A PRESENTATION ON

A PRESENTATION ON. CLOSED CIRCUIT TELEVISION (CCTV).

Definition Uses Types of CCTV system Block diagram Types of CCTV lens Camera selection Elements of CCTV system Monitor Unit Video Recorders (DVR/NVR) Cables Storage device Applications.

What is CCTV ?. Closed-circui t television CCTV is the use of video cameras to transmit a signal to a specific place, on a limited set of monitors. It differs from broadcast television in that the signal is not openly transmitted, though it may employ point to point (P2P), point to multipoint, or mesh wireless links..

Uses of CCTV CCTV is commonly used for a variety of purposes, including; Maintaining perimeter security in medium-to-high secure areas &installations. Observing behaviour of incarcerated inmates and potentially dangerous patients in medical facilities. Traffic monitoring Building & ground security Overseeing locations that would be hazardous to a human , for example, highly radioactive environment. Obtaining a visual record of activities where it is necessary to maintain proper security, for example, in banks, casinos or airports..

Types of CCTV system 1. Analog CCTV system Analog security cameras an analog video signal and transfer that signal over coax cable to Digital Video Recorder (DVR). Each camera may be powered by plugging in the power supply right at the camera or by using RG siamese cable or which bundles the video and the power cable. Digital/IP CCTV system IP stand for Internet Protocol, and basically refers to a digital video camera that can send and receive data via a computer network..

CCTV systems block diagram. ell * 001. .mera ra21..-v-c Camera4 Camera Camera2n—v-c Camera4 Monitor Remote PC Remote PC.

Types of CCTV camera Indoor camera Outdoor camera IR Day/Night camera Dome camera Bullet camera Hidden camera Pan Tilt zoom camera Fish eye camera.

Indoor Camera Indoor camera as it name suggests used for indoor security mechanism. These are suitable for security in homes, schools, offices, hotels etc....

Outdoor Camera Outdoor camera is used for outdoor places. They are mostly used for entry and exit points with limited night lighting. These cameras have hard shell vandal-proof casings..

IR day/Night Camera IR day/night camera are used for high alert security areas were surveillance needs to happed day and night These cameras are used by military personal, in parking a lots and high security zones. The cameras are ideal for outdoor surveillance application..

Dome Camera Dome CCTV Cameras . Dome Security Cameras are named for their dome -like shape. Cameras are installed inside a dark dome and are design in a way that they go unnoticed by the visitors. The camera can be rotated and tilted manually. Dome cameras are commonly used in surveillance systems inside of homes, casinos, retail stores, and restaurants..

Bullet Camera Bullet Security Cameras are a type video surveillance camera that is typically small and shaped like a rifle bullet shell. Cylindrical Outdoor use Installed inside pr otective casings, which protects against dust, dirt, rain and other harmful element..

PTZ (Pan-Tilt-Zoom) cameras PTZ cameras offer pan, tilt, and zoom capabilities, allowing them to rotate horizontally (pan), vertically (tilt), and adjust the focal length (zoom). This flexibility enables users to remotely control the camera’s movements and focus on specific areas or objects of interest. Remote Control: PTZ cameras can be controlled remotely through various methods, such as using a joystick controller, software interface, or mobile applications..

Connecting methods of PTZ camera. nudio oul DC 12V "Am Audio In Alnrrn Inl Oul Connecting interface Ø 220M' -)QQQQ Switc'l/Routor NC for tost.

rS•npc. Fish Eye Camera The fish eye camera is the single camera which allows you to record everything With a 180 or 360 degree panoramic view. Types of fish-eye lenses: There are primarily two types of fish-eye lenses: circular fish-eye and full-frame fish-eye. Circular fish-eye lenses capture a complete circular image within the frame, while full-frame fish-eye lenses cover the entire rectangular frame..

Types of cctv lens There are two types of lenses. 1. Fixed Fixed lens are those lenses where lens size doesn’t make change, all we can do is focus, we can’t join or zoom out Common sizes are 12mm, 0.8mm, 06mm, 04mm, 3.6mm, 2.8mm 2. Varifocal In varifocal lens size can be changed during the installation process and Zoom In and zoom out is possible Common sizes available are 2.5mm~8mm, 3.0mm~12mm, 5.0mm~50mm.

Camera Selection If we select the camera, we will consider about these categories..

Cameras CCIVDVR Power Supply Monitor (l R SURF 5101 HDMI/VGÅ/AVOJt 4th Router Mouse.

Monitor Unit The functions of the monitor is to display video images for viewing. The selection of monitors is as important to the quality of image as the selection of cameras, lenses and other components in the imaging chain..

Video Recorders (DVR/NVR) Video recorder is at the heart of the CCTV installation. They received, manage, store and record the video captured by the cameras. Video recorders are two types.

DVR (Digital Video Recorder) It is a device that records video and audio signals from various sources, typically television broadcasts, security cameras, or other video input devices. In surveillance systems, DVRs are used to capture and store video footage from security cameras.

DVR back side ports. Microphone LCD TV or Monitor Camera www - horung - con. 1090 L 76206 Alarrn in/out VOA Sound USB 2.0 Power Online Client Mobile, User.

NVR (Network Video Recorder) It is a device used in video surveillance systems to capture, store, and manage video footage from IP cameras or network-based video sources. NVRs are designed to work with IP cameras, which are cameras that transmit video over a network or the internet..

NVR back side ports. Alarm In GND VGA Output PoETnterface Network Interface Audio Input/Ouput HDMII Output 12V Power Output Power On/Off Power Supply USB 3.0 Alarm Out HOM12 Output RS-485.

Cable Coaxial / Ethernet. CCTV can be analogue or IP based. Depending on that the cables can be coaxial cable or CAT5/CAT6(RJ45) cables also known as Ethernet cable. Cables connect the camera with the DVR / NVR.

VGA cable. Video Graphics Array is a standard type of connection for video devices such as monitors and projectors..

Cable Connectors. BNC Connectors Type of connector used to connect coaxial cables. RJ 45 Type of connector used to connect internet cables.

Storage devices Hard disc drive or HDD need to store the CCTV camera footage. It help to review the system footage.

Applications of CCTV camera. Bars Cash rooms Gaming machines Historic sites Holiday sites Hospitals Number plate recording Public species and other large areas.

Thank you.
