Scene 1

[Audio] Static electricity refers to charge that is not moving i.e., stationary charge.
An insulator can be charged electrically, by rubbing it while a conductor cannot..

Scene 2

Static electricity refers to charge that is not moving i.e., stationary charge An insulator can be charged electrically by rubbing it while a conductor cannot

A close-up of a glass slide

Description automatically generated

A pink balloon and yellow hair

Description automatically generated

This Photo by Unknown author is licensed under CC BY.

This Photo by Unknown author is licensed under CC BY-SA.

[Audio] There are two types of charge: (a). Positive charge + (b). Negative charge -
The SI unit of charge is the Coulomb, denoted by C.
Negative charge is acquired if electrons are gained, and positive charge is acquired if electrons are lost.
All charges obey The Law of Electrostatic Charge, which states that, "like charges repel and unlike charges attract."
Electric charges can exist independent of each other..

Scene 3

A group of red circles with black arrows

Description automatically generated

There are two types of charge. (a). Positive charge +                                                           (b). Negative charge - The SI unit of charge is the Coulomb Negative charge is acquired if electrons are gained, and positive charge is gained if electrons are lost All charges obey The Law of Electric Charges which states that “like charges repel and unlike charges attract.” Electric charges can exist independent of each other

[Audio] Positively charged rod is brought near a neutral metal sphere, separating the charges.
The sphere is then connected to the ground. Negative charges flow from the ground to neutralize positive charges.
When the sphere is disconnected from the ground and the charged rod is removed simultaneously, the sphere is left with negative charge..

Scene 4

1. Separation of charge
(a)
3. Sphere is disconnected
from ground.
(c)
(b)
(d)
2. Sphere is connected
to ground.
Ground
4. Sphere has an
induced charge.

[Audio] Touching the sphere with a positively charged glass rod, allows for the passage of negative charges in to the rod, leaving the sphere positively charged.
Electrons flow from the piece of cloth into the polythene rod.
Electrons flow out of the acetate rod into the cloth which then becomes negatively charged..

Scene 5

When a polythene rod is rubbed with a cloth it becomes negatively charged. Electrons flow from the piece of cloth into the polythene rod. Electrons flow out of the acetate rod into the cloth which then becomes negatively charged

Positively charged
glass rod
Neutral conducting
sphere with charge
distribution

A diagram of a hand holding a string

Description automatically generated

[Audio] This is a demonstration on charging of the spheres by separation of charges..

Scene 6

Charging through induction can be achieved in two ways: by earthing and separation of charges

[Audio] This is to demonstrate how to charge two spheres by separation of charges..

Scene 7

[Audio] Demonstration on charging earthing or grounding..

Scene 8

A charged strip is brought close to a neutrally charged metal sphere This causes a separation of charge within the sphere itself Earthing the sphere causes the negative charge to be repelled by the strip to the ground

1. Separation of charge
3. Sphere is disconnected
from ground.
(a)
(c)
(b)
(d)
2. Sphere is connected
to ground.
Ground
4. Sphere has an
induced charge.

[Audio] Gold leaf electroscope used to detect charge..

Scene 9

Charge can be detected using a Gold Leaf Electroscope When a charged object is brought close to the metal cap, the gold leaf deflects upwards To find out the nature of the charge on the object, the electroscope must be charged first, i.e., only a charged electroscope can be used to detect the type of charge in an object

A hand holding a glass jar

Description automatically generated

Diagram of a diagram showing the reaction of a charge

Description automatically generated

This Photo by Unknown author is licensed under CC BY-NC-ND.

This Photo by Unknown author is licensed under CC BY-SA-NC.

[Audio] Charged and discharged Gold leaf electroscope..

Scene 10

Discharging refers to the loss of excess charge It takes place through contact or ionization Dangers of ionization are minimized by earthing

A diagram of electroscopes

Description automatically generated

[Audio] When excess charge has accumulated in the cloud it is discharged to the ground through ionization.
A lightning conductor discharges a cloud before it discharges on its own.
The lightning conductor should be made from a good conductor of electricity, and it should be taller than the structure it is protecting..

Scene 11

[image] A lightning striking a tower Description automatically generated

[image] A diagram of a house with wires Description automatically generated

When excess charge has accumulated in the cloud it is discharged to the ground through ionization A lightning conductor discharges a cloud before it discharges on its own The lightning conductor should be made from a good conductor of electricity, and it should be taller than the structure it is protecting

[Audio] The electric field is a region around a charged particle, where its electric force is felt.
Electric fields are illustrated with the help of electric field lines which begin at the positive charge and end at the negative charge
The diagrams demonstrate the field around single charges..

Scene 12

The electric field is a region around a charged particle, where its electric force is felt. Electric fields are illustrated with the help of electric field lines which begin at the positive charge and end at the negative charge. Field around single charges.

A circular object with arrows around it

Description automatically generated

A close-up of arrows

Description automatically generated

[Audio] Field around two like charges.. The point E= 0, is a neutral point..

Scene 13

A diagram of a mathematical equation

Description automatically generated

[Audio] Field around two unlike charges.. Field between 2 unlike charges.

Scene 14

ELECTROSTATICS

Scene 0

Static electricity refers to charge that is not moving in other words, stationary charge.

An insulator can be charged electrically, by rubbing it while a conductor cannot.

avatar

 This Photo by Unknown author is licensed under CC BY.

slide2-hotlink5

 This Photo by Unknown author is licensed under CC BY-SA.

slide2-hotlink8

There are two types of charge:   (a). Positive charge +

The SI unit of charge is the Coulomb, denoted by C Negative charge is acquired if electrons are gained, and positive charge is acquired if electrons are lost.

All charges obey The Law of Electrostatic Charge, which states that, "like charges repel and unlike charges attract."

Electric charges can exist independent of each other.

slide3-hotlink6

Positively charged rod is brought near a neutral metal sphere, separating the charges.

The sphere is then connected to the ground

Negative charges flow from the ground to neutralize positive charges.

When the sphere is disconnected from the ground and the charged rod is removed simultaneously, the sphere is left with negative charge.

slide4-hotlink5

Touching the sphere with a positively charged glass rod, allows for the passage of negative charges in to the rod, leaving the sphere positively charged.

Electrons flow from the piece of cloth into the polythene rod.

Electrons flow out of the acetate rod into the cloth which then becomes negatively charged.

slide5-hotlink14

slide5-hotlink17

This is a demonstration on charging of the spheres by separation of charges.

slide6-hotlink11

This is to demonstrate how to charge two spheres by separation of charges.

slide7-hotlink5

Demonstration on charging earthing or grounding.

slide8-hotlink5

Gold leaf electroscope used to detect charge.

 This Photo by Unknown author is licensed under CC BY-NC-ND.

slide9-hotlink5

 This Photo by Unknown author is licensed under CC BY-SA-NC.

slide9-hotlink8

Charged and discharged Gold leaf electroscope.

slide10-hotlink5

When excess charge has accumulated in the cloud it is discharged to the ground through ionization.

A lightning conductor discharges a cloud before it discharges on its own.

The lightning conductor should be made from a good conductor of electricity, and it should be taller than the structure it is protecting.

slide11-hotlink5

slide11-hotlink8

The electric field is a region around a charged particle, where its electric force is felt.

Electric fields are illustrated with the help of electric field lines which begin at the positive charge and end at the negative charge
