PARTS OF CHILLED WATER FAN COIL UNIT AND WIRING CONNECTION

[Audio] PARTS OF CHILLED WATER FAN COIL UNIT AND WIRING CONNECTION 1.COOLING COIL 2.MOTOR AND BLOWER 3.DRAIN PAN PARTS OF CHILLED WATER FAN COIL UNIT AND WIRING CONNECTION 1.COOLING COIL 2.MOTOR AND BLOWER 3.DRAIN PAN.

[Audio] 1.Cooling coil FCU's heat exchanger (the cooling coil), From the chiller ,chilled water (10 degree Celsius) flow circulated inside the Fcu to cool the air, and after it became warm water (16 degree Celsius) pump to chiller . 10 ‘ c Supply Pipe 16 ‘ c Return Pipe CHILLER.

[Audio] 2.MOTOR AND BLOWER The motor's role is to circulate air through the coil, it means.

[Audio] MOTOR AND BLOWER The motor's role is to circulate air through the coil, it means Hot air when Fcu motor start to run, it take hot air from work area ,then pass to the heat exchanger coil . Heat exchange coil already take chilled water from the chiller, and chilled water circulating inside the coil. when hot air passing through the cooling coil, that hot air became cool air and then supply cool air to work area , this procedure is repeated again Cool air 10 ‘ c Supply Pipe 16 ‘ c Return Pipe.

[Audio] Fan Coil Unit Fcu Dual Inlet Blower ... Fan Coil Unit Fcu Dual Inlet Blower ... Fan Coil Unit Fcu Dual Inlet Blower ... Backward Curved Centrifugal Blower Fan Inline Flexible Hot Air Exhaust Fan Marine Air Conditioning System Fan Coil Unit Fcu Dual Inlet Blower Fan Coil Unit Fcu Dual Inlet Blower ... Fan Coil Unit Fcu Dual Inlet Blower ... 3.DRAIN PAN The main purpose of the tray is to collect the condensation from the fan coil unit during the cooling season. The drain is attached at the bottom of the pan..
