Electric Vehicle Charging Solutions

Electric Vehicle Charging Solutions. May 2022. . abstract.

Types of Charging Solutions. AC Slow Charging solutions - 3.3KW single socket , 3.3KW x 3 sockets - Integrated on CMS & Mobile App - offering full protection to customer vehicle batteries AC & DC Fast & Ultra Fast Charging solutions - AC 7.4 KW & 22KW Chargers - DC 15KW, 30KW, 60KW & 120KW Chargers - CMS & Mobile App for automated operations Battery Swap solutions - Bounce Infinity Battery swap stations for scooters - 4 & 8 Battery options available at select locations - CMS & Mobile App for automated operations.

Serving wide range of Customers. 2W & 3W Last mile Delivery companies - E- comm Fleet 2W vehicles - Last mile delivery 3WL vehicles (AC & DC) - 3W Passenger vehicles (AC & DC) Highway Charging - Fast & Ultrafast AC & DC chargers - 4W Passenger cars & LMV trucks - Depot overnight DC slow Charging Commercial & Residential complexes - Dedicated Charging solutions for community charging - Revenue share options - Individual Charging solutions.

Charging Hubs : facilities offered. AC & DC Charging simultaneously for Multiple Vehicles & Customers Gated Parking facility upto 20 vehicles. CCTV High resolution monitoring 24x7; Feed provided to customers on demand. Sufficient EB power capacity, upgraded ahead of demand increase. Locations close to major Logistic distribution centres Fully CMS integrated on OCPP1.6 protocol with Mobile APP based charging. Provide dedicated CMS admin user accounts to customers for activating Remote Charging sessions and effectively managing vehicles fleet. Fire safety and Protection equipment. Battery swap stations (Bounce Infinity at select locations). First Aid kit and site hygiene..

Our presence. Present in over 20 cities with 50+ Charging Hubs. Adding 15+ Hubs every month. Serving over 25 3PL customers with 150+ vehicles charged daily. Also adding over 50 Charge-n-Go locations monthly. Fully CMS integrated on OCPP1.6 protocol with Mobile APP based charging. Provide dedicated CMS admin user accounts to customers for activating Remote Charging sessions and effectively managing vehicles fleet. Download our Mobile App to get latest Charging Hubs and operational status.

Esteemed customers we serve. Lets transport. amazon.

Electrical Specifications : 3.3KW x 1 & 3 connectors.

Electrical Specifications : DC15KW x 1 & 2 connectors.

Electrical Specifications : AC7.4KW Type 2. Input Power Output Power Environment Input Voltage (AC) Wires Number of Outputs Output Connector Output 1 Rating Ambient Temperature Storage Temperature Altitude Humidity Dis la Screen 230 VAC +10% or -6%, 50Hz 1 Nos. IEC 62196, Type 2 230 VAC, Max.32 Amp. -100 C to 55 0 c -100 C to 60 oc < 2000 mtr. 5% to 95%,non-condensing 4.3"/5" Screen with or without ke English Emer enc Sto using LED oard Languages- Suppotted User Push Button Interference and Control functions Protection Communication Mechanical Visual Indication User Authentication Protection Charger and Vehicle Charger and CMS Ingress Protection IP Rating IJsing mobile application or User Interface (OCPP gives only a field mandate, media to be used is open) / QR Code / RFID Card / Password Lo in Over Voltage, Under Voltage, Over Current, Short Circuit, Surge Protection, Over Temperature, Ground Fault Protection, Residual Current, Emergency shutdown with alarm, Protection against electric shock IEC 62196, IEC 61851 OCPP vl .6 or above - 10/100 Base-T Ethernet (Standard) or Optical GSM Modem (2G/3G/4G) and Wireless O tional Indoor & Outdoor p 54.

Electrical Specifications : DC60KW & 120KW. 415 Vac +10% or -6%, 50 Hz Input Parameters Power Output Protection and Safety user Interface and Control functions Input Voltage (Vac) Input Frequency THD Power Factor Wires Output Voltage - DC (Vdc) Standard/Connector Number of Connector/Gun Efficienc Safety Parameters Dis Ia Screen Lan ua es- Su orted Push Button Cha in O tion Visual Indication User Authentication Pa ment 3 - Phase 50 Hz 5% of Nominal Volta e 0.99 (Full load) 5 -WireAC Ll L2 L3 Nand PE 200-1000 vdc CCS-2 1 CHAdeMO 2 94 % Between EV Charger and EV Communication Between EV and Central Sewer Protection Coolin Chargin Cable Length Mechanical Operating Temperature Stora e Tem erature Humidity (Non-Condensing) Over Voltage, I-Jnder Voltage, Over Current, Short Circuit, Surge Protection, Over Temperature, Ground Fault Protection, Residual Current, Emergency shutdown with alarm, Protection against electric shock 4.3"/7" TFT LCD Touch Screen En 1ish Emergency Stop (Mushroom Red) Grid Res onsive meterin Presence of Input Supply, Errors Indicator, State of Charge. Using mobile application or user Interface (OCPP gives ony a field mandate, media to be used is open) I QR Code / RFID Card Password Lo in RFID Card Wallet or A Wallet / Service IEC 62196, IEC 61851 for CCS-2 and JEVS G105 for CHAdeMO OCPP v 1.6 or above - 10/100 Base-T Ethernet (Standard) or O tical GSM Modem 2G/3G/4G or Wireless O tional 54 Forced Air Coolin 5 Meter C to 550 C 00 C to 600 C 5% to.

Working with multiple OEM partners. OKAYA NEVER STOP INDIA.

Chargers Management System (CMS) Platform. Manage Stations manage charging statons and add Chargers and Active Charging Stations Inactive Charging Stations Deleted Charging Stations View Chargers Register New Station.

Mobile App Platform for customer UI. Find Charging Station Charging Station gy Type Map View Screen showing charging stations on map with different color coding By Location By Name C on nector Type By Rating By Radius.

Mobile App Platform for customer UI. Book a slot Call charging station Navigate to station Mark station as favorite Charging Station Details Charglng StatlO Auto Available Connected to Inoperative x Not Working select POint: GB/T Estimate Unit: 2 e O.O/Kwh ?20.oo.

Mobile App Platform for customer UI. Quick Charge using QR code/RFlD QR Code Scan Quick charging can be started by scanning the QR code located at the charger unit RFID Scan Charging can also be started by using registered RFID tags. QR cold e RFID iRFlD Charging Time Set Charging duration can be fixed and estimated consumption along with price is shown in the app..

Mobile App Platform for customer UI. 100.. to Payment Options Supports Multiple Payment Gateways illDes Credit Card Debit Card BHIM UPI Net banking E Wallet.

Connect with us at: TTL ELECTRIC FUEL PVT LTD Road no 11, Mithila Nagar, Banjara Hills Hyderabad, Telangana 500 034 [email protected] www.electricfuel.co.in Offices at : HYD | BANG | MUM | CHENNAI | PUNE | JAIPUR.
