Description: . . ARKOS. . VRLA BATTERY MAINTENANCE FREE. BOLT – Just A Genuine Battery.

. . ARKOS. . VRLA BATTERY MAINTENANCE FREE. BOLT – Just A Genuine Battery.

Scene 1

. . Why Battery is Needed?. BOLT – Just A Genuine Battery.

Scene 2

In an Automobile Batteries have to cater to various Electrical loads and the
most important role is to start the engine.

To Start the Engine – Starter Motor cranking


As a stabilizer to maintain the Voltage across the circuit, when

there are shortfall due to excess loads / lower output of the magneto.

As a back up power when the Magneto / Alternator fails.

STARTER
Magneto I Alternator
Voltage =14.2 + o.2V
INPUT
BATTERY
OUTPUT
ELECTRICAL
LOADS

. . Battery Terminology. BOLT – Just A Genuine Battery.

Scene 3

The rate of flow of electricity, or the movement of electrons along a conductor.
It is comparable to the flow of a stream of water. The unit of  measure of the
electron flow rate or current, through a circuit is Ampere (Amp. A)

DC : Direct Current
AC : Alternating current


Volt:
The unit of measure for electrical potential, is called volt.


Cycle:
In a battery, one discharge plus one recharge equals one cycle.


Cell Element:
A set of positive and negative plates with separators is called an element

Scene 4

The ability of a fully charged battery to deliver a specified quantity of electricity,
at a given rate, over a definite period of time. The capacity of a battery depends
upon a number of factors such as active material weight, density of the active
material, adhesion of the active material to the grid, number, design &
dimensions of the plates, plate spacing, design of separators, specific gravity &
quantity of available electrolyte, grid alloys, final limiting voltage, discharge
rate, temperature, internal & external resistance, age & life span of the battery.

Capacity of a battery varies with the rate of discharge (current), Higher the
current, lower is the capacity

The amount of current a battery can produce for 30 sec. At -18°C before its
voltage drops below 7.2 Volts (1.2 V per cell)

. . Bolt Battery Features. BOLT – Just A Genuine Battery.

Scene 5

Features
DOUBLE CLAD SEPARATOR
Improve life cycle & better resistance
to vibration
AGM CONSTRUCTION
Superior cranking power and
resistance to vibration
ADVANCED VRLA TECHNOLOGY
better
UNIQUE FLAME ARRESTER
Ensures Great Safety.
GUARANTEED WARRANTY
At ARKOS, customer satisfaction is always
our priority. TO make after sales experience
hassle free we present to you:
It Eliminates water loss making the battery
completely mai ntenance-free.
PP CASE
Special PP container makes to batteryStrong
to withstand extreme operating conditions.
BOLT WARRANTY MANAGEMENT SYSTEM (WMS)
This is a paper free electronic warranty
management system wherein the consumer
doesn't need to carry a physical copy of the
warranty card. Our WMS makes the warranty claim
settlement process completely hassle free.
BEST PRICING
Bolt batteries comes with best
pricing for the value delivered
through latest products & solutions.

. . Battery Dignostics. BOLT – Just A Genuine Battery.

Scene 6

Use Multimeter/Midtronics Tester and check
Open Circuit Voltage (OCV)

Voltage > 12.5V - Battery is fully charged.

Voltage >12.2V  <12.5V - Battery  is partially
discharged needs freshening charge.

Voltage < 12.2V - Battery is discharged and
requires full re-charging.

. . . . ARKOS. . . Two Wheeler Range. BOLT – Just A Genuine Battery.

Scene 7

. . BOLT – Just A Genuine Battery. ARKOS. . . . .

Scene 8

Scene 9

ÅRK0s
VRLA
BATTERY
MAINTENANCE FREE
GUIC
START
12V 4 AH

Scene 10

ARKOS
VRLA
BATTERY
MAINTENANCE FREE
-START
12W5 AH

Scene 11

ARKOS
VRLA
BATTERY
MAINTENANCE FREE
QUIC
-START
12V 5 AH

Scene 12

HV L
Y'tno
umia
*ONVNUNIVN
Au:uvg
soyuv
0

Scene 13

ARKOS
VRLA
BATTERY
MAINTENANCE FREE
QUIC
-START
V YAH
AB-MF 9

Scene 14

BATTERY
MAINTENANCE FREE
36
QU,'C
-START
14 A H

Scene 15

. . . . . Warranty Policy. •. •. •. •. Warranty Period: Comprises of FREE REPLACEMENT and PRO-RATA. The label
on every ARKOS battery specifies the total number of months covered by the
free replacement period and the Pro-Rata period for batteries fitted in two-
wheelers.
In all cases the warranty is applicable from the date of sale to the original
purchaser.
For a battery being replaced on Free of Cost basis the warranty
commences from the date of sale of the original battery as stated in the
original Warranty Card and not from the date of replacement given.
For batteries purchased on pro-rata warranty settlement discount, a
fresh warranty is applicable from the date of purchase..

Scene 16

Warranty Period: Comprises of FREE REPLACEMENT and PRO-RATA. The label
on every ARKOS battery specifies the total number of months covered by the
free replacement period and the Pro-Rata period for batteries fitted in two-
wheelers.
In all cases the warranty is applicable from the date of sale to the original
purchaser.
For a battery being replaced on Free of Cost basis the warranty
commences from the date of sale of the original battery as stated in the
original Warranty Card and not from the date of replacement given.
For batteries purchased on pro-rata warranty settlement discount, a
fresh warranty is applicable from the date of purchase.

. . . . Term 8 Conditions... . . Free. Replacement.

Scene 17

Scene 18

. . BOLT – Just A Genuine Battery. soyuvl. . All liabilities under this Warranty shall cease if:
•
The battery has been operated in an application that it was not designed for and/or.

Scene 19

All liabilities under this Warranty shall cease if:
•
The battery has been operated in an application that it was
not designed for and/or

•
Marketed to support/Company's Application Chart.

•
Battery has been refilled with additives, dopes or any other
substance besides distilled water that may have
contaminated the battery

• Damaged due to fitment of additional accessories in vehicle

• Out of Warranty Period.
• Please use the below Website.. https://wms.arkos.in/

. . APP LINKS. BOLT – Just A Genuine Battery. . .

Scene 20

Our Warranty Process is Complete Online.
All batteries has to be billed and put warranty claim online only.

Please follow the below links for further details..

BOLT CARE APP:-
https://play.google.com/store/apps/details?id=com.twoiq.boltcare

CBT 300 APAR APP:-
https://play.google.com/store/apps/details?id=com.appleenergy.cbt300.apar

. . SOP FOR CBT-300 Tester. BOLT – Just A Genuine Battery.

Scene 21

. . Charging VRLA battery. BOLT – Just A Genuine Battery.

Scene 22

 This is a Fully Automated Charger where the

simultaneously which also results in lower gas
generation during charging.

BATTERY
VOLTAGE
12.ov
HARGIN
CU RRENT
CHARGING TIME
IN FORMAT
HOUR : MIN : SEC
STAGE NO.

. . ARKOS. . Thank Y. k You. . BOLT – Just A Genuine Battery.
