Description: Aerial Design reference is in Section 6 of Access Design Guideline Distributed Splitter Locations Architecture.

[Audio] Aerial Design reference is in Section 6 of Access Design Guideline Distributed Splitter Locations Architecture.

Scene 1

Aerial Design reference is in Section 6 of Access Design Guideline Distributed Splitter Locations Architecture

[image] Technical Specifications
Guidelines
Name
Design Guidelines
Implementation Guidelines
Others
folders

[image] Technical Specifica tions
Guidelines Design Guidelines
Name •
Access Design Guideline Distributed Splitter Locations Architecture.pdf
Access Design Guidelines Centralized Splitting Architecture.pdf
NW Survey and Civil Design Guidelines.pdf
Outside Plant Long Distance and Junction.pdf

[image] 6.
Aerial Design
Rule 59: Reuse of existing poles
The OSP Designer shall optimize the number of poles. Existing poles shall be used to extend the
network of Feeder, Sub-Feeder/'Distribution and Drops. It is not allowed to dedicate a pole for a
network section. The existing poles shall be surveyed and verified on field. The OSP Designer
shall not rely on records alone when designing a network using existing poles

For online link, always refer to the latest announcement by OSP Standard & Specification

[Audio] Some areas where underground network is not feasible for implementation aerial network shall be considered..

Scene 2

Aerial Design : Section 6 of Access Design Guideline Distributed Splitter Locations Architecture

[image] -30 ¯
Figure 6-1: Drop Span Length

[image] o
Drop to Building (designed
but not implemented)
Poles without drop cables
(Designed and Implemented)
Figure 6-2 Drop Pole Location

Some areas where underground network is not feasible for implementation aerial network shall be considered.
