with clear indicators, buttons, and oxygen output levels. In the background, a patient is seated using a nasal cannula connected to the machine, with the focus on the larger oxygen concentrator and blurred patient details for privacy. The concentrator should be bulky, with visible wheels for mobility, in a clean clinical setting, well-lit to emphasize the device's size and functionality.
A close-up shot of a large oxygen concentrator in use, showing its control panel with clear indicators, buttons, and oxygen output levels. In the background, a patient is seated using a nasal cannula connected to the machine, with the focus on the larger oxygen concentrator and blurred patient details for privacy. The concentrator should be bulky, with visible wheels for mobility, in a clean clinical setting, well-lit to emphasize the device's size and functionality.
A close-up shot of a large oxygen concentrator in use, showing its control panel with clear indicators, buttons, and oxygen output levels. In the background, a patient is seated using a nasal cannula connected to the machine, with the focus on the larger oxygen concentrator and blurred patient details for privacy. The concentrator should be bulky, with visible wheels for mobility, in a clean clinical setting, well-lit to emphasize the device's size and functionality.
A close-up shot of a large oxygen concentrator in use, showing its control panel with clear indicators, buttons, and oxygen output levels. In the background, a patient is seated using a nasal cannula connected to the machine, with the focus on the larger oxygen concentrator and blurred patient details for privacy. The concentrator should be bulky, with visible wheels for mobility, in a clean clinical setting, well-lit to emphasize the device's size and functionality.
 What is Oxygen Concentartor
 An oxygen concentrator is a medical device that delivers concentrated oxygen to patients who have low blood oxygen levels. It’s a safer, more economical alternative to oxygen tanks because it extracts oxygen directly from the surrounding air instead of storing it. These devices are used in hospitals, clinics, and even in-home care settings.

How Does an Oxygen Concentrator Work?
 So, how does it work? The concentrator takes in air from the room, which is about 21% oxygen and 78% nitrogen. The key process behind this device is Pressure Swing Adsorption (P-S-A--). Inside the concentrator, the air is compressed, and a material called zeolite absorbs the nitrogen, leaving behind concentrated oxygen—usually around 90-95%. This oxygen is then delivered to the patient via a nasal cannula or mask.

Principle of Operation: Pressure Swing Adsorption
 "The core of this device is the Pressure Swing Adsorption (P-S-A--) principle. In P-S-A--, compressed air passes through two chambers filled with zeolite. One chamber adsorbs nitrogen, while the other regenerates the zeolite by releasing the captured nitrogen back into the air. This alternating process ensures a continuous supply of concentrated oxygen to the patient."

When is an Oxygen Concentrator Used?
 Oxygen concentrators are used when patients suffer from respiratory conditions that lower blood oxygen levels. Common medical conditions include C-O-P-D-, pneumonia, COVID-19, asthma, and even sleep apnea. They’re especially useful in home-care settings where patients need long-term oxygen therapy."

Types of Oxygen Concentrators
 "Now, let’s talk about the two main types of oxygen concentrators:

 1.stationary   2.portable.




 side-by-side comparison image clearly showing the differences between a stationary and a portable oxygen concentrator. The stationary unit is larger and used indoors, while the portable unit is smaller and designed for outdoor use.

"Stationary Oxygen Concentrators"
 Stationary oxygen concentrators are larger units designed for home or hospital use. They offer high oxygen flow rates, up to 10 liters per minute, and run on electricity. They’re ideal for patients who are bedridden or don’t need to move around much.

"Portable Oxygen Concentrators"


 Portable oxygen concentrators are lightweight, battery-operated devices designed for patients who need oxygen on the go. While they typically provide lower flow rates, they allow patients more mobility and independence.“


 Portable Pros: Lightweight, Battery-powered Stationary Pros: Higher flow rates, Continuous supply"

Troubleshooting for Biomedical Engineers
 "Now, for the biomedical engineers out there, let’s talk about troubleshooting common issues with oxygen concentrators. Here are the most frequent problems you’ll encounter and how to solve them.“                           1.Low Oxygen Purity                        2.No Oxygen Flow                        3.Power issues or Alarms

1.Low Oxygen Purity
 1.Low Oxygen Purity If the oxygen purity drops below 90%, the machine might have a problem with the filters, zeolite sieve, or compressor. Solution:  Start by cleaning or replacing the filters. If that doesn’t work, check the zeolite sieve beds and replace them if necessary.“

2.No Oxygen Flow

 2.No Oxygen Flow  If there’s no oxygen flow, it could be due to blockages in the tubing or a problem with the flow meter Solution:  Inspect the tubing for kinks or leaks and ensure the flow meter is set correctly.“

3.Power Issues or Alarms"
 "Issue: If the device won’t power on or is showing alarms, it could be a power supply issue or an internal fault.
Solution: First, check the power source and connections. If the alarm persists, refer to the error code and manual for guidance."

Stay Tuned for More
 "And that’s a comprehensive overview of oxygen concentrators, their workings, and how to troubleshoot common issues. As a biomedical engineer, your role in maintaining these life-saving devices is crucial. Thanks for watching! Be sure to like, subscribe, and hit the bell for more insightful videos here on Biomedical Diaries!"
