[Audio] This slide shows a computer interface with a CIMS-MOBILE network layer. It is one of the systems used in mobile network operations which registers and generates E-M-F parameters for EIRP. The layer ensures the parameters for CIMS-EMF are correctly identified and available..

[Audio] Our team is responsible for gathering the essential data for registering mobile network operations and antenna details to the CIMS-MOBILE network Layers. These details include the project site ID network operation details frequency power antenna detail azimuth and tilt values as well as any other information specified by the TSSR/SSO/NOC/Helpdesk Reference Point Manuals and Huawei Infos. We must then register the mobile operations to the CIMS-MOBILE network and register the antenna detail to the CIMS-MOBILE network-ANTENNA. After doing this we generate a mobile ID and a technical ID for mocan and moran. All these details in the mobile network will then generate E-M-F parameters for the EM ID. Furthermore a separate registration of the structure information to R-C-I is necessary to generate Structure/Tower IDs. This is required for each band/frequency and all the details for each structure must be added. Then the site handover and actual detail must be confirmed..

Item Site ID Building Height AGL Tower Height (GBT) AGL Latitude Longitude Antenna Height AGL System Type Frequency Band Antenna Manufacturer Eelctrical Tilt / Tilt Azimuth Units (m) (m) (Degl (Degl (m) (MHz) Anta (Deg) (Deg) (Deg) (Watts) Operator 2 TSE 0891S1 Kg Simatuoh Digi Kg Simatu&l, Sepulot, 89950 Nabawa Sabah Operator BE 0891S1 Kg Simatuoh Kg Simatuoh, Sepulot, 89950 Nabawa Sabah ase979•N 21 1800 N/A 466979• N 1800 ase979•N 4,66979• N 2100 N/A 2100 ADU4518R6v06 ADU4518R6v06 ADLI 4518R6v06 2100 AOU4518R6v06 ADU4518R6v06 ADu4518R6v06 120 20.

[Audio] The Radio Communication Infrastructure Layer in C-I-M-S will automatically generate a Structure ID which is necessary for Operators to tag and share information for Local Operation. The CIMS-Mobile Network must also have the Structure ID to register network details. Incomplete parameters could affect the CIMS-EMF-EIRP generation therefore the Actual Site Name and Address Actual Latitude and Longitude Installation or Handover Date and USP Project must match the Project Approval or Handover Documents. A black tower with a satellite dish is shown in the image..

[image]. CIMS-MOBILE NETWORK-Data Required. Info Needed comes from : - ON AIR INFO-SAT PART 2. SSO, SSV, PER SITE ID - RT NOC, HUAWEI - Structure info from CIMS-RCI Layer Compulsory Parameter Needed. - TOWER_ID from CIMS-RCI Layer - SITE ID (REFID), SERVICE PROVIDER. - BACKHAUL INFO - ACTUAL LATLONG AS RCI -1 MOBILE ID for 1 Operating Service Provider Must same as Project Approve / Hand Over./TSSR CIMS-MOBILE NETWORK LAYER-WILL GENERATE MOBILE_ID PURPOSE : 1. For CIMS-MOBILE NETWORK- ANTENNA and CIMS-MOBILE NETWORK _TECHNOLOGY -antenna detail registering 3. MOBILE ID COMPULSORY FOR 2300&2600 SA SUBMISSION 4. EMF – Incomplete parameter will affect CIMS-EMF-EIRP to Generated..

[Audio] To ensure the proper functioning of our CIMS-MOBILE network layers and the generation of E-M-F parameters it is necessary to register mobile network operations and antenna details. This includes parameters such as RT NOC and HUAWEI SSO S-S-V and P-E-R site ID. Additionally in order to generate EIRP EMF parameters Antenna Height Azimuth and Mechanical Tilt details must be registered per antenna. The Mobile Network Antenna Template requires all compulsory parameters to be added as outlined in the colour column and every antenna detail must be added per Mobile ID in the CIMS-MOBILE network layer..

MOBILE NETWORK ANTENNA TECHNOLOGY-Data Required. [image].

Current issue :. [image] A black tower with a satellite dish Description automatically generated.

[Audio] This slide highlights the significance of having up-to-date precise data for our E-M-F parameters to be effectively produced. The mobile network data gap shown in this slide is a crucial marker of the advancement of the CIMS-MOBILE network layers used to generate E-M-F parameters for EIRP. This data gap gives us information on towers from T3E_P1 T3E_P3 jendela rens L-2-6-0-0 and L2300. Duplicate mobile network info has been untagged from RCI ID and must be fixed..

[Audio] To ensure the accuracy and quality of data within our CIMS-MOBILE network layers we have identified a data gap between T3E-P1 and T3E-P3 towers in Johor Sarawak Kelantan Kedah Perak Negeri Sembilan Sabah and Sarawak as well as a gap in jendela towers which is specific to Sabah and Sarawak. We have also identified discrepancies in EMF-T3E towers rens L-2-6-0-0 and STES L2300 towers as well as extra antennas per mobile ID and wrong antennas associated with wrong mobile IDs. To resolve these discrepancies we are requesting to delete all associated extra antennas and wrong mobile IDs..

[Audio] Without greetings and without beginning with Today: We are looking at data gap T3E_P1 T3E_P3 jendela and rens L-2-6-0-0 to L2300 OTHerS TM rooftop fiberail and EMF T3E. We are discussing the need to delete extra antenna technology per antenna as well as for incorrect antenna details within incorrect mobile ID's. Generally one antenna typically consists of two bands for 2G and 3G or three bands for 2G 3G and 4G. However with the addition of 5G more antennas and bands are being added creating a need for more antenna technology to be deleted. Thank you for your attention..
