Scene 1 (0s)
1006 OSI. R&D Instrument Services Specialist in Calibration Instruments Since 2002.
Scene 2 (15s)
[Audio] The HP-series introduces the HP-40 hand pump, a reliable tool for precise pressure calibration. With its ability to generate pressures up to 60 bar and vacuums up to -0.95 bar, this pump ensures accurate results with ease. The APG-series takes it further by delivering exceptional accuracy, ranging from 0.1% to 0.02% full-scale, and offering a wide range of pressure settings from -1 bar to 1000 bar. With its large, backlit display and CE certification, the APG-series provides a comprehensive solution for pressure calibration, ensuring durability even in harsh environments..
Scene 3 (59s)
[Audio] The APG Series provides high-accuracy digital pressure indicators with selectable accuracies of 0.1%, 0.05%, and 0.02% Full Scale, ranging from -1 to 1000 bar. As a standalone gauge or integrated into pneumatic systems, it features 14 pressure units, zero, tare, and peak hold functions. This advanced pressure gauge calibrator kit is suitable for calibrating pressure gauges, transducers, and switches, offering precise pressure generation..
Scene 4 (1m 32s)
[Audio] The APG series digital pressure gauge has several buttons that allow users to easily operate it. The ZERO button resets the gauge's display to zero before calibration or testing. The MIN/MAX button selects the display mode to show the minimum, maximum, and present values. Users can also choose their preferred unit of measurement using the UNIT button. Furthermore, the ON/OFF button controls the gauge's power status, turning it on by pressing it once, off by long pressing, and toggling its state when already on..
Scene 5 (2m 4s)
[Audio] The APG Series offers high-accuracy digital pressure indicators with selectable accuracies of 0.1%, 0.05%, and 0.02% FS, covering ranges from -1 to 1000 bar. The device features 14 pressure units, zero, tare, and peak hold functions. It is ideal for calibrating pressure gauges, transducers, and switches. The APG Series is available as a standalone gauge or integrated into pneumatic systems. It has a pressure port with a 1/4 inch BSP (F) connection and a fine adjustment vernier for precision and accuracy. The device also comes with an adjustable stroke nut for customizable adjustments. The APG Series is designed to provide a complete pressure calibration solution..
Scene 6 (2m 53s)
[Audio] To ensure accurate results, it's crucial to establish a secure connection between the hand pump and the pressure gauge and calibration device. Attach the master pressure gauge to the top port of the hand pump using a swivel adapter, ensuring the O-ring is present within the adapter to prevent pressure leaks. Then, connect the pressure gauge to the ¼" BSP male port of the hand pump. Next, link the device under calibration to the secondary port of the hand pump via a 4 mm hose fitted with a ¼" BSP female connector, verifying that all connections are snug and leak-free to maintain system integrity throughout the calibration process..
Scene 7 (3m 34s)
[Audio] To ensure accurate results, we must prepare the system by tightening all threaded connections using the right tools. We also need to confirm that there are no leaks in the system to prevent pressure loss during operation. Next, we identify and locate the pressure selector switch, rotating the knob clockwise until it reaches its end stop to set the unit into Pressure Mode. We must verify that the correct mode is selected and the knob is fully rotated before proceeding..
