1 ALIGNMENT OPTIONS FOR SIGNATURE BRIDGE.
Scene 2 (6s)
2 Summary • Main alignment is proposed almost parallel to Prakasham barrage. • Vijayawada Side is planned to take up in two phases • Phase 1: Merging with At-Grade Bund road • Phase 2 : Connecting NH65 using Elevated Roundabout • Two options are shortlisted for merging towards Amaravati side • Option 1: Keeping round about partially in river and connecting sitanagaram directly • Option 2: Moving round about towards ghatside.
Scene 3 (25s)
3 Vijayawada Side Phase 1 • Vijayawada side out of total 6 lanes, 2 lanes (1 LHS + 1 RHS) arms are separated and merged along at grade Bund roads. • Remaining 4 lanes are merged with service road at mouth of existing VUP (2 cell) on NH 65. • As the level of existing service road at VUP is RL +22.2 and proposed bridge FRL is above +26m, very steep gradient is required (approximately 3.75% which is closer to exceptional gradient of 4%). • Further vertical clearance above HFL could not be satisfied in starting 40 to 60m of bridge (needs special approval from irrigation department). • Requires signalized junction development at grade.
Scene 4 (52s)
4 Vijayawada Side Phase 1 RAMP TOWARDS KANAKADURGA TEMLE RAMP FROM PNBS AMARAVATHI MERGING AT GRADE AMARAVATHI.
Scene 5 (59s)
5 Vijayawada Side Phase 1 ELEVATION TOWARDS VIJAYAWADA SIDE VUP SERVICE ROAD MERGING LOCATION.
Scene 6 (1m 7s)
6 Vijayawada Side Phase 1 (Cont.) • Pros: • Quick to construct • Relatively cheaper • Requires minimal coordination with other agencies • Cons: • Acts as quick-fix solution like replacement to prakasam barrage road • Do not solve the traffic congestion issues completely • The arrived gradient on viajaywada side is relatively steeper for daily maneouvering along this gradient, • The Q at the junction get accumulate on to the bridge due to proximately of the junction to the bridge proper during the peak hours(will be assessed through traffic studies and simulation) • They could be possibiltes of vehicles collusion at the junction..
Scene 7 (1m 31s)
7 Vijayawada Side Phase 2 • To make the solution complete, phase 2 is proposed in which a elevated roundabout is developed connecting existing NH65. • Part of bridge that was constructed (first 180m towards Vijayawada side shall be partially demolished for connection to NH 65 as part of the rotary. • Additional ramp for connection towards Kaleshwara rao market can be taken up..
Scene 8 (1m 49s)
8 Vijayawada Side Phase 2 (Cont.) ADDIRIONAL BRIDGE CROSSING CANAL RAMP FROM PNBS AMARAVATHI MERGING AT ELEVATED ROUNDABOUT RAMP TOWARDS KANAKADURGA TEMLE.
Scene 9 (1m 57s)
9 Vijayawada Side Phase 2 (Cont.) • Reduces the conflict points by providing comprehensive solution to address all the traffic movements • Avoids signalized junction • No issues with vertical clearance of structure above HFL • Gradient issues are solved • Scope for landscaping of Roundabout • Need coordination with NHAI/R&B & VMC • Need temporary blockage of certain traffic which takes time during construction. • Requires demolition of part of bride (NH-65 & 180m the proposed bridge) if planned to take up in phased manner.
Scene 10 (2m 19s)
10 Amaravati Side Option 1 • Round about partially in river • Direct connection to Sitanagaram • Arm connecting round about towards Amaravati side is taken adjacent to Sitanagaram road • As the FRL at round about is RL+26 and same at Mangalagiri road is RL+25, elevated corridor with moderate slope is proposed • Existing road is retained providing access to residents of sitanagaram • Length of Stay cable bridge is 800m • In future, possibility of connecting up to amravathi Trunk roads.
Scene 11 (2m 39s)
11 Amaravati Side Option 1 • Pros : • Will not obstruct ghats • Provides all-whether connectivity towards sityanagaram side • Cons : • As the roundabout falls partially in river obstruction of waterway is relatively higher.
Scene 12 (2m 51s)
12 Amaravati Side Option 2 • Round about is shifted towards ghat side • Sitanagaram connection is proposed along ghat • Arm connecting round about towards Amaravati side is taken adjacent to Sitanagaram road • As the FRL at round about is RL+26 and same at Mangalagiri road is RL+25, elevated corridor with moderate slope is proposed • Existing road is retained providing access to residents of sitanagaram • Length of Stay cable bridge is 900m • Service road between elevated road and hill must be planned to cater traffic movement towards Sitanagaram side from Mangalagiri.
Scene 13 (3m 14s)
13 Amaravati Side Option 2 • Pros: • Kept far away from river causing less obstruction to water flow • There is provision for landscaping and beautification with public access • Cons: • Slightly costlier compared to option 1 as length of structure increased by about 120m • As round about falls on bank, it will obstruct the existing ghat to a substantial extent.
Scene 14 (3m 30s)
14 TYPOLOGY AND AESTHETICS PROPOSALS (CONCEPTUAL).
Scene 15 (3m 37s)
15 Design Evolution: Twin Cable stay.
Scene 16 (3m 43s)
16 Design Evolution: Twin Cable stay.
Scene 17 (3m 50s)
17 Design Evolution: Twin Cable stay.
Scene 18 (3m 56s)
18 Design Evolution: Twin Cable stay.
Scene 19 (4m 3s)
19 Design Evolution: Twin Cable stay.
Scene 20 (4m 9s)
20 Design Evolution: Twin Cable stay.
Scene 21 (4m 16s)
21 Design Evolution: Sculpture – Farmer Contribution A large stylized hand emerging from the ground, gently holding or supporting wheat/rice/paddy stalks. Concept: “The hands that feed the nation.” • 1 large central hand, approximately 6–8 m high • 3–5 stylized crop stalks emerging from the palm • Stalks progressively increasing in height • Stainless steel / bronze / weathered metal finish • Circular low plinth integrated into the landscape • Low grasses and seasonal flowering planting around the base The hand should be sculptural and simplified, rather than anatomically realistic..
Scene 22 (4m 39s)
22 Design Evolution: Sculpture Options Ref Image 01 Ref Image 02 Ref Image 03.
Scene 23 (4m 47s)
23 Design Evolution: Sculpture Lighting Options Ref Image 01 Ref Image 02 Ref Image 03 Ref Image 04.
Scene 24 (4m 55s)
24 Design Evolution: Twin Cable stay.
Scene 25 (5m 2s)
25 Design Evolution: Side Median + Footpath.
Scene 26 (5m 9s)
26 Design Evolution: Twin Cable stay Ixora varieties @ 0.60 m c/c Raphis palm@ 0.60 m c/c.
Scene 27 (5m 18s)
27 Design Evolution: Median Options.
Scene 28 (5m 24s)
28 Design Evolution: Central Deck Area.
Scene 29 (5m 31s)
29 Design Evolution: Twin Cable stay.
Scene 30 (5m 37s)
30 Design Evolution: Twin Cable stay.
Scene 31 (5m 44s)
31 Design Evolution: Twin Cable stay.
