Office and Warehouse Blueprint Presentation BCOM 102 Michael W. Shafer Jr Sheet Number: A-16/Door Schedule and Details
Scene 1 (0s)
Draft drawing of a floor plan. Office and Warehouse Blueprint Presentation BCOM 102 Michael W. Shafer Jr Sheet Number: A-16/Door Schedule and Details.
Scene 2 (32s)
Diagram, engineering drawing Description automatically generated.
Scene 3 (51s)
Door Schedule & Details:. Shell Building Door Schedule subsections: Main Headers; Door and Frame Subsections Door: Size, Type, Thickness, Material, Finish Subsection Frame: Type, Material, Finish, Detail Fire Rating, Hardware, and remarks other sections.
Scene 4 (1m 25s)
Door schedule notes On sheet A-16 Door Notes are listed numerically and serve as general checklist before, during and after door installs Reference for Project Manager, Contractors, etc.
Scene 5 (2m 2s)
Hardware Schedule. Applied to Doors included in Shell Door Schedule Multiple hardware notes may apply to numbered door in Shell Schedule.
Scene 6 (2m 26s)
FRAME AND ELEVATION TYPES. . Diagram, engineering drawing Description automatically generated.
Scene 7 (3m 2s)
SHELL BUILDING DOOR SCHEDULE & DETAILS. REFERENCES:.
