BASIC PRODUCTS FOR BASIC SET-UP

Published on
Scene 1 (0s)

BASIC PRODUCTS FOR BASIC SET-UP. NANXING woodworking Machinery INDIA Pvt Ltd Email: - info@nanxingindia.com Phone: +91-99803 91827.

Scene 2 (4s)

50TON COLD PRESS NI-50T. NANXINGINDIA. Capacity 50 Ton Platen Size 2500mm x 1300mm(8’ x 4’) Max Opening 1000mm No of cylinders 02 Stroke 900mm Fully automatic Power Pack & Panel 5HP Machine Weight Approx. 2.8 Tone.

Scene 3 (8s)

NANXING MANUAL SLIDING TABLE PANEL SAW MJK1132F1.

Scene 4 (12s)

NANXING BASIC AUTOMATICE EDGE BANDER NBC332. Model NBC332 Panel length ≥120mm Panel width ≥60mm Min panel size 120×60mm Panel thickness 9-60mm Edge tape thickness 0.4-3mm Feeding speed 16/20/24m/min Dust extraction φ125mm×3 Total power 12.2kw Overall dimension 5040×1050×1440mm Net weight 1620kg.

Scene 5 (16s)

NANXING 3-HEAD MULTI BORING MACHINE. aLoaec.1N. Model NDB201C Max panel width 1700mm Min. panel width 90mm Max. panel thickness 70mm Spacing of drills 32mm Max vertical boring depth 70mm Max horizontal boring depth 40mm Total power 4.1kw Overall dimension 2550×2835×1510mm Approx. weight 1100kg.

Scene 6 (20s)

ADDRESS No.5 , 1 st Main, Opp. BIEC Nandishwar Badavane , Madavara Bangalore India-562123 THANK YOU.
