. . . . How to Choose a
Freight Elevator?. . . .

Scene 1

. . . . You have the power to. make an informed choice!.

Scene 2

A Freight Elevator has to be carefully chosen as it is meant to serve you for
decades, it’s just not only for its Size, Capacity, Speed and Orientation but

also should be compatible as per Indian Standards (IS), Government

. . ELEVATORS Capacity How & What The Weight and Volume of the material to be transported at ONE TIME will determine the capacity. Remarks & Recommendations However, volume and size of the cabin will also have to be considered keeping in mind the requirement of lift authorities. A capacity of 443 kg/Sq.mtr for moderate loading is recommended..

Scene 3

ELEVATORS
Capacity
How & What
The Weight and Volume of the material to be transported
at ONE TIME will determine the capacity.
Remarks & Recommendations
However, volume and size of the cabin will also have to be
considered keeping in mind the requirement of lift authorities. A
capacity of 443 kg/Sq.mtr for moderate loading is recommended.

The Weight and Volume of the material to be transported

However, volume and size of the cabin will also have to be

considered keeping in mind the requirement of lift authorities. A

capacity of 443 kg/Sq.mtr for moderate loading is recommended.

. . ELEVATORS Size of Car How & What The volume of goods (trolley size/ no. of pallets) to be transported at ONE TIME will determine the size of the car/ cabin. Remarks & Recommendations You can choose any size that is required by the user, we will suitably design the elevator according to BIS specification..

Scene 4

ELEVATORS
Size of Car
How & What
The volume of goods (trolley size/ no. of pallets) to be transported at
ONE TIME will determine the size of the car/ cabin.
Remarks & Recommendations
You can choose any size that is required by the user, we will
suitably design the elevator according to BIS specification.

The volume of goods (trolley size/ no. of pallets) to be transported at

ONE TIME will determine the size of the car/ cabin.

You can choose any size that is required by the user, we will
suitably design the elevator according to BIS speciﬁcation.

. . ELEVATORS Number of Floors and Travel Height How & What Each stoppage will be considered as one stop and travel from the bottom most floor to the topmost floor is the travel distance. Remarks & Recommendations Example: A four stop lift will have Ground + First + Second + Third floor. We can cater travel heights from 2.5 meters to 1 50 meters.

Scene 5

ELEVATORS
Number of Floors and Travel Height
How & What
Each stoppage will be considered as one stop and travel from the
bottom most floor to the topmost floor is the travel distance.
Remarks & Recommendations
Example: A four stop lift will have Ground + First + Second + Third
floor. We can cater travel heights from 2.5 meters to 1 50 meters

Each stoppage will be considered as one stop and travel from the

bottom most ﬂoor to the topmost ﬂoor is the travel distance.

Example: A four stop lift will have Ground + First + Second + Third
ﬂoor. We can cater travel heights from 2.5 meters to 150 meters

. . ELEVATORS Lifting Speed How & What General industry standard is 0.5 meters/second i.e. 30 meters/minute. Remarks & Recommendations Higher or Customized speeds is an option.

Scene 6

ELEVATORS
Lifting Speed
How & What
General industry standard is 0.5 meters/second i.e.
30 meters/minute.
Remarks & Recommendations
Higher or Customized speeds is an option

General industry standard is 0.5 meters/second i.e.

. . ELEVATORS Traffic Analysis- How many elevators do you need in your facility How & What To calculate the actual weight, volume of material to be transported between various floor levels in one hour / one shift and the various areas in which the load is to be carried in one facility Remarks & Recommendations This helps in concluding the capacity, speed, and the number of lifts to be installed in the facility.

Scene 7

ELEVATORS
Traffic Analysis- How many elevators
do you need in your facility
How & What
To calculate the actual weight, volume of material to be
transported between various floor levels in one hour /
one shift and the various areas in which the load is to be
carried in one facility
Remarks & Recommendations
This helps in concluding the capacity, speed, and the
number of lifts to be installed in the facility

To calculate the actual weight, volume of material to be
transported between various ﬂoor levels in one hour /

one shift and the various areas in which the load is to be

This helps in concluding the capacity, speed, and the

number of lifts to be installed in the facility

. . . . . Machine Room or. Machine Room Less. Most installations are now machine room less type. However, please check for convenience, if your building height permits or.

Scene 8

Most installations are now machine room less type. However,
please check for convenience, if your building height permits or

you have an option to provide machine rooms on top of the

Machine room less elevators save construction cost hence most

elevators are now ﬁtted with Gearless Machines which employ latest

modern technologies for enhanced performance.

. . ELEVATORS Lift Entrance Door How & What Manual Doors or Automatic Doors with electrical and Mechanical interlocks Remarks & Recommendations Automatic Doors are used for air-conditioned shop floors or clean room areas or where lift rules demand so. Manual Doors are employed for very rough and tough usage.

Scene 9

ELEVATORS
Lift Entrance Door
How & What
Manual Doors or Automatic Doors with electrical
and Mechanical interlocks
Remarks & Recommendations
Automatic Doors are used for air-conditioned shop floors or
clean room areas or where lift rules demand so. Manual
Doors are employed for very rough and tough usage

Manual Doors or Automatic Doors with electrical

Automatic Doors are used for air-conditioned shop ﬂoors or

clean room areas or where lift rules demand so. Manual

Doors are employed for very rough and tough usage

. . ELEVATORS Orientation Loading and Un-loading Sides How & What The Car can be loaded from one side and unloaded from another side, please choose from any options. Front Opening - Single side opening Front & Rear Opening -180 degrees -Two side opening Front & Side Opening - 90 degrees -Two side opening Front, Rear & Side Opening — 180 & 90 degrees - Three side opening Remarks & Recommendations Yes, any choice is possible!.

Scene 10

ELEVATORS
Orientation
Loading and Un-loading Sides
How & What
The Car can be loaded from one side and unloaded from another side,
please choose from any options.
Front Opening - Single side opening
Front & Rear Opening -180 degrees -Two side opening
Front & Side Opening - 90 degrees -Two side opening
Front, Rear & Side Opening — 180 & 90 degrees - Three side opening
Remarks & Recommendations
Yes, any choice is possible!

The Car can be loaded from one side and unloaded from another side,
please choose from any options.

Front Opening – Single side opening
Front & Rear Opening -180 degrees -Two side opening
Front & Side Opening - 90 degrees -Two side opening
Front, Rear & Side Opening – 180 & 90 degrees - Three side opening

. . ELEVATORS Cabin Interior & Landing Door & Door Frame Materials How & What Mild Steel Powder Coated I Stainless Steel Remarks & Recommendations General Industries use powder coated finishes. I Food Processing & Pharma industry use stainless steel interiors for unpacked, raw and finished goods.

Scene 11

ELEVATORS
Cabin Interior &
Landing Door & Door Frame Materials
How & What
Mild Steel Powder Coated I Stainless Steel
Remarks & Recommendations
General Industries use powder coated finishes. I Food
Processing & Pharma industry use stainless steel interiors for
unpacked, raw and finished goods

Mild Steel Powder Coated  |  Stainless Steel

General Industries use powder coated ﬁnishes.  |  Food

Processing & Pharma industry use stainless steel interiors for

. . ELEVATORS Traction Drives How & What Counter-Weight System - Use of multiple ropes & out of balance loads. The number of ropes will depend on the load and speed of the elevator Remarks & Recommendations Elevators used with S4 / S5, Industrial duty always Use multiple BIS ropes & out of balance load system for higher speeds, efficiency, safety and Longer Life..

Scene 12

ELEVATORS
Traction Drives
How & What
Counter-Weight System - Use of multiple ropes & out of
balance loads. The number of ropes will depend on the
load and speed of the elevator
Remarks & Recommendations
Elevators used with S4 / S5, Industrial duty always Use multiple
BIS
ropes & out of balance load system for higher speeds, efficiency,
safety and Longer Life.

Counter-Weight System - Use of multiple ropes & out of
balance loads. The number of ropes will depend on the

Elevators used with S4 / S5, Industrial duty always Use multiple
ropes & out of balance load system for higher speeds, eﬃciency,

. . ELEVATORS Safety Brakes & Over-speed Governor How & What Overspeed Governor to trip on more than rated speed in the downward direction which activates the safety brake on cabin to prevent free fall of the elevator in an emergency is mandatory Remarks & Recommendations During a free fall, when the cabin speed in downward direction is more than the rated speed, the overspeed Governor trips resulting in Safety Brake below the cabin getting actuated resulting in instant stoppage of the lift..

Scene 13

ELEVATORS
Safety Brakes &
Over-speed Governor
How & What
Overspeed Governor to trip on more than rated speed in the
downward direction which activates the safety brake on cabin to
prevent free fall of the elevator in an emergency is mandatory
Remarks & Recommendations
During a free fall, when the cabin speed in downward direction is
more than the rated speed, the overspeed Governor trips resulting
in Safety Brake below the cabin getting actuated resulting in
instant stoppage of the lift.

Overspeed Governor to trip on more than rated speed in the

downward direction which activates the safety brake on cabin to

prevent free fall of the elevator in an emergency is mandatory

During a free fall, when the cabin speed in downward direction is
more than the rated speed, the overspeed Governor trips resulting

in Safety Brake below the cabin getting actuated resulting in

. . ELEVATORS Integrated Frequency Drives with Closed Loop Operations How & What Integrated Drives are the latest technology in Elevator Engineering. CE Certified Integrated lift controllers Remarks & Recommendations Integrated Drives have inbuilt safety features, smooth functioning and a very good uptime. Results in accurate floor levelling, Jerk less Travel, Soft start & stop features and up to 40% saving on power.

Scene 14

ELEVATORS
Integrated Frequency Drives
with Closed Loop Operations
How & What
Integrated Drives are the latest technology in Elevator Engineering. CE
Certified Integrated lift controllers
Remarks & Recommendations
Integrated Drives have inbuilt safety features, smooth functioning
and a very good uptime. Results in accurate floor levelling, Jerk
less Travel, Soft start & stop features and up to 40% saving on
power

Integrated Frequency Drives
with Closed Loop Operations

Integrated Drives are the latest technology in Elevator Engineering. CE

Integrated Drives have inbuilt safety features, smooth functioning
and a very good uptime. Results in accurate ﬂoor levelling, Jerk
less Travel, Soft start & stop features and up to 40% saving on

. . ELEVATORS Advanced Optional Features & Benefits Multiple Guiding System Overload Device Automatic Rescue Device Self Leveling Device Emergency Calling & IOT Functions O.

Scene 15

ELEVATORS
Advanced
Optional Features & Benefits
Multiple Guiding System
Overload Device
Automatic Rescue Device
Self Leveling Device
Emergency Calling & IOT Functions
O

. . ELEVATORS Multiple Guiding System How & What 4 or more guide rails with safety brakes on each rail are used for sturdy and balanced vertical movement in large cabins Remarks & Recommendations To prevent the car from tilting or for unbalanced loads in the car, in large cabins and heavy concentrated loads multiple guiding system is used. Safety Brake is installed along with all guide rails on the cabin for these installations..

Scene 16

ELEVATORS
Multiple Guiding System
How & What
4 or more guide rails with safety brakes on each rail are used for
sturdy and balanced vertical movement in large cabins
Remarks & Recommendations
To prevent the car from tilting or for unbalanced loads in the car, in
large cabins and heavy concentrated loads multiple guiding
system is used. Safety Brake is installed along with all guide rails
on the cabin for these installations.

4 or more guide rails with safety brakes on each rail are used for

sturdy and balanced vertical movement in large cabins

To prevent the car from tilting or for unbalanced loads in the car, in

large cabins and heavy concentrated loads multiple guiding

system is used. Safety Brake is installed along with all guide rails

. . ELEVATORS Overload Device How & What When the car is overloaded an Audible and visual display is activated. Remarks & Recommendations Accuracy of +/- 2 to 3 %. When the load is corrected within the :permissible limit (rated load) an Auto Correction for normal operations is facilitated instantly..

Scene 17

ELEVATORS
Overload Device
How & What
When the car is overloaded an Audible and visual display
is activated.
Remarks & Recommendations
Accuracy of +/- 2 to 3 %. When the load is corrected within the
:permissible limit (rated load) an Auto Correction for normal operations
is facilitated instantly.

When the car is overloaded an Audible and visual display

Accuracy of +/- 2 to 3 %. When the load is corrected within the

permissible limit (rated load) an Auto Correction for normal operations

. . ELEVATORS Automatic Rescue Device ARD How & What In case of Power failure, the lift moves to the next floor. Remarks & Recommendations With the ARD back up device which have Maintenance free batteries, The car travels to the nearest landings and the doors open for evacuation. Mandatory in some states All Controller should have the option to use an ARD.

Scene 18

ELEVATORS
Automatic Rescue Device
ARD
How & What
In case of Power failure, the lift moves to the next floor.
Remarks & Recommendations
With the ARD back up device which have Maintenance free
batteries, The car travels to the nearest landings and the doors
open for evacuation. Mandatory in some states All Controller
should have the option to use an ARD

In case of Power failure, the lift moves to the next ﬂoor.

With the ARD back up device which have Maintenance free

batteries, The car travels to the nearest landings and the doors
open for evacuation. Mandatory in some states All Controller

. . ELEVATORS Re Leveling Device How & What A re levelling device corrects the floor levelling after heavy loads are loaded in the cabin. For very heavy loads, this option is necessary Remarks & Recommendations Example - When a forklift enters the cabin, the cabin floor level changes, the cabin moves down about 50-75mm (depending on load). The floor level of the cabin needs to be corrected to the landing level. In this instance the Re Levelling device activates and bring back the cabin to match the floor level..

Scene 19

ELEVATORS
Re Leveling Device
How & What
A re levelling device corrects the floor levelling after heavy
loads are loaded in the cabin. For very heavy loads, this
option is necessary
Remarks & Recommendations
Example - When a forklift enters the cabin, the cabin floor level
changes, the cabin moves down about 50-75mm (depending on
load). The floor level of the cabin needs to be corrected to the
landing level. In this instance the Re Levelling device activates and
bring back the cabin to match the floor level.

A re levelling device corrects the ﬂoor levelling after heavy
loads are loaded in the cabin. For very heavy loads, this

Example - When a forklift enters the cabin, the cabin ﬂoor level

changes, the cabin moves down about 50-75mm (depending on

load). The ﬂoor level of the cabin  needs to be corrected to the

landing level. In this instance the Re Levelling device activates and

bring back the cabin to match the ﬂoor level.

. . ELEVATORS Emergency Calling & IOT Functions How & What Emergency calling for trapped passengers & Remote monitoring Remarks & Recommendations A passenger can use this facility for calling or reaching out to three pre-fed numbers. The Calling device calls on the pre-fed numbers thrice until it receives a response. Remote monitoring is used by Building Management systems. Easa an also offer this facility for predictive maintenance, fault finding and remote correction..

Scene 20

ELEVATORS
Emergency Calling & IOT Functions
How & What
Emergency calling for trapped passengers
& Remote monitoring
Remarks & Recommendations
A passenger can use this facility for calling or reaching out to three
pre-fed numbers. The Calling device calls on the pre-fed numbers
thrice until it receives a response.
Remote monitoring is used by Building Management systems. Easa
an also offer this facility for predictive maintenance, fault finding and
remote correction.

A passenger can use this facility for calling or reaching out to three
pre-fed numbers. The Calling device calls on the pre-fed numbers

Remote monitoring is used by Building Management systems. Easa
can also oﬀer this facility for predictive maintenance, fault ﬁnding  and

. . Easa Elevators Pvt. Ltd. Head Office and Showroom 1 No. 2 & 3, Aravali Complex Rajiv colony, NH-a, Gurgaon-122001 Haryana, India. Branch Office and Showroom 2 SCO 32, Sector 82, JLPL Industrial Area, Mohali- 140308, Punjab, India. Branch Office Office No. 4, Ground Floor, Plot No. A- 15, Sector- 3, Noida - 201301, Uttar Pradesh India. ELEVATORS Manufacturing Unit G-1, 603/4/5, RIICO Industrial Area, Khushkhera- 300717, Alwar, Rajasthan, India. Contact us Uttar Pradesh, Delhi, Uttarkhand: +91 966 779 3372 Haryana, Rajasthan, Gujarat: +91 966 779 3373 Punjab, Jammu, Himachal: +91 966 779 3374 Email: info@easa.in Web: www.easaelevators.in.

Scene 21

Easa Elevators Pvt. Ltd.
Head Office and Showroom 1
No. 2 & 3, Aravali Complex
Rajiv colony, NH-a, Gurgaon-122001
Haryana, India.
Branch Office and Showroom 2
SCO 32, Sector 82, JLPL Industrial Area,
Mohali- 140308, Punjab, India.
Branch Office
Office No. 4, Ground Floor,
Plot No. A- 15, Sector- 3,
Noida - 201301, Uttar Pradesh India.
ELEVATORS
Manufacturing Unit
G-1, 603/4/5, RIICO Industrial Area,
Khushkhera- 300717, Alwar, Rajasthan, India.
Contact us
Uttar Pradesh, Delhi, Uttarkhand: +91 966 779 3372
Haryana, Rajasthan, Gujarat: +91 966 779 3373
Punjab, Jammu, Himachal: +91 966 779 3374
Email: info@easa.in
Web: www.easaelevators.in

Easa Elevators Pvt. Ltd.
Head Office and Showroom 1
No. 2 & 3, Aravali Complex
Rajiv colony, NH-a, Gurgaon-122001
Haryana, India.
Branch Office and Showroom 2
SCO 32, Sector 82, JLPL Industrial Area,
Mohali- 140308, Punjab, India.
Branch Office
Office No. 4, Ground Floor,
Plot No. A- 15, Sector- 3,
Noida - 201301, Uttar Pradesh India.
Manufacturing Unit
G-1, 603/4/5, RIICO Industrial Area,
Khushkhera- 300717, Alwar, Rajasthan, India.
Contact Us
Uttar Pradesh, Delhi, Uttarkhand: +91 966 779 3372
Haryana, Rajasthan, Gujarat: +91 966 779 3373
Punjab, Jammu, Himachal: +91 966 779 3374
Email: info@easa.in
Web: www.easaelevators.in

EASA Educational PPT.pptx
