INDIA's First Corrosion Resistance Advance Polymer Coated Metal Roofing Sheet

[Audio] INDIA’s First Corrosion Resistance Advance Polymer Coated Metal Roofing Sheet Durotufftm Polyshine® Apc Metal.

[Audio] This Or That Colour Coated Adavance Polymer Coated OR.

[Audio] A-P-C Metal Roofing Sheet has Excellent Corrosion Resistance Chemical Resistance Weatherability Fire Proof Colour Stable *Terms & Conditions Applied as Application and type of Chemicals.

[Audio] What is APC STEEEL? polyshine®APC Steel is pretreated steel coated by Advance Polymer Resin layer on both sides via an unique pressing process at high temperature. polyshine® A-P-C Steel combines both the advantages of steel and resin, is an innovative material for building systems, providing long service life with high resistance to corrosion, climate and mechanical damage. polyshine APC STEEL is pretreated steel coated by Advance Polymer Resin layer on both sides via an unique pressing process at high temperature. polysibne APC STEEL combines both the advantages of steel and resin, is an innovative material for building systems, providing long service life with high resistance to corrosion, climate and mechanical damage..

[Audio] Product Structure & Coating Layers The result of this particular combination is a roofing or wall steel sheet, which can be applied in any environmental circumstances, without fear of chemical vapors, be it industrial or agricultural, or the most destructive of saline fog! marinshield Weather Resistance Advance Polymer Layer 0.18MM Pretreated Steel Sheet 0.45MM CHEMISHIELD Modified Anti-climate Advance Polymer Layer 0.18MM.

[Audio] Layer Material Thickness Application Colour Surface marinshield® Weather Resistance Advance Polymer 180 µ Exterior Raspberry Red 3027 Mohogany Brown 8016 Moss Green 6005 Light Blue 5012 Gray White 9002 Graphite Grey 7024 Terracotta Orange 2001 CHEMISHIELD® Modified Anti-Climate Advance Polymer 180 µ Interior Blue White Base GI Galvinium Aluminum 0.45 millimeters To 0.60 millimeters Substrate Natural.

[Audio] Technical Data Sheet No. Test Elements test result 1 Thermal Conductivity 0.015-0.029W/m.k 2 Coefficient of Expansion (1.6-1.8)х10﹣5 millimeters/mm/℃ 3 Color E=（△E1 plus △E2)/2 △E≤1.5 4 Gloss G=G1 plus G2 plus G3/3 5 Adhesiveness ≥B3 Grade 6 9N Lasting Adhesiveness ≥100H 7 Freeze-thaw Resistance Test No hollowing, bubble, peeling or crack on sample surface 8 Low-temperature Hammer Drop Test No peeling or crack on sample surface 9 Temperature Resistance No peeling or crack on sample surface 10 Bending Properties No peeling or crack on sample surface 11 Corrosion Resistance 1000 hours, No rusting 12 Flame Resistance A Grade 13 Cold Workability No peeling or crack on sample surface 14 Stain Resistance Oil Marking Pen Black No fading, swelling or separation Blue Red Kerosene No fading, swelling or separation 15 Chemical Stability 10%(Mass Fraction）HCL No fading, swelling or separation 10%(Mass Fraction）Ga(O-H---)2 10%(Mass Fraction）NaOH 10%(Mass Fraction）H2SO4 16 Chemical Resistance Properties 20%(Mass Fraction）H2SO4 168 hours, No fading, swelling or separation 15%(Mass Fraction）HCL 20%(Mass Fraction）H3PO4 5%(Mass Fraction）NaOH 20%(Mass Fraction）HF 20%(Mass Fraction）HNO3 Ammonia Chlorine.

[Audio] Applications polyshine A-P-C Steel is well applied in Corrosive industries Salty coastal areas Serving chemical factory Electrolytic/electroplating plant Metallurgic plant Fastener manufacturing units Galvanizing and metal Treatments industries Fertilizer storage Mining area Power station Printing and dyeing plant Waste plant Leather workshop Food and drug workshop Agricultural and breeding industries, et cetera.

[Audio] polyshine® A-P-C Steel VS Pre-painted Color steel polyshine® APC STEEL combines the advantages of high resistance resin with strong steel plate, creating a revolutionary coated steel with much HIGHer corrosion resistance than traditional colour coated steels. It shows that there are many microscope on surface of color coated steel (caused by volatilization). Corrosive will penetrate easily to substrate, which will reduce lifespan of the product. While the surface of polyshine A-P-C Steel is very intact. Colour Coated Polyshine® Apc Steel After soaked in 20% sulfuric acid for 22 hours Anti-corrosive polyshine A-P-C Steel has no change on surface, while the coating color coated steel was seriously corroded and peeled off. Anti-corrosive polyshine A-P-C Steel is definitely a Revolutionary product, Much More Durable than Repainted Color Steel! Colour Coated Polyshine® Apc Steel.

[Audio] Overall comparison of different roofing materials Properties F-R-P Sheet PPGI/PPGL Stainless Steel Aluminium A-C-P Steel Density (g/cm3) 1.50 7.85 7.90 2.70 4.59 Thermal Conductivity W/mK 0.18 6.60 15.00201.00 0.601 Liner Expansion (mm/mtr/˚C) 2.6 X10-5 1.25 X 10-5 1.10 X 10-5 2.35 X 10-5 1.25 X 10-5 Yield Strength (Mpa) 360 to 550320 to 340 45360 to 550 Tensile Strength (Mpa) 100400 to 520 620 to 670120400 to 520 Elongation (%) 1.9 20 to 30 48 27 20 to 30 Anti Fire (Class) B A A A A Workable N Y Y Y Y Life time –Normal (Year) 10 -15 20 80 – 100 50 30 Life Time –Severe (Year) 10 10 20 – 30 20 20 Nominal Thickness (mm) 2.0 0.40 to 0.70 0.40 to 0.50 0.70 0.50 to 0.80.

[Audio] Improve the service life of the Metal Sheet The service life of the metal tile in the factory the coastal area is short, the chemical corrosion and the Stalinization are realty affected, and the Advance Polymer Coating is increased to at least 10-15 years. Colour Coated Polyshine Apc Environmental protection A large number of pollutants are produced in the process of painting production by colour steel Sheet, and there is no waste gas and wastewater in the coating process of color steel tiles, which is completely environmental protection. The product is also a pollution-free environmental protection product. Colour Coated Polyshine Apc Every spraying repair in the application of colour coated steel sheet pollutes the environment seriously marinshield Weather Resistance Advance Polymer layer has the effect of anti-static and self cleaning like lotus leaf, and keeps bright for a long time..

[Audio] Features Corrosion resistance is the main advantage of polyshine A-P-C Steel Compared with P-P-G-I or P-P-G-L products. polyshine A-P-C Steel is well Protected by marinshield Advance engineering Polymer resin Layer from outside corrosions and damage. And CHEMISHIELD Advance Polymer resin layer from inside (bottom side) Corrosion and damage. Corrosion Resistance We did comparative test at Power Chem Plast Ltd Laboratory after 96Hrs. AFTER 96 Hours Solution Performances in 96 hrs. polyshine APC STEEL COLOUR coated STEED 10 % H-2-O-2 (Hydrogen Peroxide) No change Paint peeled off after 65hrs 20 % H-3-P-O-4 (Phosphoric Acid) No change Fell after 41hrs Disappeared after 63hrs 20 % NaOH (Sodium Hydroxide) No change Paint peeled off after 15hrs 20 % H-2-S-O-4 (Sulfuric Acid) No change Fell after 18hrs Disappeared after 52hrs 20 % H-C-L (Hydrochloric Acid) No change Fell after 15hrs Disappeared after 58hrs 20 % NH3H2O (Ammonium Hydroxide) No change No Change 10% NaClO (Sodium Hypochlorite) Slight Red Rust appeared after 70 Hrs Heavy Red Rust appeared after 67 Hrs This test approves that polyshine® A-P-C steel is suitable for most of the corrosive environments and has much better performance than color coated steel in these applications..

[Audio] Photographs of In-house test With Common Chemicals which are Most used.

[Audio] Heat Insulation Comparison Under the same condition the thermal conductivity of polyshine A-P-C Steel is 0.601 (w/m.k) and Colour coated PPGI/PPGL is 6.598 (w/m.k). polyshine A-P-C Steel is one tenth of PPGI / P-P-G-L . Corrosion-prone Area PEB Metal Building in most corrosion-prone Area like Chemical Zone, Costal Area, Salty costal area, industries like Chemical, Metal Processing, Smelting, Sugar, Salt et cetera Build with Colour Coated Steel Sheet.

[Audio] Build with polyshine® A-P-C Steel Sheet Standard Colors Raspberry Red 3027 Mohogany Brown 8016 Moss Green 6005 Light Blue 5012 Gray White 9002 Graphite Grey 7024 Terracotta Orange 200.

[Audio] Key Features of polyshine® APC STEEL Corrosion Resistance A-P-C Metal Sheets is Coates With Advance Polymer on Top and Bottom,it is Stable when exposed to chemical agents such as industrial emission,fog, salt, acids, alkali et cetera Colour Stable The Advance polymer on Top Surface is excellent UV resistant material, Anti-aging and make colour stable. Fire Proof Difficult to burn, the fire proof level can reach Grade A and meet the common safety requirements is most areas. Cooling Effect With the infrared ray reflection technology on the surface Advance Polymer layer, it can reflect over 30% of infrared ray Electricity Isolation The Advance Polymer on top and bottom surface protect the product from electricity conduction, make the house safe in thunderstorm weather. Excellent mechanical Properties A-P-C Metal Sheets has the same mechanical property with the Galvanized and Aluminum sheet.. Environmental Friendly The Advance Polymer material and Steel are 100% recyclable and no Harm to the environment. Excellent impact resistance and load Bearing Performance. High-quality raw materials for roof construction of commercial and industrial buildings. Customized Shape Customer can buy the Roll and make his own shape; this brings more options to customer. Light Weight and esay installation it’s light and easy to handle, means faster installation and save time and money..

[Audio] Thank you. Thank you.

[Audio] Our Some Prestigious clients. Our Some Prestigious clients.

[image] Jd Industries India Limited in Riico Industrial Area Bhiwadi Bhiwadi Best Metal Product Manufacturers in Bhiwadi Justdial.

[Audio] power CHEM PLAST LTD. (An ISO 9001:2015 Certified Co.) Factory Address: Hadbast No. 216, Village Kunjhal, P O Barotiwala, Tehsil : Baddi, Dist : Solan (H-P---) 174103 Email : [email protected] Phone: plus 91-172-5086950 Office Address: 2112 ampere, The Corenthum Building, Corporate Office Building, Opp.Electronic City Noida Metro Station, Noida, Sector 62, Pincode – 201301. Phone: plus 91-120-4291459 Email : [email protected], [email protected] Website : www.durotuff.com Website : www.polyshine.in.
