Fire Rated Lite Kits and Glass.pptx

[Audio] Fire Rated Lite Kits and Glass. Fire Rated Lite Kits and Glass.

[Audio] Motivational Quote "Coming together is a beginning, keeping together is progress, working together is success" Henry Ford.

[Audio] Lite Kits. Lite Kits.

[Audio] 3-Hour Fire Rating The maximum visible glass are is 100 square inches, and the maximum visible height is 33 inches. 90-Minute Fire Rating The maximum visible area is 2034 square inches, and the maximum visible height is 56.5 inches. Hollow Metal Manufacturer Max Size 20-60 Minute Fire Rating The maximum visible area is 3024 square inches, and maximum visible height is 89 inches. Exception NDT is a certified fire shop by Intertek. We are allowed to modify lite kits and preps in hollow metal doors. We are not allowed to modify a 3-hour door for a lite kit..

[Audio] NGP lite kits are fire rated.. [Audio] Fire rated lite kits from National Guard Products provide a safe and secure solution for your building's fire protection needs. These kits are designed to meet the highest standards of fire resistance, ensuring that your property remains protected in the event of a fire emergency. With their advanced technology and rigorous testing, National Guard Products lite kits offer unparalleled performance and reliability. Whether you're looking to upgrade your existing fire protection system or install a new one, National Guard Products lite kits are the perfect choice for any building owner or manager seeking peace of mind and compliance with local regulations..

[Audio] Since fire code regulations can vary by jurisdiction, always check with your building authority to verify the specific lite size requirements and fire rating criteria..

[Audio] Fire Rated Glass. Fire Rated Glass.

[Audio] Difference between standard and fire rated glass The main difference between standard and fire rated glass is the fire rated glass can withstand much higher temperatures and help protect against fire, smoke, and radiant heat. Standard glass will shatter at about 250 degrees, and tempered glass can last to 250 degrees. Fire rated glass, on the other hand, can typically survive heat over 1600 degrees..

[Audio] Types of Fire Rated Glass Clear Fire-Rated Glass: This is the most common type, designed to remain transparent while providing fire protection. Wire-Glass: This is a type of glass reinforced with a mesh of wire, which helps prevent the glass from shattering when exposed to heat. While it offers some fire resistance, it is less commonly used today due to its reduced transparency and potential safety concerns. Intumescent Glass: This type of glass has a special coating that expands when exposed to heat. The expansion forms an insulating layer that prevents the passage of heat and smoke. Laminated Fire-Rated Glass: This is made of multiple layers of glass with a special interlayer that can withstand fire. It provides both fire resistance and sound insulation. Glass with Fire-Resistant Film: These types of glass have a film or coating that is designed to resist heat and prevent the glass from breaking during a fire..

[Audio] Fire Protective Wired Glass 20T Pyran® Platinum F National Guard Products Fire Rated Glass Pyran® Platinum L.

[Audio] 1/4" Thick 3/4" X 3/4" Diamond pattern electrically welded steel wire mesh Clear glass - ground and polished both sides Maintains integrity when fractured or subjected to a hose stream Etched with UL classification on each piece Weight: 3 lbs./sq. ft. STC 28 rating Fire Protective Wired Glass ¼" Thick Fire Protective Glass Fire-rating information: Certified by UL to ANSI/UL10C: 20 min. with closed cell PVC foam glazing tape like NGP L-GT-116, L-GT118, or L-GT-132 45, 60 & 90 min. with NGP 9800C intumescent glazing tape ANSI/UL9 with closed cell PVC glazing tape like NGP L-GT-116, L-GT-118, L-GT-132 Impact Safety Rating Information: Meets ANSI Z97.1 Class C Does NOT comply with IBC 2006 or newer requirements for use in doors or sidelights. Allowed only in non-hazardous locations defined in IBC.

[Audio] 1/4" thick tempered fire-rated glass Superior optical clarity – clear and wireless Economical fire and safety rated glass Etched with fire and impact safety classification on each piece Manufactured in USA Weight: 3 lbs./sq. ft. STC 28 rating 20T ¼" Thick 20 Minute Fire Protective Glass Certified by UL to ANSI/UL10C, With Closed Cell PVC Foam Glazing Tape Like NGP L-GT-116, L-GT-118, L-GT-132, or L-GT316 Impact Safety Rating Information: Meets ANSI Z97.1, Class A Meets CPSC 16CFR 1201 (Category I and II) Complies with IBC requirements for use in doors This glass is cut to size then heat treated (tempered) to achieve its safety rating properties Orders for this product are non-changeable and noncancellable.

[Audio] 3/16" thick glass ceramic Heavy duty 7 mil durable safety film Neutral coloration - clear and wireless Advanced manufacturing process eliminates the need for surface polishing Etched with UL classification on each piece 5-year Manufacturer Warranty Weight: 2.5 lbs./sq. ft. STC 31 rating Pyran Platinum F 3/16" Thick Fire Protective Glass Fire-rating information: Certified by UL to ANSI/UL9, ANSI/UL10B, ANSI/UL10C, CAN/ULC-S104, ULC CAN4-S106 with closed cell PVC foam glazing tape like NGP L-GT-116, L-GT-118, or L-GT-132 IBC applicable edition may limit maximum size allowable Impact Safety Rating Information: Meets ANSI Z97.1, Class A Meets CPSC 16CFR 1201 (Category I and II) Complies with IBC requirements for use in doors, side-lites, transom lites and borrowed lites.

[Audio] 3/8" thick laminated glass ceramic Neutral coloration - clear and wireless Advanced manufacturing process eliminates the need for surface polishing Etched with UL classification on each piece 5-year Manufacturer Warranty Weight: 4 lbs./sq. ft. STC 36 rating Pyran Platinum L 3/8" Thick Fire Protective Glass Fire-rating information: Certified by UL to ANSI/UL9, ANSI/UL10B, ANSI/UL10C, CAN/ULC-S104, ULC CAN4-S106 with closed cell PVC foam glazing tape like NGP L-GT-116, L-GT-118, or L-GT-132 IBC applicable edition may limit maximum size allowable Impact Safety Rating Information: Meets ANSI Z97.1, Class A Meets CPSC 16CFR 1201 (Category I and II) Complies with IBC requirements for use in doors, side-lites, transom lites and borrowed lites.

[Audio] Our Fire Rated Lite Kits and Glass products offer several key features and benefits. These include the ¼” thick tempered fire-rated glass, which provides superior optical clarity, as well as the Pyran Platinum L 3/8” thick laminated glass ceramic, which offers advanced manufacturing processes. Our products cater to different needs, whether it's economical fire and safety rated glass or more advanced options..
