Definition and Explanation of KVL. The algebraic sum of all voltages encountered in traversing any loop of a circuit in a specified direction must be zero. Voltage changes around any closed loop must have sum of zero. For any closed loop network, the total voltage around the loop is equal to the sum of all the voltage drops within the same loop”. Sum of voltage drops = Sum of voltage rises Law as a consequence of conservation of energy..

Scene 1

The algebraic sum of all voltages encountered in traversing any loop of a circuit in a specified direction must be zero. Voltage changes around any closed loop must have sum of zero. For any closed loop network, the total voltage around the loop is equal to the sum of all the voltage drops within the same loop”. Sum of voltage drops = Sum of voltage rises Law as a consequence of conservation of energy.

Definition and Explanation of KVL
