Name: Course Name : Data Structures & Algorithms
Uploaded: 2023-07-28
Duration: 5 min 53 s
Description: Course Name : Data Structures & Algorithms. Bharat Deshpande Computer Science & Information Systems.

Course Name : Data Structures & Algorithms. Bharat Deshpande Computer Science & Information Systems.

Scene 1

Course Name :  Data Structures & Algorithms

Bharat Deshpande Computer Science & Information Systems

What is a program?. Algorithm An algorithm is a step-by-step procedure for solving a problem in a finite amount of time. Data Structures Is a systematic way of organizing and accessing data, so that data can be used efficiently. Algorithms + Data Structures = Program.

Scene 2

Algorithm 	An algorithm is a step-by-step procedure for solving a problem in a finite amount of time. Data Structures 	Is a systematic way of organizing and accessing data, so that data can be used efficiently. 	Algorithms + Data Structures = Program

Algorithmic problem. 3. Specification of output as a function of input Specification of input ? ???.

Scene 3

Specification of output as a function of input Specification of input  ? ???

For  eg :  Sorting of integers Input Instance				         	: 	 8,4  , 5,2,10 Output Instance as a permutation of  input	: 	 2,4,5,8,10

Algorithmic Solution. 4. Specification of input ? Specification of output ALGORITHM.

Scene 4

Specification of input  ? Specification of output ALGORITHM

Algorithm  describes actions on the input instance .  Infinitely  many correct algorithm for the  same  problem .   Infinite number of input instances satisfying the specification. Two key points: Repeatable argument  & Correctness

What is good algorithm?. Resources Used Running time Space used Resource Usage Measured proportional to (input) size.

Scene 5

Resources Used Running time Space used Resource Usage Measured proportional to (input) size

Measuring the running time. Write a program implementing the algorithm. Run the program with inputs of varying size and composition. Use a method like System.currentTimeMillis () to get an accurate measure of the actual running time..

Scene 6

Write a program implementing the algorithm. Run the program with inputs of varying size and composition. Use a method like  System.currentTimeMillis () to get an accurate measure of the actual running time.

Limitations of experimental studies. Implementation is a must. Execution is possible on limited set of inputs. If we need to compare two algorithms we need to use the same environment (like hardware, software etc).

Scene 7

Implementation is a must. Execution is possible on limited set of inputs. If we need to compare two algorithms we need to use the same environment  	(like hardware, software etc)

Analytical model to analyze algorithm. Algorithm should be analyzed by using general methodology. This approach uses: High level description of the algorithm. Takes into account all possible inputs. Allows one to evaluate the efficiency of any algorithm in a way that is independent of the hardware and the software environment..

Scene 8

Algorithm should be analyzed by using general methodology.  This approach uses: High level description of the algorithm. Takes into account all possible inputs. Allows one to evaluate the efficiency of any algorithm in a way that is independent of the hardware and the software environment.

Pseudo-code. A mixture of natural language and high level programming concepts that describes the main ideas behind a generic implementation of a data structure and algorithms..

Scene 9

A mixture of natural language and high level programming concepts that describes the main ideas behind a generic implementation of a data structure and algorithms.

Algorithm  arrayMax (A, n) Input:       An  array  A of n integers Output:    The   maximum element of  A 	 currentMax  ←A[0] 	for  i  ←  1 to n - 1 do 	  if  A[ i ] >  currentMax  then  currentMax  ← A[ i ] 	return  currentMax

Pseudo-code. Is structured than usual prose but less formal than a programming language. Expressions Use standard mathematical symbols to describe numeric and Boolean expressions. Uses for assignment. Use = for the equality relationship. Method declaration Algorithm name(param1,param2…).

Scene 10

Is structured than usual prose but less formal than a programming language. Expressions Use standard mathematical symbols to describe numeric and Boolean expressions. Uses       for assignment. Use = for the equality relationship. Method declaration Algorithm name(param1,param2…)

11. Assumptions. Individual statement considered as “unit” time Not applicable for function calls and loops Individual variable considered as “unit” storage Often referred to as “algorithmic complexity”.

Scene 11

Individual statement considered as “unit” time Not applicable for function calls and loops Individual variable considered as “unit” storage Often referred to as “algorithmic complexity”

Complexity Example [1]. Example 1 (Y and Z are input) X = Y * Z; X = Y * X + Z; // 2 units of time and 1 unit of storage // Constant Unit of time and Constant Unit of storage.

Scene 12

Example 1  (Y and Z are input) X = Y * Z; X = Y * X + Z; // 2 units of time and 1 unit of storage // Constant Unit of time and Constant Unit of storage

13. Complexity Example [2]. Example 2 (a and N are input) j = 0; while (j < N) do a[j] = a[j] * a[j]; b[j] = a[j] + j; j = j + 1; endwhile ; // 3N + 1 units of time and N+1 units of storage // time units prop. to N and storage prop. to N.

Scene 13

Example 2  (a and N are input) j = 0; while (j < N) do 	a[j] = a[j] * a[j];     b[j] = a[j] + j;     j = j + 1; endwhile ; // 3N + 1 units of time and N+1 units of storage // time units prop. to N and storage prop. to N

14. Complexity Example [3]. Example 3 (a and N are input) j = 0; while (j < N) do k = 0; while (k < N) do a[k] = a[j] + a[k]; k = k + 1; endwhile ; b[j] = a[j] + j; j = j + 1; endwhile ; // ??? units of time and ??? units of storage // time prop. to N 2 and storage prop. to N.

Scene 14

Example 3  (a and N are input) j = 0; while (j < N) do      k = 0; 	while (k < N) do  		   a[k] = a[j] + a[k];          k = k + 1;       endwhile ;     b[j] = a[j] + j;     j = j + 1; endwhile ; // ???  units of time and  ???  units of storage // time prop. to N 2  and  storage prop. to N

Example of sorting. 15. Output a Permutation of input of numbers b 1 ,b 2 ,b 3 ,…, b n 1,2.4.6.8 Input Sequence of numbers a 1 , a 2 ,a 3 ,…,a n 8,4,6,2,1 Sort.

Scene 15

Output  a Permutation of input of numbers b 1 ,b 2 ,b 3 ,…, b n 1,2.4.6.8 Input  Sequence of numbers a 1 , a 2 ,a 3 ,…,a n 8,4,6,2,1 Sort

Correctness(Requirement for the output) For any input algorithm halts with the output:  b 1 <b 2 <b 3 <…<  b n  b 1 ,b 2 ,b 3 ,…,  b n   is a        permutation  of     a 1 , a 2 ,a 3 ,…,a n

Running time of algorithm depends  on   Number of  elements n.  How  (partially)sorted they are.

16. Order Notation. Purpose Capture proportionality Machine independent measurement Asymptotic growth (i.e. large values of input size N).

Scene 16

Purpose Capture proportionality Machine independent measurement Asymptotic growth  	(i.e. large values of input size N)

17. Motivation for Order Notation. Examples 100 * log 2 N < N for N > 1000 70 * N + 3000 < N 2 for N > 100 10 5 * N 2 + 10 6 * N < 2 N for N > 26.

Scene 17

Examples   100 * log 2 N  <  N          for N > 1000 70 * N + 3000   <  N 2     for N > 100 10 5  * N 2  + 10 6  * N   <   2 N     for N > 26

Asymptotic Analysis. Goal: To simplify analysis of running time of algorithm .eg 3n 2 =n 2 . Capturing the essence: how the running time of the algorithm increases with the size of the input in the limit..

Scene 18

Goal: To simplify analysis of running time of algorithm .eg 3n 2 =n 2 . Capturing the essence: how the running time of the algorithm increases with the size of the input in the limit.

Asymptotic Notation. The big O notation Definition Let f and g be functions from the set of integers to the set of real numbers. We say that f(x) is in O(g(x)) if there are constants C > and k such that |f(x)| ≤ C |g(x)|, w henever x > = k. This is read as f(x) is big-oh of g(x) Note : Pair of C and k is never unique..

Scene 19

The big O notation  	 Definition 	 Let  f   and  g   be functions from the set of integers  to the set of real numbers. We say that  f(x)  is in  O(g(x))   if there are constants  C >   and   k   such that 	 |f(x)| ≤ C |g(x)|, w henever   x  > = k.  This is read as  f(x)  is   big-oh  of  g(x) Note : Pair of  C  and  k  is never unique.

20. Order Notation. Examples g(n) = 17*N + 5 lim n   g(n) / f(n) = c lim n   (17*N +5)/N = 17. The asymptotic complexity is O(N) g(n) = 5*N 3 + 10*N 2 + 3 lim n   (5*N 3 + 10*N 2 + 3) / N 3 = 5. The asymptotic complexity is O(N 3 ) g(n) = C1* N k + C2*N k-1 + … + Ck*N + C lim n   (C1* N k + C2*N k-1 + … + Ck*N + C) / N k = C1 . The asymptotic complexity is O( N k ) 2 N + 4*N 3 + 16 is O(2 N ) 5*N*log(N) + 3*N is O(N*log(N)) 1789 is O(1).

Scene 20

Examples g(n) = 17*N + 5         lim n    g(n) / f(n) = c lim n    (17*N +5)/N = 17. The asymptotic complexity is O(N) g(n) = 5*N 3  + 10*N 2   + 3  lim n    (5*N 3  + 10*N 2   + 3) /  N 3  = 5.  The  asymptotic complexity is O(N 3 ) g(n) = C1* N k  + C2*N k-1  + … + Ck*N + C lim n    (C1* N k  + C2*N k-1  + … + Ck*N + C) /  N k   = C1 . The  asymptotic complexity is O( N k ) 2 N   + 4*N 3  + 16      is O(2 N ) 5*N*log(N)  + 3*N    is O(N*log(N)) 1789   is O(1)

21. Linear Search. function search (X, A, N) j = 0; while (j < N) if (A[j] == X) return j; j++; endwhile ; return “Not-found”;.

Scene 21

function search (X, A, N)  	j = 0;    while (j < N) 		if (A[j] == X)  return j;          j++;      endwhile ;    return “Not-found”;

22. Linear Search - Complexity. Time Complexity “if” statement introduces possibilities Best-case: O(1) Worst case: O(N) Average case: ???.

Scene 22

Time Complexity 	“if” statement introduces possibilities Best-case:  O(1) Worst case:  O(N) Average case: ???

23. Binary Search Algorithm. Assume: Sorted Sequence of numbers low = 1; high = N; while (low <= high) do mid = (low + high) /2; if (A[mid] = = x) return x; else if (A[mid] < x) low = mid +1; else high = mid – 1; endwhile ; return Not-Found;.

Scene 23

Assume:  Sorted Sequence of numbers low = 1;  high = N; while (low <= high) do 	mid = (low + high) /2;    if (A[mid] = = x)  return x;    else if (A[mid] < x) low = mid +1; 	else high = mid – 1; endwhile ;    return Not-Found;

24. Binary Search - Complexity. Best Case O(1) Worst case: Loop executes until low <= high Size halved in each iteration N, N/2, N/4, … 1 How many steps ?.

Scene 24

Best Case  O(1) Worst case: Loop executes until  low <= high  Size halved in each iteration N, N/2, N/4, … 1 How many steps ?

25. Binary Search - Complexity. Worst case: K steps such that 2 K = N i.e. log 2 N steps is O(log(N)).

Scene 25

Worst case: K steps such that 2 K  = N    i.e. log 2 N steps is O(log(N))
