WELCOME TO ALCMS IN HOUSE TRAINING

[Audio] welcome to a l c m s in house training. WELCOME TO ALCMS IN HOUSE TRAINING.

What is ALCMS?. Airfield Lighting Control and Monitoring System.

ALCMS PLC & IF PANEL WYOLJYANG he, NO U YANG ALCMS PLC & IF PANEL SSQYOUYANG.

ABBREVIATIONS ALCMS Airfield Lighting Control and Monitoring system RCD Remote Control Desk LCD Local Control Desk MOB Monitoring and Operation Board AGLRS Airfield Ground Lighting Recording System IF PANEL Interface Panel.

PLC Programmable Logic Controller FDF Fiber Distribution Frame FOH Fiber Optic Hub SMPS Switched-Mode Power Supply NF Noise Filter IGC Industry Grand Computer HMI Human Machine Interface MCCB Molded Case Circuit Breaker CNT Consent UPS Uninterruptible Power Supply.

AR Surge Arrester TOP Touch Operation Panel CTB Common Terminal Block RY01 Relay IIFB Input Interface Board OIFB Output Interface Board EXPLC Extended PLC HDMI High Definition Multimedia Interface HUB Switching Hub RB Relay Board EIOI Ethernet Module TB01 Fixed Terminal Block CPU Central Processing Unit.

ALCMS consist of main PLC.

Extended PLC. ALCMS PLC & IF PANEL #2. ALCMS PLC & IF PANEL.

Main PLC consists of Power Module, Redundant CPU Module, MELSEC-NET Module, two Ethernet Module and Serial Module.

PLC-CPU module.

PLC-CPU normal state.

The main PLCs are installed in each system for CPU redundancy and CPUs are connected to each other using a redundant CPU module..

The main PLC is installed in PIP # 1, and the extended PLC is installed in PIP # 2 and PIP # 3..

Extended PLC consists of MELSEC-NET module for communication with main PLC, QX41 PLC input card receiving CCR input, and QY41P PLC output card outputting output to CCR. The number of input cards and output cards is inserted and the quantity inserted is determined by the number of CCRs and the number of other equalizers..

operations. When remote control tower initiates a control command, the PLC CPU received the signal through fiber optic hub, the control command will sends to QY41P PLC output card of extended PLC through Melsec-net module, the QY41P PLC card transmits the control command to the CCR through the R32C-YNT-V relay of the interface board. When the control command energized the R32C-YNT-V relay of the interface board, the LED of the corresponding relay lights up. And when the CCR energized, the CCR will send input signal to transferred to QX41P PLC card through R32C-YP-INN relay of interface board, and QX41P PLC card transferred to CPU module of main PLC. When the CCR sent input to the R32C-YP-INN relay on the interface board, the LED of the corresponding relay lights up..

RCC OF CCR 10 110B fmuntijn Ethernet(0pc) PIM mmo cancan nn.

PIP #1 COMPONENTS. FLC [liiil 4 13 15. NO 2 Part Drawing Part Picture TOP Description Usage: Emergency application in case of communication failure OP NAME : XTOP15TX-SA MAKER : M21 INDEX : TOP PLC Usage: Device for transferring PC control command to extended PLC. It is made up of redundancy. NAME : Q Series MAKER : Mitsubishi INDEX : PLCOI, 02.

3 4 5 6 7 8 MCCB Usage: UPS input power cut off voltage and DC power over current shut off _ NAME : ABS 32F IOA MAKER LSIS INDEX MCCBOI, 02 Noise Filter Usage : Power Supply Noise Filter for Optical Hub NAME MAW-1201-22 IA MAKER : TDK INDEX : NFOI. 02 FUSE Usage: DC Abnormal current interruption of control power supply NAME : KF-32L (5A) MAKER : KACON INDEX : FOI 02 SMPS Usage : F)ower supply for optical hub DC24 supply NAME : OR-15-24 MAKER : Mean Well INDEX : SMPSOI, 02 Fiber Optical Hub Usage: Optical device communicating witl NAME NSW508FCS-T MAKER ICP DAS INDEX : FOHOI SMPS Usage : Contro input DC24V Power supply Power supply NAME : DRP-240-24 MAKER : Mean Well INDEX : SMPS03, 04.

10 11 12 13 14 15 Noise Filter Usage: Power supply noise filter for control / input_NAME : MB1210 MAKER : TDK INDEX : NF03, 04 Surge Arrester Usage: Over-voltage Guidance device NAME : 9L15ECB001 MAKER : General Electric INDEX : AROI Common Terminal Block 20P Usage : Power terminal block NAME : XTB-COM20 MAKER : Samw•on Act INDEX : CTBOI - 03 Relay Usage: TOP and PLC communication redundancy relay. NAME : HR705 4PL 24V MAKER : KACON INDEX : RYOI FDF Usage : Optical connection dispenser 16Port NAME : FDF-1U-SC8C INDEX : FDFOI Fixed Terminal Block Usage : Input Power Terminal Block NAME : KH-6020-3 MAKER : KOINO INDEX : TBOI UPS Usage: Uninterruptible power supply_ It is used separately for control power and main equipment power_ NAME SURT2000XLl MAKER : APC.

PIP #1 CIRCUIT DIAGRAM. POWER m.'ACQkVA NF03 ,sF04 FOI To RCO W-LT1-a-JTLET.

NO 2 Pan Draw Pan Picture iiiiiiiic Description Extended PLC Usage: Outputs and inpl-ns to the extended PLC board to the main PLC. NAME : Q Series MAKER : Mitsubishi INDEX: PLC03 Output Relay 32Point Board Usage : Output relay board to control CCR and other equalizaüon NAME : R32F-YNT-V MAKER.

3 4 5 6 11 11 Input Relay 32Point Board Relay board receiving input signal of CCR and other equalizaton NAME : R32C-YP-lNN MAKER : SAMWON Act INDEX : -5 Fuse Usage: DC 24V (+) protective fuse for input MAKER : KACON Common Terminal Block 20P Usage : Power Terminal Block : XTB-COM20 MAKER : Samwon Act INDEX CTBU Common Terminal Block 40P Usage : Power Terminal Block NAME : TG-COM40 MAKER Act INDEX: CTB05.

PIP #2 CIRCUIT DIAGRAM. ALSF27-1 ALSF27 SSALF09-1 pAP109-1 EXPLCOI ALSF27-1 ALSF27 IIFB02 RAP127-1 PAP127 RED-I.

OUTPUT RELAY BOARD DIAGRAM.

PIP #2 OIFB CIRCUIT DIAGRAM.

PIP #2 OIFB CIRCUIT DIAGRAM.

PIP #2 OIFB CIRCUIT DIAGRAM.

PIP #2 OIFB CIRCUIT DIAGRAM.

PIP #2 IIFB CIRCUIT DIAGRAM.

PIP #2 IIFB CIRCUIT DIAGRAM.

PIP #2 IIFB CIRCUIT DIAGRAM.

PIP #2 IIFB CIRCUIT DIAGRAM.

PIP #2 IIFB CIRCUIT DIAGRAM.

INPUT RELAY BOARD DIAGRAM. RI RS RS R7 240 24G +'•v 2 o O 24 RIO R12 R14 R16 R17 R19 R21 R23 R26 R28 R30 R32 4 o 0 O 0 0 0 0 000 0000 0 0 00000 0 0 000 00 00 0 0 000 00 0 37 21 B IS 13 9 ZOLEiUiEiEKiUiUiUiAEiUiUiUILUiiiUi •v cucow RIS COL COE.

PIP #3 COMPONENT. NO 2 Part Draw Part Picture Description Extended PLC Usage: Output and inputs to the extended PLC board to the main PLC. Extended PLC Board NAME n Series : Mitsubishi INDEX : PICU Output Relay 32Point Board Usage : Relay board receiving input signal of CCR and equalization I INDEX :.

3 4 5 6 1 Input Relay 32Point Board Usage : Relay board receiving input signal of CCR and ofrer equalization NAME : R32C-YP-lNN Act INDEX : Fuse Usage: DC 24V (+) protective fuse for input NAME: KF-32L(lA) WE-R KACON INDEX 18 Common Terminal Block 20P Usage: Power Terminal Block NAME : XTB-COM20 ",IAKER : Samwon Act INDEX : CTB06 Common Terminal Block 40P Usage: Power Teminal Block NAME : TG-COIUO WE-R : SAWION Act INDEX CTB07.

PIP #3 REAR COMPONENTS. NO 2 3 Part Drawing Part Picture Description FDF Usage: Optical connection dispenser : FDF-lU-SC8C INDEX : FDFOI Output Relay 8Point Board Usage : Relays for controlling other equalization : R8G-24V MAKER : Samwon Act INDEX: RBOl&04 Input Relay 8Point Board Usage : Other equalization input signal relay NAME :.

4 5 6 7 8 9 MAKER Samwon Act INDEX : RB05 08 Common Terminal Block 20P Usage: Power Termind Block NAME : TG-COM20 MAKER : Samwon Act INDEX : CTB08, 09 Ethernet Input/output Board Usage: Control by optical repeater to optical repeater in field- NAME : ET7052-1 MAKER : ICP-DAS INDEX : EIOOI - 04 SMPS Usage: Power supply fcy device power and control, input NAME : DRP-24()-24 MAKER : Mean Well INDEX SMPS05, 06 Fiber Optical Hub Usage: Equipment that optically cammunicates with the field SFL, RTIL, WC optical repeater and ring netwcyk- NAME : NSW508FCS-T MAKER : ICP-DAS INDEX : FOH02 Surge Arrester Usage : Application: Over-voltage induction device NAME : 9L15ECB001 MAKER : General Electric INDEX : AR02 MCCB Usage : UPS Abnormal voltage of input power supply and DC power shut off NAME : ABS 32F IOA MAKER : LSIS.

PIP #3 CIRCUIT DIAGRAM. RBOI RB02 RB03 RBC4 RBOS RBCS RB07 on-ERI RB08 EIOO' EICÜ2 EICM EXPLC02 To WC27 To RTL09 E1004 8002 8003 8004 8001 E1002 8003 Elou field ( L" ) FOH02 FOH02 WC27 (RB34) FLOI FL02 FL03 FL04 FL05 FL06 FL07.

PIP #3 OIFB CIRCUIT DIAGRAM. EXPLC02. SLOTOI PLC Carg OIFBCS Kaw 8001 / SFU7 EIC02,'SFLß CAO-F.IPB.I (FB CABLE) E1003/RTIL09 EIC04,'M0127.

PIP #3 OIFB CIRCUIT DIAGRAM.

PIP #3 IIFB CIRCUIT DIAGRAM. EAC02.SLOT03 [FLC [Relay Fl 7 EICOt/SFU7 EIC02/SFLC8 CÅYF-3PB-1 (FB E1003/RTIL09 EIC04/WCZ7.

PIP #3 IIFB CIRCUIT DIAGRAM.

LCD COMPONENTS. NO 2 3 Part Drawing Part Picture Description MONITOR Usage : ALCMS Local HMI NAME : P2214H' MAKER : DELL INDEX : HMI Keyboard & Mouse Usage : PC Interface Device Industry Grand Computer Usage : ALCMS PC NAME:SNT4100 1 MAKER : SNT system INDEX : IGC.

4 5 6 7 0 At»a Surge Arrester Usage : Over-voltage Guidance device NAME : 9L15ECB001 MAKER : General Electric INDEX : AR MCCB Usage : Abnormal voltage of UPS input power supply NAME : ABS 32F IOA MAKER : LSIS INDEX : MCCB Fixed Terminal Block Usage: Input power terminal block NAME : KH-6020..3 MAKER : KOINO INDEX : TBOI Switching Hub Usage: Distribution to Ethernet line PLC, LCD, RCD. NAME : SG24001 MAKER : IP TIME INDEX : HUB UPS Usage: Uninterruptible power supply It is used separately for control power and main equipment power- NAME : SURT2000XLl MAKER : APC INDEX : UPS.

LCD DIAGRAM.

AGLRS COMPONENTS. NO 3 Part Draw Patt Picture Description MONITOR NAME:P22UH' MAKER DELL INDEX : HMI Keyboard & Mouse Usage : PC Interface Devte Industry Grand Computer Usage:ALCMSLocaIPC UME:SNT41001 MAKER SNTSFtem INDEX. IGC.

AGLRS DIAGRAM.

MOB COMPONENTS. NO 2 3 Part Drawing Part Picture Description MONITOR Usage:ALCMSLocalHMl NAMEd9LX310C(1EDN49) MAKER IG INDEX HMI Keyboard & Mouse Usage : PC Inteface Device Industry Grand Convuter Usage:ALCMSlülPC NAMESNT41001.

MOB DIAGRAM.
