Scene 1 (0s)

[Virtual Presenter] Welcome everyone! In this lesson, we will be learning about circles and their connection to mathematics. Circles are all around us, from the wheels on our cars to the face of a clock. Today, we will define what a circle is and the essential terms associated with it. Are you ready to join me on this journey? Let's begin! First, let's understand what a circle is - a shape formed by a continuous curved line, known as the circumference, that joins at all points with the same distance from the center. This means that no matter where you measure on a circle, the distance from the center to the edge is always the same. Now, let's explore important terms related to circles. The first term is the radius, which is the distance from the center of the circle to any point on the circumference, usually represented by "r". The diameter is the next term, which is the measurement across the center of the circle, passing through the circumference and represented by "d". It is always twice the length of the radius. Another significant term is the chord, a line segment that connects two points on the circumference and is similar to the diameter but does not pass through the center. Next, we have the secant, a line that intersects the circle at two points. Lastly, we have the tangent, a line that touches the circle at one point. With a better understanding of the definition of a circle and its related terms, we can apply this knowledge to solve more complex problems and equations. This foundation allows us to explore the diverse ways that circles are a part of daily life. That concludes our introduction to circles in mathematics. I hope you are as eager as I am to continue our journey and discover more about this intriguing shape. In the next slide, we will put our knowledge into practice with some examples. I'll see you there!.

Scene 2 (1m 59s)

[Audio] In this lesson, we will be learning about circles and their related terms in mathematics. Our learning competency is to understand and illustrate terms such as radius, diameter, chord, circumference, center, arc, central angle, and inscribed angle. By the end of this lesson, you will be able to define a circle and its related terms, as well as solve problems involving the circumference of a circle. Let's begin!.

Scene 3 (2m 32s)

[Audio] Today's lesson will focus on polygons and calculating the number of sides based on the sum of their interior angles. A previous lesson taught us that a regular polygon has 1080 degrees as the sum of its interior angles. Now, we have a challenge for you. Can you determine the number of sides in a regular polygon with a sum of 1080 degrees? Take some time to think about it before sharing your answer. This challenge serves as a warm up and a way to test our understanding. Remember to refer back to our previous lesson for guidance. Let's now move on to learning about circles and their related terms in mathematics. Thank you for watching and see you in the next slide..

Scene 4 (3m 18s)

[Audio] Slide number 4 of our training video on circles and related terms in mathematics covers the topic of regular polygons and their interior angles. A regular polygon is a shape with equal sides and equal angles, with a varying number of sides. As the number of sides increases, the regular polygon approaches a circle. Our recall question asks for the number of sides of a regular polygon with a sum of interior angles equal to 1080. Using the formula n-2 * 180 = 1080, we find that the polygon has 8 sides, also known as an octagon. This formula can be applied to any regular polygon. Thank you for watching and stay tuned for the next slide as we continue to explore circles and their related terms..

Scene 5 (4m 8s)

[Audio] A circle in mathematics is a shape that has been studied for thousands of years and is defined as the set of all points in a plane that are the same distance away from a specific point, known as the center. In the image on the screen, point A represents the center of the circle. When referring to a specific circle, such as the one shown in the image, it can be labeled as "circle A" or represented by the symbol ʘA. This symbol is commonly used in mathematics to represent a circle with a particular center point. To better understand the concept of a circle, one can imagine taking a rope and fixing one end at the center point, then rotating the other end around the center for one full circle. This helps visualize how a circle is formed by a set of points that are all the same distance away from the center point. Now that we have a better understanding of what a circle is in mathematics, we can move on to learning about related terms and properties in our next slides..

Scene 6 (5m 11s)

[Audio] We will now discuss important terms related to circles, starting with the radius. The radius is described as an "arm" extending from the center of the circle to a point on the circumference. It helps us understand the size and relationship of a circle to other shapes. In our example, circle A has a radius named AB̅̅̅̅. It's important to note that the plural form of radius is radii. We will continue to explore more terms related to circles in this lesson. Let's move on to the next slide and continue our journey into the world of circles..

Scene 7 (5m 47s)

[Audio] The next term we will discuss is the chord, an important concept in the study of circles in mathematics. It is defined as a line segment formed by two points on a circle. Just like a bridge, a chord connects two points on the circumference of a circle. In this example, we have a circle named ʘA and the chord is represented by BC̅̅̅̅, indicating the two endpoints on the circle. As we delve further into circles, it is crucial to remember the essential role that chords play in connecting different points on the circumference. Next, we will move on to the next slide to explore the properties and applications of chords..

Scene 8 (6m 26s)

[Audio] We will be discussing the diameter, an important term in the study of circles. The diameter is a chord that divides the circle into two equal halves by passing through its center. It is also the longest possible chord of a circle. Interestingly, the diameter's length is always twice the length of the radius. For example, in circle A, the diameter DE̅̅̅̅ divides the circle into two equal halves and is twice the length of the radius. The diameter is a vital concept for understanding circles and is always twice the length of the radius..

Scene 9 (7m 2s)

[Audio] We will be discussing the concept of circumference in circles. The circumference is the distance around the circle, and can also be thought of as the length around the circle. For better understanding, envision yourself running around a circular flower bed. The distance you run is the circumference of the flower bed. Moving on, there are two ways of calculating the circumference: C = 2πr or C = πD. In the first formula, r represents the radius of the circle, while in the second formula, D stands for the diameter. The value of π, which is approximately 3.14, is an essential factor in these equations. To summarize, the circumference is the distance around the circle, and can be determined using the formula C = 2πr or C = πD. Remember this as we proceed to the next slide..

Scene 10 (7m 55s)

[Audio] To demonstrate our understanding, we will now use a real-life scenario. We will consider a circular pond in a park and determine its circumference using the formula C = 2𝜋r. The given radius is 7 cm, so we can plug it into the formula and find the circumference to be 43.96 cm. This formula is applicable to any circular object, from ponds and wheels to the Earth. It is a simple and versatile tool for understanding and measuring circles in our daily lives. Remember to utilize this formula whenever you encounter a circle..

Scene 11 (8m 32s)

[Audio] We are currently on slide number 11 out of 25 in our lesson on circles and related terms in mathematics. Today, we will be discussing a specific type of line that is essential in the world of circles - the secant line. This line intersects a circle in two points, penetrating the boundary and passing through two distinct points on its circumference. In our example, the line FG⃡ in circle A is a secant line. You may be wondering, what sets a secant line apart from a chord? Well, a chord connects two points on the circumference, while a secant line passes through the circle and intersects it in two points. Secant lines are often seen as extensions of chords, providing additional information and aiding in problem solving in geometry and trigonometry. Understanding the concept of a secant line is crucial in fully comprehending the properties of circles. Now that we have learned about secant lines, let's move on to the next slide to explore other important terms related to circles..

Scene 12 (9m 39s)

[Audio] Today, we will be discussing the concept of tangent lines and their relationship with circles. Specifically, we will be focusing on slide number 12 out of 25. A tangent line is a line that intersects a circle at only one point. This is represented as a point lightly touching the edge of the circle and then moving away. In our example, circle A has a tangent line HG⃡ and the point of tangency is point J. The idea of a tangent line is that it is "barely" touching the circle without fully intersecting it. In terms of notation, the tangent line is represented by HG⃡ and the circle by ʘA. The point of tangency, J, is where the two intersect. Tangent lines have various applications in geometry, trigonometry, and physics, making it an important concept in mathematics. We hope you have found this lesson helpful and we look forward to finishing the remaining slides in our presentation..

Scene 13 (10m 41s)

[Audio] In this lesson on circles and related terms in mathematics, we will be discussing a very important concept - the central angle in circle A. A central angle has its vertex at the center of the circle and is formed by two radii. It divides the circle into two equal parts and is crucial in solving geometric problems. The slide shows an illustration of the central angle and the arc it embraces, aiding in visualizing and understanding the concept. To summarize, a central angle is formed by two radii and divides a circle into two equal parts, and we will continue to explore circles and their properties on the next slide..

Scene 14 (11m 23s)

[Audio] We are now on slide number 14 out of 25, where we will discuss the concept of arcs and their relationship to the circumference of a circle. An arc is any part of a circle's circumference, representing a portion of the outer edge of the circle. The length of an arc is determined by the size of the circle and the angle it forms. There are three types of arcs: minor, semi-circle, and major. A minor arc covers less than half the circle's circumference, measuring less than 180 degrees. A semi-circle covers exactly 180 degrees, while a major arc covers more than 180 degrees. Understanding these types of arcs is important in solving problems involving circles and their properties. Let's continue on to the next slide to learn about other important terms related to circles in mathematics..

Scene 15 (12m 19s)

[Audio] Let's examine Minor Arcs in relation to circles and mathematics. A Minor Arc has a measure greater than 0 degrees but less than 180 degrees, and is labeled with two capital letters representing its endpoints. In circle A, Arc BC or BC⏜ is a Minor Arc. Understanding this term is crucial for determining angle and arc measures in circles, as well as calculating their central angles and length using the formula: Length = (𝜃/360) x 2𝜋r, where 𝜃 is the arc measure and r is the circle radius. Minor Arcs can also refer to a section of a line between two points on a circle. Recognizing and measuring Minor Arcs is a key skill in geometry and has practical applications in mapping and navigation. Next, we will move on to exploring Major Arcs - another important term in the world of circles..

Scene 16 (13m 18s)

[Audio] Slide number 16 will cover circles and other important terms related to them. One of these terms is a semi-circle, which is an arc with a measure of 180 degrees or half of a circle. In other words, a semi-circle is exactly half of a circle. For example, in our illustration, circle A is divided into two equal halves by a semi-circle named EJC. It is important to use three capital letters when naming a semi-circle. This concludes our discussion on terms related to circles on this slide. We will explore more concepts on our next slide. Thank you for watching and we will see you on slide number 17..

Scene 17 (14m 3s)

[Audio] Slide number 17 is where we will continue our lesson on circles and related terms in mathematics. Today, our focus will be on major arcs. These are arcs within a circle with a measurement between 180 and 360 degrees. They are named using three capital letters, and in our circle A, we have an arc labeled as MGS or MGS ⏜, which is a perfect example of a major arc. Remember, a major arc is not a complete circle, but rather a portion of it. To summarize, major arcs have a measurement between 180 and 360 degrees and are named using three capital letters. We hope this has helped improve your understanding of major arcs in circles..

Scene 18 (14m 50s)

[Audio] The distance from the center of a circle to its edge is known as the "radius." This distance will vary for each circle within a set of concentric circles. In the example on this slide, the blue and purple circles have different radii - the blue circle's radius is smaller, while the purple circle's is larger. This difference in radii directly affects the circumference of each circle, or the distance around the edge. Just like water waves, concentric circles also expand in circular patterns, originating from the same center. This can be observed in the animation on this slide. Concentric circles are significant in mathematics, as they are utilized in various geometric and trigonometric calculations. They also have practical applications in fields such as engineering and architecture. Familiarizing yourself with concentric circles and their related terms will not only enhance your mathematical understanding, but also assist in problem-solving and precise measurements. Take some time to practice drawing and identifying concentric circles, and you will see their usefulness in your studies and daily life. Thank you for watching this lesson. Stay tuned for more intriguing mathematical topics..

Scene 19 (16m 8s)

[Audio] The terms we will be discussing on this slide are related to circles in mathematics. One of these terms is congruent circles, which are circles with the same radius but different centers. Similar to twins, they have the same shape but are located in different places. It's essential to note that congruent circles are not identical, as their centers are in different positions. This concept is frequently utilized in geometry and can aid in solving various problems. Let's proceed to the next slide to learn more about related terms..

Scene 20 (16m 43s)

[Audio] The concept of inscribed angles in circles is our next topic. An inscribed angle is created when two lines intersect the circle at two different points. It is important to note that the measure of the inscribed angle is always half of the central angle that intercepts the same arc. Some key terms related to inscribed angles are the vertex, the arc, the chord, and the central angle. Inscribed angles give us a unique perspective of the circle. In the next lesson, we will continue our study of circles and related terms in math..

Scene 21 (17m 19s)

[Audio] Now that we have learned about the different terms associated with circles, it's time for some hands-on practice. Let's look at this circle, ⚫P, and identify its components. The circle is named after its center, so this one is called ⊙P. Our first component is the center, represented by the point 𝑃 at the exact center. The radii are line segments connecting the center to any point on the circle, which in this case are 𝑃𝐴̅̅̅̅, 𝑃𝐶̅̅̅̅, and 𝑃𝐵̅̅̅̅. The diameter is a line passing through the center with endpoints on the circle, which can be represented by 𝐵𝐶̅̅̅̅ or 𝐶𝐵̅̅̅̅. Chords are line segments connecting any two points on the circle, such as 𝐷𝐸̅̅̅̅ and 𝐵𝐶̅̅̅̅. Moving on to arcs, we have 𝐶𝐴̂, 𝐴𝐵̂, 𝐸𝐷̂, 𝐴𝐵𝐶 ̂, 𝐴𝐸𝐶 ̂, 𝐶𝐴𝐵 ̂, and 𝐶𝐸𝐵 ̂. Finally, we have central angles, with their vertex at the center of the circle. In this case, we see ∠𝐶𝑃𝐴 and ∠𝐴𝑃𝐵. You have successfully identified all components of this circle. Remember, practice makes perfect, so keep practicing and you'll become a pro at identifying circle terms in no time. Well done!.

Scene 22 (18m 28s)

[Audio] We are now on slide 22 out of 25 in our presentation on circles and related terms in mathematics. In this lesson, we will visually demonstrate the various elements that we have been discussing. In the circle B, we will identify and illustrate the following: a.) The radius represented by BC. b.) The diameter, which is shown as AD. c.) Chords, specifically ED and AD, which intersect within the circle. d.) Arcs, including DĈ, CÂ, AÊ, DCÂ, and DEÂ. e.) Central angles, for example ∠ABC and ∠CBD. f.) And finally, an inscribed angle, ∠ADE. This will give us a better understanding of the concepts and how they are related in a circle. Now it's your turn to practice. Pause the video and identify these elements in the circle B. Once you have finished, we will review them together. After that, we will move on to our final slide and wrap up our discussion on circles..

Scene 23 (19m 37s)

[Audio] We are now on slide number 23 out of 25, discussing various terms related to circles. Please have a sheet of paper ready for a few questions. On the slide, there is a circle with marked points. The first question is, what is the name of the line touching the circle at only one point, from point E to point J? Write your answer in the designated box. Moving to the second question, what is the name of the line connecting the circle's center to any point on the circle? Write your answer in the second box. Next, there is a line from point E, through the circle's center, ending at point R. What is this line called? Write your answer in the third box. The fourth question is, what is the name of the line passing through the circle's center, with both endpoints on the circle, starting at the center and ending at point R? Write your answer in the fourth box. For question number 5, what is the name of the line starting at point I, going through the center, and ending at point W? Write your answer in the fifth box. Question number 6 asks for the name of the point marked as E on the figure. Write your answer in the sixth box. Next, question number 7 asks for the name of the angle formed by the lines starting at points I and E, touching the circle at point W. Write your answer in the seventh box. Moving on, what is the name of the line starting at point I and tangent to the circle at point E? Write your answer in the eighth box. The ninth question asks for the term of the angle formed by the lines starting at points I and E, and touching the circle at point R. Write your answer in the ninth box. For the final question, what is the name of the point marked as N on the circle? Write your answer in the tenth box. I hope all questions have been answered..

Scene 24 (21m 35s)

[Audio] We have covered various aspects of circles in mathematics and it's time for a quick review. On the final slide, there is a circle with labeled points and lines. Your task is to identify and label the following: the diameter, Point A, the tangent line, the angle formed by the tangent and secant lines, the distance between Point A and the center of the circle, the minor arc, the entire circle, and the central angle formed by the intersecting secant and tangent lines. Please complete this assignment to solidify our understanding..

Scene 25 (22m 12s)

Thank You. A person holding a cake Description automatically generated with low confidence.
