[Audio] Bio Gene PLATELET AGITATOR WITH INCUBATOR MAKE BIO GENE MODEL NO:- BTI-PIPA- 22 BIOTECHNOLOGIES INC.

[Audio] ISO 9001: 2000 certified company engaged in manufacturing & exporting of Bio Gene brand of wide range of Thermo setting equipment for laboratories, Industries, universities & research institutes. The equipment range offered by us are in conformance with CE, GMP and EU standards. Bio Gene equipment finds wide application for conducting various quality Control, Production, researches and experiments worldwide. Bio Gene follow stringent quality management system in all our business activities, through qualified team of proficient quality analysts. They make sure to follow quality measures at every production stage right from procurement of raw material to final dispatch of the range. Further, the product assortment is quality inspected at all stages of production under the able guidance of our quality team. Presently, apart from the domestic markets, Bio Gene serves the demands of clients based in USA. Biotechnologies Inc Biotechnologies Inc. European quality award winner, manufacturers of laboratory equipment, scientific equipment and research equipment is a leading exporter of laboratory equipment, scientific equipment and laboratory equipment around the globe. Bio Gene lab equipment, scientific equipment and laboratory equipment have credited with CE..

. . . AWARDS & HONORS. . . . . . . . . .

[Audio] BIOTECHNOLOGIES INC® Winner of European Quality Award) CE EN- 12469 EN- 610101 EN- 61010 9480 27-DEC-2019 CE ( MDD) ( 93/42/ EEC) 9453 13/JULY/2019 ISO 9001 2015 12835 13/JULY/2019 ISO 13485 2016 1395 13/JULY/2019 ISO 14644:2015 9486350 3/APRIL/2021 US- FDA 199251 26/FEB/ 2021 ANSI 49-2019 10252023 22/AUG / 2020 WHO GMP 1024103 15-DEC-2020) GMP 60601 02/AUG/ 2019 RoHS 22489 02/AUG/ 2019 OHSAS 18001 : 2007 1801242 06/AUG/2019 ACCREDITED FROM UCS (unitas certification services UK) GMS Certification UKCL (UK).

[Audio] PLATELET AGITATOR WITH INCUBATOR MAKE BIO GENE MODEL NO:- BTI- PIPA- 22.

[Audio] APPLICATION Purpose To continuously agitate platelet concentrates in an incubator in an even suspension in a plasma bag. Type of Equipment: Flatbed agitator fitted inside a temperature-controlled incubator operating with CFC-free refrigerant gas and insulation material. FEATURES ( 1) Digital temperature recorder ( 2) Toughened glass door for safety and better visibility of platelet bags. ( 3) Digital sensor placed inside the solution-filled bottle. ( 4) Pause switch provided to arrest agitator motion for 10 seconds, for easy placement and removal of bags. ( 5) Automatic illumination when the door is opened allows for better visibility. ( 6) Magnetic gaskets for doors ensure no air is lost in a 'door closed' condition. ( 7) The internal fan switches off when the door is opened to avoid the loss of cold air. ( 8) Eyelevel positioning of TRCU for better visibility. ( 9) Bio Gene Incubator is provided with the facility of single transparent outer door for clear visibility. (10) Heavy duty ball bearing gear motor for noise less and continuous operation for 24 hours a day throughout the year. ( 11) Motor with internal fan. ( 12) Push buttons switch with pause function for temporary stoppage of the motion..

[Audio] A. PLATELET INCUBATOR Bio Gene Incubator has a provision to store the agitator. Bio Gene Incubator is provided with the facility of single transparent outer door for clear visibility. Bio Gene Incubator is capable to maintain a temperature of 22+ 2° C, set temperature of 22°C Bio Gene Incubator has a digital temperature indicator. Facility of seven day inkless chart recorder and battery back-up for 2 hours for continuous operation during power failure is provided in Bio Gene Incubator. Bio Gene Incubator is provided with single digital temperature sensor for both recording and controlling. Bio Gene Incubator has audible visual high/low alarm for temperature control, battery on/low, sensor failure, agitator off power failure compressor and system. Bio Gene Incubator has forced air circulation method for the uniformity of the temperature at all sides of the incubator. Chamber mounted electrical outlet for agitator is available. Power supply: 220- 240 volts at 50 Hz. Facility to connect with central ( Temperature) monitoring system..

[Audio] B. PLATELET AGITATOR CONSTRUCTION Internal: Stainless steel ( min 304 grade) External: Corrosion Resistant, at least 1 mm thickness Capacity: Designed to hold random platelet packs or aphaeresis platelet packs or a mixture of both types (minimum 48 random platelet concentrate packs). Transparent Door Design of Shelves: Shelves are made of nonslip, corrosion resistant material, Coated with bacteria resistant material, perforated to ensure air circulation and with sufficient clearance to minimize noise Gentle side to side agitation at 3.6- 4 cm side to side, 60- 70 strokes/ minute. Provision of forced air circulation method is available in Bio Gene Platelet Agitator With Incubator for the uniformity of the temperature at all sided of incubator..

[Audio] PLATELET AGITATOR: The platelet agitator is used for safe and reliable storage of platelets under controlled environment. Flatbed agitator fitted inside a temperature-controlled incubator operating with CFC-free refrigerant gas and insulation material. Bio Gene Platelet agitator is fully programmable with the power supply of 220- 240 volts at 50 Hz. Temperature • 7 day chart recorder with free charts till warranty period. • Temperature controller with sensor. FULLY AUTOMATIC MICROPROCESSOR CONTROL: A fully automatic dedicated microprocessor helps in monitoring all the functions of the agitator as well as Incubator. The advanced microprocessor monitors the temp. Of the chamber in real time. A bright LED displays all the parameters including date, time, temp., cooling mode, heating mode etc. COMPRESSOR: Bio Gene platelet incubator with agitator is inbuilt with hermetically sealed compressor. Refrigeration: Non-CFC air cooled refrigeration. SAFETY FEATURES Audio alarm for temperature fluctuation Auto stop for agitation when the door is opened Power failure alarm POWER SUPPLY To work on 220-240 volts at 50 Hz..

[Audio] MAKE Bio Gene PRODUCT NAME PLATELET AGITATOR WITH INCUBATOR MODEL BTI-PIPA- 22 Temperature Maintain a temperature of 22+ 2° C, set temperature of 22°C Display Digital Display Controller Microprocessor Based PID Controller Internal Stainless steel (min 304 grade) External Corrosion Resistant, 1 mm thickness SAFETY FEATURES • Audio alarm for temperature fluctuation • Auto stop for agitation when the door is opened • Power failure alarm Power Supply 220- 240 volts at 50 Hz..
