INDIA's First Corrosion Resistance Advance Polymer Coated Metal Roofing Sheet

INDIA’s First Corrosion Resistance Advance Polymer Coated Metal Roofing Sheet.

COLOUR COATED. [image] G,. THIS OR THAT. [image].

[image] ouew]l ...n AINVBBVM uv3Å oz. APC Metal Roofing Sheet has Excellent Corrosion Resistance Chemical Resistance Weatherability Fire Proof Colour Stable.

[Audio] polyshine APC STEEL is pretreated steel coated by Advance Polymer Resin layer on both sides via an unique pressing process at high temperature. polysibne APC STEEL combines both the advantages of steel and resin, is an innovative material for building systems, providing long service life with high resistance to corrosion, climate and mechanical damage..

[image]. MARINSHIELD Weather Resistance Advance Polymer Layer.

Product Structure & Coating Layers. Layer Material Thickness Application Colour Surface MARINSHIELD® Weather Resistance Advance Polymer 180 µ Exterior Raspberry Red 3027 Mohogany Brown 8016 Moss Green 6005 Light Blue 5012 Gray White 9002 Graphite Grey 7024 Terracotta Orange 2001 CHEMISHIELD® Modified Anti-Climate Advance Polymer 180 µ Interior Blue White Base GI Galvinium Aluminum 0.45 mm To 0.60mm Substrate Natural.

NO. TEST ELEMENTS TEST RESULT 1 Thermal Conductivity 0.015-0.029W/m.k 2 Coefficient of Expansion (1.6-1.8)х10﹣5mm/mm/℃ 3 Color E=（△E1+△E2)/2 △E≤1.5 4 Gloss G=G1+G2+G3/3 5 Adhesiveness ≥B3 Grade 6 9N Lasting Adhesiveness ≥100H 7 Freeze-thaw Resistance Test No hollowing, bubble, peeling or crack on sample surface 8 Low-temperature Hammer Drop Test No peeling or crack on sample surface 9 Temperature Resistance No peeling or crack on sample surface 10 Bending Properties No peeling or crack on sample surface 11 Corrosion Resistance 1000h, No rusting 12 Flame Resistance A Grade 13 Cold Workability No peeling or crack on sample surface 14 Stain Resistance Oil Marking Pen Black No fading, swelling or separation Blue Red Kerosene No fading, swelling or separation 15 Chemical Stability 10%(Mass Fraction）HCL No fading, swelling or separation 10%(Mass Fraction）Ga(OH)2 10%(Mass Fraction）NaOH 10%(Mass Fraction）H2SO4 16 Chemical Resistance Properties 20%(Mass Fraction）H2SO4 168h, No fading, swelling or separation 15%(Mass Fraction）HCL 20%(Mass Fraction）H3PO4 5%(Mass Fraction）NaOH 20%(Mass Fraction）HF 20%(Mass Fraction）HNO3 Ammonia Chlorine.

APPLICATIONS. POLYSHINE APC Steel is well applied in Corrosive industries Salty coastal areas Serving chemical factory Electrolytic/electroplating plant Metallurgic plant Fastener manufacturing units Galvanizing and metal Treatments industries Fertilizer storage Mining area Power station Printing and dyeing plant Waste plant Leather workshop Food and drug workshop Agricultural and breeding industries, etc..

POLYSHINE® APC Steel VS Pre-painted Color steel. POLYSHINE® APC STEEL combines the advantages of high- resistance resin with strong steel plate, creating a revolutionary coated steel with MUCH HIGHER corrosion resistance than traditional colour coated steels..

Overall comparison of different roofing materials.

Improve the service life of the Metal Sheet. The service life of the metal tile in the factory the coastal area is short, the chemical corrosion and the Stalinization are realty affected, and the Advance Polymer Coating is increased to at least 10-15 years..

Features. Corrosion Resistance. Corrosion resistance is the main advantage of POLYSHINE APC Steel Compared with PPGI or PPGL products. POLYSHINE APC Steel is well Protected by MARINSHIELD Advance engineering Polymer resin Layer from outside corrosions and damage. And CHEMISHIELD Advance Polymer resin layer from inside (bottom side) Corrosion and damage..

[image]. [image] pcked. [image]. Photographs of In-house test With Common Chemicals which are Most used.

Under the same condition the thermal conductivity of POLYSHINE APC Steel is 0.601 (w/m.k) and Colour coated PPGI/PPGL is 6.598 (w/m.k). POLYSHINE APC Steel is one tenth of PPGI / PPGL ..

Build with POLYSHINE® APC Steel Sheet. [image]. [image].

Key Features of POLYSHINE® APC STEEL. Corrosion Resistance APC Metal Sheets is Coates With Advance Polymer on Top and Bottom,it is Stable when exposed to chemical agents such as industrial emission,fog, salt, acids, alkali etc..

Thank you.

Our Some Prestigious clients. [image] GEM Technologies Inc LinkedIn.

[image] Jd Industries India Limited in Riico Industrial Area Bhiwadi Bhiwadi Best Metal Product Manufacturers in Bhiwadi Justdial.

[image] Intertek CERTIFICATE REGI TRATION Power Chem Plast Limited - Unit-II (Formerly Power Drugs Limited) •so 9001 :2015.
