Scene 1

Team Members. ‹#›. Tizana Thomas. Angelieka Hill.

Scene 2

Objectives. The objectives of this presentation are to: Define irradiation Describe the mode of action and sources of irradiation Identify factors affecting the irradiation process Discuss the applications of food irradiation and required doses State the nutritional quality of irradiated food Identify the advantages and disadvantages. State the labeling requirements of irradiated products.

Scene 3

The objectives of this presentation are to: Define irradiation  Describe the mode of action and sources of irradiation  Identify factors affecting the irradiation process Discuss the applications of food irradiation and required doses State the nutritional quality of irradiated food Identify the advantages and disadvantages. State  the labeling requirements of irradiated products

What is Food Irradiation. An advanced technology that enhances the safety and extends the shelf life of food by removing microorganisms that cause spoilage, decomposition and foodborne illnesses. A food preservation technique or process where food is exposed to radiation or ionizing energy during the irradiation procedure..

Scene 4

An advanced technology that enhances the safety and extends the shelf life of food by removing microorganisms that cause spoilage, decomposition and foodborne illnesses. A food preservation technique or process where food is exposed to radiation or ionizing energy during the irradiation procedure.

Scene 5

Scene 6

Scene 7

‹#›. Gamma Rays. X Rays. Electronic Beam. 0 3. 0 1.

Scene 8

Sources of Ionizing Radiation. Gamma Emitted from radioactive forms of Cobalt 60 or Cesium 137 FDA allows up to 100,000 rads of radiation for approved foods At 100,000 rads marker, radiation penetrates foods and infectious organisms thus preventing them from growing Low doses of gamma rays are sufficient to eliminate insects from foods.

Scene 9

Gamma Emitted  from radioactive forms of Cobalt 60 or Cesium 137 FDA allows up to 100,000 rads of radiation for approved foods At 100,000 rads marker, radiation penetrates foods and infectious organisms thus preventing them from growing  Low doses of gamma rays are sufficient to  eliminate  insects from foods

X Rays Can detect contamination or physical defects in food They are produced when high energy streams of electrons are reflected off one of the heavy metals in food The technology is important in food productions/inspections of already packaged foods as it provides non disruptive imaging.

Scene 10

Sources of Ionizing Radiation. Electronic beam High energy electrons is propelled from an electron accelerator and then into the food Novel method of all three sources of irradiation, it is also non-thermal and physical. Can be used for microbial decontamination and disinfestation of insects, thus improving food shelf life Ideally electronic beams should be used in combination with other conventional or nonconventional food processing technologies.

Scene 11

Electronic beam High energy electrons is propelled from an electron accelerator and then into the food  Novel method of all three sources of irradiation, it is also non-thermal and physical. Can be used for microbial decontamination and disinfestation of insects, thus improving food shelf life Ideally electronic beams should be used in combination with other conventional or nonconventional food processing technologies

Factors affecting food irradiation process. ‹#›.

Scene 12

Factors affecting food irradiation process

‹#›. Medium Composition of medium around organism determines dose More complex medium is, the more protected microbes are.

Scene 13

Medium Composition of medium around organism determines dose More complex medium is, the more protected microbes are

Water activity Reduction in moisture results in microbes being protected from ionizing radiation The less water present, the less damage done to DNA of microbes

Temperature Direct proportional relationship between treatment temperature and radiation effectiveness  The greater the  temperature the greater the effectiveness of radiation on vegetative cells

Oxygen The lethal effects of radiation on microbial cells increases in the presence of oxygen.  Radiation resistance increases by a factor of 2-4  without oxygen and wet conditions and 8-17 in dry conditions

Freezing Increases the radiation resistance of vegetative cells Cells are about 2-3 times more resistant in frozen foods In frozen state damage caused by OH  radicals  is almost completely  avoided

Applications of R adiation in food processing. ‹#›.

Scene 14

Applications of  R adiation in food processing

Radicidation The application of a dose of ionization sufficient to reduce the specific number of viable pathogenic bacteria to a level such that they are not detectable by any known method. The process uses a medium range dose between 2 and 8 kGy Food borne pathogenic bacteria and parasites are inactivated during this process.

Scene 15

Radappertization The application of a dose of ionizing radiation sufficient to reduce the number and activity of viable microorganisms to such an extent that very few, if any, are detectable after (viruses being excepted). Also called radiation sterilization.  Requires exposing food in sealed containers to ionizing radiation at absorbed doses high enough  (25 to 70 kGy)  .

Radicidation  The application of a dose of ionization sufficient to reduce the specific number of viable pathogenic bacteria to a level such that they are not detectable by any known method. The process uses a medium range dose between 2 and 8 kGy  Food borne pathogenic bacteria and parasites are inactivated during this process

Raduzation This treatment is sufficient to enhance the keeping quality of foods through a substantial reduction in the numbers of viable specific spoilage organisms. Doses vary with the type of food and level of contamination, but are often in the range 1–5 kGy.

Scene 16

Raduzation This treatment is sufficient to enhance the keeping quality of foods through a substantial reduction in the numbers of viable specific spoilage organisms. Doses vary with the type of food and level of contamination, but are often in the range 1–5 kGy

F ood irradiation and dose range. ‹#›. Dose range (kGy) Effects Food Items Low dose (0.1-1) Inhibit sprouts Delay ripening Phytosanitary treatment (delay insects reproducing Inactivates parasites Kills insects Potatoes, onions and garlic Banana, papaya Fresh produce Dried fish, dried fruits and legumes Meat products, fresh fruits and vegetables.

Scene 17

Dose range (kGy) Effects  Food Items Low dose (0.1-1) Inhibit sprouts Delay ripening Phytosanitary treatment (delay insects reproducing Inactivates parasites Kills insects Potatoes, onions and garlic Banana, papaya Fresh produce Dried fish, dried fruits and legumes Meat products, fresh fruits and vegetables

Food Irradiation and dose range. ‹#›. Dose range (kGy) Effects Food Items Medium dose pasteurization (1-10) Number of spoilage organisms reduced Shelf life extended Non-sporulating microorganisms inactivated Microbiological contamination reduced Strawberries Refrigerated meats and fish, ready-to-eat meals Refrigerated or frozen meats, fish and seafoods, pre-cut fruits and vegetables Spices and dried food ingredients.

Scene 18

Dose range (kGy) Effects  Food Items Medium dose pasteurization (1-10) Number of spoilage organisms reduced  Shelf life extended Non-sporulating microorganisms inactivated Microbiological contamination reduced Strawberries Refrigerated meats and fish, ready-to-eat meals Refrigerated or frozen meats, fish and seafoods, pre-cut fruits and vegetables Spices and dried food ingredients

Food Irradiation and dose range. ‹#›. Dose range (kGy) Effects Food Items High dose sterilization (10-50) Reduces microbes to point of sterility in food Meat, poultry, seafood and other food prepared for sterilized hospital diets, spices, enzyme preparations, natural gums.

Scene 19

Dose range (kGy) Effects  Food Items High dose sterilization (10-50) Reduces microbes to point of sterility in food Meat, poultry, seafood and other food prepared for sterilized hospital diets, spices, enzyme preparations, natural gums

Nutritional Quality of Irradiated Foods. ‹#›.

Scene 20

Nutritional Quality. The effect of irradiation on food components depends on the dose of irradiation used, the food matrix, and the preparation method. Nutrient losses are small when compared to other preservation methods. Macronutrients (carbohydrates, proteins, and lipids) and most micronutrients (primarily water-soluble and fat-soluble vitamins) and essential minerals do not suffer significant losses. Vitamins have varied sensitivity to irradiation and depends on the complexity of the food systems and water or fat solubility Vitamins A, B1, C and E are highly sensitive to irradiation. Losses can be minimized by freezing and packaging food in inert environment prior to irradiating..

Scene 21

The effect of irradiation on food components depends on the dose of irradiation used, the food matrix, and the preparation method. Nutrient losses are small when compared to other preservation methods.  Macronutrients (carbohydrates, proteins, and lipids) and most micronutrients (primarily water-soluble and fat-soluble vitamins)  and essential minerals do not suffer significant losses.   Vitamins have varied sensitivity to irradiation and depends on  the complexity of the food systems and water or fat solubility Vitamins A, B1, C and E are highly sensitive to irradiation. Losses can be minimized by freezing and packaging food in inert  environment prior to irradiating.

Advantages of food irradiation. ‹#›.

Scene 22

‹#›. Sprout Inhibition Onion, Potato, Insect Disinfestation Cereals, Pulses, Dry Fruits One Process: Multiple Uses Shelf-life Extension Quarantine Fruits Pathogen Reduction Spices, Flesh Foods.

Scene 23

Sprout
Inhibition
Onion, Potato,
Insect
Disinfestation
Cereals, Pulses,
Dry Fruits
One Process:
Multiple Uses
Shelf-life Extension
Quarantine
Fruits
Pathogen
Reduction
Spices, Flesh Foods

Advantages o f Food Irradiation. Elimination of pathogens and microbes of public health concern (such as parasites in fish and meat) which may cause food borne illnesses. Destroys or inactivates organisms that cause food spoilage and decomposition thus extending the shelf life Disinfestation of insect pests in agricultural commodities and quarantine treatment Decreases the need for other pest control measures that may harm fruits Inhibits sprouting tumors and bulbs (irradiation in low doses 0.02-0.2 kGy) Does not significantly alter physico-chemical characters of the treated prod uct.

Scene 24

Elimination  of pathogens and microbes of public health concern (such as parasites in fish and meat) which may cause food borne illnesses.  Destroys or inactivates organisms that cause food spoilage and decomposition thus extending the shelf life  Disinfestation of insect pests in agricultural commodities and quarantine treatment Decreases the need for other pest control measures that may harm fruits Inhibits sprouting tumors and bulbs (irradiation in low doses 0.02-0.2 kGy) Does not significantly alter physico-chemical characters of the treated prod uct

Advantages of Food Irradiation. Delay ripening and senescence of fruits and vegetables (0.2-1 kGy- enzymatic activities are inhibited in the plant tissue thus increasing longevity) Sterilization of foods which can then be stored for years without refrigeration. Reduce food spoilage since it reduces bacterial growth Reduce the need for other preservatives Reduce the need for toxic chemical treatments Only minor nutrient loss occurs Reduction of microbial load in ready to eat foods (reduction of L. Monocytogenes in soft whey cheese).

Scene 25

Delay ripening and senescence of fruits and vegetables (0.2-1 kGy- enzymatic activities are inhibited in the plant tissue thus increasing longevity) Sterilization of foods which can then be stored for years without refrigeration. Reduce food spoilage since it reduces bacterial growth  Reduce the need for other preservatives  Reduce the need for toxic chemical treatments Only minor nutrient loss occurs Reduction of microbial load in ready to eat foods (reduction of L. Monocytogenes in soft whey cheese)

Disadvantages of food irradiation. ‹#›.

Scene 26

Disadvantages of Food Irradiation. Slow acceptance by consumers due to perceived association with radioactivity. Irradiation can modify the texture and flavor of meals May lead to decrease in the nutritive value of some foods Food irradiation process does not kill all bacteria and is ineffective against viruses and bacterial toxins nor does it replace the need for correct food handling practices in the food industry Free radicals produced might react with chemicals (eg. pesticides) in food and created new compounds High capital cost in the start up and the operation of an irradiation facility.

Scene 27

Slow acceptance by consumers due to perceived association with radioactivity.  Irradiation can modify the texture and flavor of meals May lead to decrease in the nutritive value of some foods  Food irradiation process does not kill all bacteria and is ineffective against viruses  and bacterial toxins nor does it replace the need for correct food handling practices in the food industry Free  radicals  produced might react with chemicals (eg. pesticides) in food and created new compounds  High capital cost in the start up and the operation of an irradiation facility

Scene 28

Labeling requirement. FDA stipulates that irradiated foods must bear the international irradiation symbol, the Radura, with along with the statement “Treated with radiation” or “Treated by irradiation”.

Scene 29

FDA stipulates that irradiated foods must bear  the  international irradiation symbol,  the  Radura, with along with the statement “Treated with radiation” or “Treated by irradiation”

(h Koep hot foods hot, Rofrigorate loftovots
immediately or discard.

References. ‹#›. Ashraf et al., (2019). Food irradiation: A review. International Journal of Chemical Studies 7 (2): 131-136. https://www.researchgate.net/publication/332548321_Food_irradiation_A_review Bhat, R., Alias, A.K., Paliyath, G., (2012). Use of Electronic Beams in Food Preservation. Retrieved from: https://onlinelibrary.wiley.com/doi/10.1002/9781119962045.ch17#:~:text=Electron%2Dbeam%20irradiation%20(EBI),%2D%20and%20agriculture%2Dbased%20commodities. Better Health Channel (n.d). Food irradiation. https://www.betterhealth.vic.gov.au/health/healthyliving/food-irradiation#bhc-content.

Scene 30

Ashraf et al., (2019).  Food irradiation: A review.  International Journal of Chemical Studies 7 (2): 131-136.  https://www.researchgate.net/publication/332548321_Food_irradiation_A_review Bhat, R., Alias, A.K., Paliyath, G., (2012).  Use of Electronic Beams in Food Preservation.  Retrieved from: https://onlinelibrary.wiley.com/doi/10.1002/9781119962045.ch17#:~:text=Electron%2Dbeam%20irradiation%20(EBI),%2D%20and%20agriculture%2Dbased%20commodities. Better Health Channel (n.d).  Food irradiation.  https://www.betterhealth.vic.gov.au/health/healthyliving/food-irradiation#bhc-content

References. ‹#›. Brennan, J.G. & Grandison, .S. (2012). Food Processing Handbook 2nd Edition. Wiley-VCH. https://www.pdfdrive.com/food-processing-handbook-vol-1-and-2-e187022319.html Crawford, L.M., Ruff, E.H. (1996). A review of the safety of cold pasteurization through irradiation. Food Control, 7, 87-97 Dionísio, A.P., Gomes, R.T., Oetterer, M. (2009). Ionizing radiation effects on food vitamins: A review. Brazilian Archives of Biology and Technology, 52, 1267-1278. Food irradiation: What you need to know . (2018, January 4). U.S. Food and Drug Administration. https://www.fda.gov/food/buy-store-serve-safe-food/food-irradiation-what-you-need-know.

Scene 31

Brennan, J.G. & Grandison, .S. (2012).  Food Processing Handbook 2nd Edition.  Wiley-VCH.  https://www.pdfdrive.com/food-processing-handbook-vol-1-and-2-e187022319.html Crawford, L.M., Ruff, E.H. (1996). A review of the safety of cold pasteurization through irradiation. Food Control, 7, 87-97 Dionísio, A.P., Gomes, R.T., Oetterer, M. (2009). Ionizing radiation effects on food vitamins: A review. Brazilian Archives of Biology and Technology, 52, 1267-1278. Food irradiation: What you need to know . (2018, January 4). U.S. Food and Drug Administration. https://www.fda.gov/food/buy-store-serve-safe-food/food-irradiation-what-you-need-know

References. ‹#›. FSSAI (2015, January 7). What does the irradiation of a food product mean? Food Safety Helpline. https://foodsafetyhelpline.com/irradiation-food-product-mean/ FSSAI (2016, February 18) . Proposes standards for irradiation of foods . Food Safety Helpline. https://foodsafetyhelpline.com/fssai-proposes-standards-for-irradiation-of-foods/ Guantam, S. & Tripathi, J. (03, August 2016). Food processing by irradiation - An effective technology for food safety and security. Indiana Journal of Experimental Biology, 54 (11): 702. http://nopr.niscair.res.in/bitstream/123456789/36891/1/IJEB%2054%2811%29%20700-707.pdf.

Scene 32

FSSAI (2015, January 7).  What does the irradiation of a food product mean?  Food Safety Helpline.  https://foodsafetyhelpline.com/irradiation-food-product-mean/ FSSAI  (2016, February 18) . Proposes standards for irradiation of foods . Food Safety Helpline. https://foodsafetyhelpline.com/fssai-proposes-standards-for-irradiation-of-foods/ Guantam, S. & Tripathi, J. (03, August 2016).  Food processing by irradiation - An effective technology for food safety and security.  Indiana Journal of Experimental Biology,  54 (11): 702.  http://nopr.niscair.res.in/bitstream/123456789/36891/1/IJEB%2054%2811%29%20700-707.pdf

Scene 33

Scene 34

Scene 35

Scene 36

Food Irradiation

 Ashraf et al., (2019).  Food irradiation: A review.  International Journal of Chemical Studies 7 (2): 131-136.  https://www.researchgate.net/publication/332548321_Food_irradiation_A_review Bhat, R., Alias, A.K., Paliyath, G., (2012).  Use of Electronic Beams in Food Preservation.  Retrieved from: https://onlinelibrary.wiley.com/doi/10.1002/9781119962045.ch17#:~:text=Electron%2Dbeam%20irradiation%20(EBI),%2D%20and%20agriculture%2Dbased%20commodities. Better Health Channel (n.d).  Food irradiation.  https://www.betterhealth.vic.gov.au/health/healthyliving/food-irradiation#bhc-content

slide30-hotlink292

 Brennan, J.G. & Grandison, .S. (2012).  Food Processing Handbook 2nd Edition.  Wiley-VCH.  https://www.pdfdrive.com/food-processing-handbook-vol-1-and-2-e187022319.html Crawford, L.M., Ruff, E.H. (1996). A review of the safety of cold pasteurization through irradiation. Food Control, 7, 87-97 Dionísio, A.P., Gomes, R.T., Oetterer, M. (2009). Ionizing radiation effects on food vitamins: A review. Brazilian Archives of Biology and Technology, 52, 1267-1278. Food irradiation: What you need to know . (2018, January 4). U.S. Food and Drug Administration. https://www.fda.gov/food/buy-store-serve-safe-food/food-irradiation-what-you-need-know

slide31-hotlink299

 FSSAI (2015, January 7).  What does the irradiation of a food product mean?  Food Safety Helpline.  https://foodsafetyhelpline.com/irradiation-food-product-mean/ FSSAI  (2016, February 18) . Proposes standards for irradiation of foods . Food Safety Helpline. https://foodsafetyhelpline.com/fssai-proposes-standards-for-irradiation-of-foods/ Guantam, S. & Tripathi, J. (03, August 2016).  Food processing by irradiation - An effective technology for food safety and security.  Indiana Journal of Experimental Biology,  54 (11): 702.  http://nopr.niscair.res.in/bitstream/123456789/36891/1/IJEB%2054%2811%29%20700-707.pdf
