Scene 1 (0s)

[Audio] This is the last topic 3S sticker check For the frequency to check One time per month Risk The operator may pinch on his finger by moving part because he didn't confirm the moving part was stopped completely We should Confirm all step of 3S was attached & indicated at the right position How to check Check 3S sticker still good condition & indicated at the right position If you take a look at example red one is no good Because Don't have some sticker Like S1 S2 S3, And also Attached sticker at wrong position Blue one was good because Have all 3S sticker and put at the right position.

Scene 2 (1m 5s)

3. 3S sticker check. Point and speak out “ S witch off - OK”.

Scene 3 (1m 11s)

[Audio] …...

Scene 4 (1m 16s)

[Audio] Next Swing cover type For the frequency to check One time per week Risk The operator may get cut on his body by put body part into danger zone because it wasn't install safety cover to separate between safe zone & danger zone We should Checking that Swing safety cover can working normally. How to check In this device we have two method for check the safety device Method number one Open the swing cover during operation and check an emergency stop occurs If you take a look at example red one is no good Because Machine can't stop by open the cover Blue one was good because machine was stop by open the cover.

Scene 5 (2m 20s)

[Audio] We are still in, Swing cover type In case it is difficult to conduct Method number one Please check by method number two With the swing cover detected by the proximity switch try to turn on Master on after that check machine does not start If you take a look at example red one is no good Because Machine is ready to start after press Master on Blue one was good because Machine can't start until cover was closed.

Scene 6 (2m 59s)

[Audio] Next Photoelectric safety device For the frequency to check Please follow the table Risk The operator may get pinch in his finger by put finger into danger zone because it wasn't install Photoelectric to separate between safe zone & danger zone. We should Checking that Swing safety cover can working normally. How to check In this device we have two method for check the safety device Method number one Turn on master on and Obstruct the light during operation after that check an emergency stop occurs If you take a look at example red one is no good Because Machine can't stop by obstructed the light Blue one was good because machine was stop by obstructed the light.

Scene 7 (4m 7s)

3. 3S sticker check. Point and speak out “ S witch off - OK”.
