Scene 1 (0s)

[Audio] Today we are going to present a presentation on topic jmrc and automatic train supervision(ats).

Scene 2 (9s)

[Audio] here is a preview of metro at night time.

Scene 3 (17s)

[Audio] Vision : TO be the leading infrastructure develop of choice Mission : Efficient ,Rapid and innovative development of quality infrastructure to create Infra wealth for the nation...

Scene 4 (32s)

[Audio] JMRC- Jaipur Metro Rail Corporation The Jaipur Metro Rail Corporation Ltd., abbreviated to JMRC, is a state-owned company that operates the Jaipur Metro. The Jaipur Metro Rail Corporation Ltd. was created on 1 January 2010 BY MR AJAY GHOSH serving as the MANAGING DIRECTOR...

Scene 5 (56s)

[Audio] Overview of Jaipur Metro track over the city.

Scene 6 (1m 3s)

[Audio] Here is the route map of jaipur metro.

Scene 7 (1m 10s)

[Audio] Phase 1 A on 3 june 2015 from mansarovar to chandpol with length of 9.63 km and total station 9 Phase 1 -b 2020 from chandpol to badi chaupar with length of 2.34 km and total station 2 So total no. of station in both phases are 11.

Scene 8 (1m 34s)

[Audio] The Pink Line of the Jaipur Metro is part of the rapid transit system in the city of Jaipur, India. It is also called East-West Corridor of Jaipur. It consists of 11 metro stations from Mansarovar in the West to Badi Chaupar in the East. The line with a length of 11.97 kilometers (7.44 mi) is mostly elevated and partially underground and has been laid to connect the oldest part of Jaipur to rest of it. This is the Metro line that got flagged off on 3 June 2015, and has been named as Pink Line, as the line passes through the Pink City. The Pink line has planned interchange with the Orange Line of the Jaipur Metro. it also connects Mansarovar, the Largest Colony of Asia with the Jaipur Junction railway station of the Indian Railways, Sindhi Camp Bus Stand, Heritage Sites like Hawa Mahal, Town Hall, Jantar Mantar, City Palace etc..

Scene 9 (2m 35s)

[Audio] Jaipur metro pink line at chandpol station and a exterior view of railway station halt on pinl line.

Scene 10 (2m 44s)

[Audio] So the pink line metro station are in order Mansarovar - New Aatish Market - Vivek Vihar - Shyam Nagar - Ram Nagar - Civil Lines - Railway Station - Sindhi Camp - Chand Pole - Choti Chaupar - Badi Chaupar Some of them are elevated and some of them are underground.

Scene 11 (3m 7s)

[Audio] Trains operate at a frequency of10to 15 minutes between 6:45 and 21:00 depending peak and off peak time. Trains operating within the network typically travel at speed up to 40 km/h (25 mph) and stop for about 20-40 seconds at each qation. Automated station announcements are recorded in Hindi and English...

Scene 12 (3m 32s)

[Audio] Under Phase-I B, the Pink Line was extended further East from Chandpole station by 2.349 km. Two additional stations got built to extend the line to Badi Chaupar. The stations on this extension are: 1) Chhoti Chaupar 2) Badi Chaupar. The construction of the extension was delayed following the discovery of an ancient stepwell..

Scene 13 (4m 0s)

[Audio] For Phase 1C, Jaipur Metro Rail Corporation (JMRC) plans to extend the Pink Line from Badi Chaupar to Transport Nagar. For the same, the corporation has prepared a detailed project report (DPR) of Phase 1C by taking public suggestions. According to the DPR, the estimated project cost will be Rs 856 crore, including cost of land and taxes, The total length of the project will be 2.85km (2.26km Underground and 0.59km Elevated). This project is expected to be completed till March 2025 if the construction takes place. Once constructed, the estimated ridership between the entire stretch, Mansarovar to Transport Nagar, will be over 1.38 lakh till 2031. The stations on this extension are: 1) Badi Chaupar 2) Ramganj Chaupar 3) Transport Nagar..

Scene 14 (5m 7s)

[Audio] Signalling and telecommunications The Jaipur Metro uses cabsignalling along with a centralised automatic train control system consisting of Automatic Train Protection and automatic train signalling modules. Jaipur metro has proposed that it will have automatic train operation in future.a 380 mhz digital tera radio communication system is used on all line to carry both voice and data infornation. An integrated system comprising optical fibre cable, on train radio,cctv and a centralised clock and public address system.

Scene 15 (5m 42s)

[Audio] Exterior view of track and cab in jaipur metro office at mansarovar.

Scene 16 (5m 53s)

[Audio] Organization Sanctioned Hierarchy. Executive Director General Manager Dy. General Manager Manager (Tele & AFC) Manager (Signal) Junior Engineer (Electronics) 12 nos. Junior Engineer (Electronics) 09 nos. Maintainer (Electronics) 21 nos. Maintainer (Fitter, Electronics,) 25 nos. JGM.

Scene 17 (6m 8s)

[Audio] GENERAL SYSTEM OVERVIEW OF SIGNALLING. LATS subsystem ASCV Sub System ATC Trackside subsystem Track/Train interfaces ATC Train borne subsystem Trackside overview..

Scene 18 (6m 30s)

[Audio] Overview of signalling It includes Radio System Passenger Information Other Systems (i.e. Clock) NP-SCADA Signalling Train Interface.

Scene 19 (6m 50s)

[Audio] ICONIS-ATS CONTEXT ATS Automatic Train Supervision ICC Integrated Control center IXL Interlocking ATC Automatic Train Control.

Scene 20 (7m 8s)

[Audio] Signalling Rules (SIG). Function: Equipment state monitoring: Track Circuit Switch Point Signal Route and Sub-route .... Command management Command validity management Address "Technical topology" Configured by "data preparation"..

Scene 21 (7m 33s)

[Audio] Signalling Rules (SIG). Allows animation of signalling mimic to monitor and control : signals, points, routes, cycles, track circuits, etc. Must interface different IXL technologies Smartlock (=ASCV) (Apparato di Stazione con Calculatore Vitale) Offer a common interface with other ATS functionalities..

Scene 22 (8m 1s)

[Audio] Territory Assignment (TAS). Operator expectations Co-ordinate the use of field signalling resources by multiple entities and preclude conflicts control assignment of track sectors to operators and consoles Maintain audit trace of all transfers..

Scene 23 (8m 18s)

[Audio] Where are the ATS ?. Three types: Central Local Depot..

Scene 24 (8m 30s)

[Audio] This slides tells us about the functionalities availabe at all three ats central,local, and depot.

Scene 25 (8m 38s)

[Audio] LOCAL ATS. MANSAROVAR METRO STATION METRO RAILWAY STATION BADI CHAUPAD METRO STATION. CENTRAL ATS MANSAROVAR METRO office It have a operation control centre for checking the functioning in short occ.

Scene 26 (9m 3s)

[Audio] Working of central ats The central ats is at mansoravar metro office and all the data and information that comes from the local ats are stored here and according to the need the actions are taken place in the occ.

Scene 27 (9m 18s)

[Audio] Working of local ats The jmrc have three local ats MANSAROVAR METRO STATION METRO RAILWAY STATION BADI CHAUPAD METRO STATION. All these local ats have a particular area and all these local ats send data to the central ats and can be controlled from the occ.

Scene 28 (9m 46s)

[Audio] Working of depot ats. Depot.

Scene 29 (9m 52s)

[Audio] Logical arcitecture including the central and the local ats with the automatic train control and and different interlocking.

Scene 30 (10m 1s)

[Audio] The central ats software is the most important part of the ats It includes different workstations from which it sends and receive the important data and builds the server for proper functioning..

Scene 31 (10m 15s)

[Audio] Signalling failures are divided into following categories : ATP ATS Point Signal Track Circuit IXL Miscellaneous.

Scene 32 (10m 35s)

[Audio] The failure chart is as follows.. Sales ATP/ATO ATS POINT SIGNAL TC IXL Misc. 820 222 25 45 61 11 46.

Scene 33 (10m 44s)

[Audio] Generic Principles. Redundancy Open architecture (COTS) Value Timestamp Quality (VTQ) data Login management Configuration Reliability, Availability, Maintenability, Safety..

Scene 34 (11m 7s)

[Audio] ATS work station monitoring consists of a cyclic of 3 colours as follows The animated link shown above allows operator for checking whether the ATS Machine is active or frozen. The operator will know the activeness of the ATS Work Station when the colour changes continuously from RED to Green to Blue and again to RED and follows the cycle as shown in the above figure. The colour changes at the rate of 0.5s. If the ATS Machine is frozen then the ATS Machine will not have any communication with the application server...

Scene 35 (11m 42s)

[Audio] In addition to the project logo and date & time already displayed on the Initialization layout, in the operational layout, the project master plan in the mimic area will be replaced by Various View Associated with buttons provided in the bottom banner.

Scene 36 (11m 57s)

[Audio] Here is the previw of the operation layout on the screen.

Scene 37 (12m 3s)

[Audio] The 3 aspects signals with route indicator graphical aspects shall behave as follow: Red Signal at red Violet Signal at Violet Green Signal at green Black Not updated.

Scene 38 (12m 21s)

[Audio] Train Describer (TDS). Functions : Detection of train movements and stops Tracking of train location Train kilometres follow-up Identifier assignment to a train Train description information for the operator..

Scene 39 (12m 38s)

[Audio] Train identity is a function, which covers several information relative to a train. This information is grouped together and accessible through the berth symbol, which is representing a train through its train id. They have been split in homogeneous sets of data such as: Train id State (Crew id, rake id, train state) Rolling stock information (RIN, RS status, train doors status) Manual regulation (skip stop, keep door closed) ATC information (on board ATC status, train ready, driving mode) Monitoring & controlling information related to train identity is presented below To open the "Train identity" dialog box the operator shall left click on the berth..

Scene 40 (13m 33s)

[Audio] Emergency Stop Plungers : They display emergency stop plunger states. One symbol by platform shall give a summarized state for platform emergency stop plungers. Background: Light Grey Text: Black Cleared Background: White Text: Red Activated Background: Black Text: White Not updated.

Scene 41 (14m 12s)

[Audio] ATS Control management. The HMI shall provide the operator to perform the handover from CATS. The handover can be negotiated (with ack) or not (emergency request). This section describes the HMI provided in order to manage the handover between two different ATS for a given zone. These zones are defined during data preparation process MANUAL CONTROL BOX..

Scene 42 (14m 42s)

The following control dialog box is displayed on the Workstation which has control(Traffic controller 1). Manual controls handover request controls are being requested from another ATS. Do you accept? From ATS: Territory requested: Operator: Workstation: <ATS name> <Territory name> <Operator name> <Workstation name> Without an answer before <hh:mm:ss> this request will be automatically refused. Figure 40 —Take control request dialog box (Traffic controller 1) After confirmation CATS operator(eg Traffic controller 2) has the control of the area and the indicator becomes green in station banner..

Scene 43 (15m 4s)

Possible from AT S. Sl.No 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 ATS Functions logon Si nalli ui ment man ement SIG Train describer (TDS) Automatic route setting (ARS) Automatic Train (AT R) Dwell time operator controls ATS train hold management: Train hold,'release control & Status Skip-stop station / keep doors closed management : controls Passenger Information Management (PIM) Rolling-stæk management Train Crew man ement ATS Sub-system Supervision (monitoring) Alarms & Events management Time management Operation Mode Management- Manual Operation Mode Management — Constant HW T SR Management Table 21: Operations.

Scene 44 (15m 24s)

[Audio] Route setting Route Setting control symbols shall be located on the mimic area, close to signal number. Two types of symbols to be used for Route setting control: One button for route entrance and other button for route exit. When no route is selected only "Route Entrance" buttons shall be displayed. To perform a route setting control, the operator shall successively click on two buttons. One "Route Entrance button at the origin signal and one Route Exit button at the destination signal. If the operator has not validated a second button (Route Exit button) within the Time out (30 Secs) the storage of the first button shall be cancelled and the next button selected shall be considered as a first button. Route Block Route blocking control symbols shall be located on the mimic area, close to signal numbers. Two types of symbols shall be used for route blocking control, one button for route entrance and one button for route exit..

Scene 45 (16m 30s)

[Audio] Local ats system supervision view. Local ATS system supervision view.

Scene 46 (16m 37s)

THANK YOU.
