Scene 1 (0s)

MODULE 1 Standard HPMT Product Introduction HPMT Catalogue E Reading Industry Application.

Scene 2 (8s)

Objective: From what HPMT’s Standard Product List and Category, learnt for what was the general cutting tools grouping and difference. From the step by step instruction provided, understand how end user would search for tool fitting their requirement. From the description, standard and technical information explained alongside each HPMT Product, learnt for the relationship in between each features and the applications..

Scene 3 (27s)

PRODUCT SERIES TRAINING. TOOL TYPE AND CONFIGURATION.

Scene 4 (43s)

ALU LINE NiTiC030 OPTIMUM Non Ferrous Metal EZ LINE - ENDMILL s 35 HRC SE30 s 35 HRC s 45 HRC s 45 HRC SE45 36 - so HRC SE 45X S 52 HRC NiTiCo 45 36 - 52 HRC SE 60 53-68 HRC SE 60X 40-60 HRC DWO - SE 70 50-70 HRC SE GR -plastic & Graphite TE45 s 45 HRC PLUNGE- MILL S 45 HRC THREAD MILL THREAD MILL.

Scene 5 (1m 1s)

BALLNOSE BN 30 36-50 53-æ BN 45 BN60 BN 60X 40-60 HRC DM70 - BN 70 50-70 BNGR Thermo s 35 HRC -plastic & HRC.

Scene 6 (1m 10s)

*HRC – Hardness Rockwell C, the measurement method for material hardness *HRC higher, material is harder.

Scene 7 (1m 19s)

ALUMINIUM CAST IRON STEEL & PREHARDENED STAINLESS STEEL SUPER ALLOY HARDENED STEEL THERMOPLASTIC & GRAPHITE.

Scene 8 (1m 33s)

*TBU. SAMPLE MATERIAL IN ISO GROUPING. MATERIAL APPENDIX Material HPMT NI Description Aluminium alloys Aluminium alloys Aluminium alloys Properties Si 3.0255 3.0515 3.0517 3.1255 3.1655 3.2161 3.2341 3.3206 33210 3.3315 3.4335 3.4365 3.5103 3.5612 3.5812 3_2315 3.2381 3.2382 DIN A199S AIMn1 AIMn1Cu AICuSiMn AICuBiPb G-AlSi8Cu3 G-AlSiSMg AMgSiO.5 AIMgSiO.7 AIMg1 AIZn4_5Mg1 AIZnMgCu1S G-Mgsgznezrl G-MgA16Zn G-MgA18Zn AIMgSi1 G-AISi10Mg GD-AISi12 UNI 3599 AFNOR A-511050A A-MI/3003 A-IJ4SG/2014 A-U5PbBi/2011 A-S7G A-GS/6060 A-GSIJC/6061 A-CO.6 A-Z5C/7020 A-Z5CU/7075 ZREI G-A6-Z1 (G-A7-Z1) A-SGMO_7/6082 A-SIOG AISI/SAE/ASTM A380 826 AMS 4442 AZ61A AZ80A BBS A413.2 B390_O XHPMT Common Name (A1050) A3003 A2011 AC4C (A6063) A7075 ADC14.

Scene 9 (2m 3s)

Refer to Page 41, Catalogue E (Summary). COATING.

Scene 10 (2m 11s)

COATING. •c 62 52 w i m 80 to —t dry. Refer to Page 41, Catalogue E (Simple).

Scene 11 (2m 21s)

CARBIDE GRADE. Micro Grain Carbide 90% wc 6% co 91.5 HRA 0.7 micron Grain Sze ISO Grade KIO/K30 Ultra Fine Carbide 86.5% wc 12% co 93.0±0.5 HRA 0.5 micron Grain Size ISO Grade KIO/K40 Tool Material (Tungsten Carbide) Micro Grain Carbide 90% wc co 92.0±0.5 HRA 0.8 micron Grain Size ISO Grade KIO/K30 Ultra Fine Carbide 91% wc 9% co 93.9 HRA 0.2 micron Grain Size ISO Grade K05/KIO Micro Grain Carbide 93.5% wc co 93.5 HRA 0.6 micron Grain Size ISO Grade K05/KIO.

Scene 12 (2m 48s)

CARBIDE GRADE (Summary). Property MG UF UF+ Grain Size, µm Big Medium Small TRS, MPa Tough Medium Brittle Hardness, HRA Soft Medium Hard Application Soft Material General Application Hardened Steel Picture.

Scene 13 (3m 1s)

TUTORIAL TO SELECT TOOLS. Refer to Page 10, Catalogue E.

Scene 14 (3m 21s)

AL SE VLOTES. CNC Repeatedly: The workpiece’s dimension when being repeatedly cut at same location will still remained within the said tolerance..

Scene 15 (3m 52s)

Refer to Pages 513, Catalogue E. Cutting Parameter Calculations.

Scene 16 (4m 4s)

Refer to Pages 530, Catalogue E. Tolerance Table.

Scene 17 (4m 36s)

Refer Pages 524 ~ 530. Description Of The Icons (Eng) IHPMT.

Scene 18 (4m 51s)

Application and Industry. Mould & Die Aerospace Automotive Medical/Dental Industry Semiconductor.

Scene 19 (5m 0s)

Application and Industry. Mould & Die Plastic Mold Plastic Mold Product 3C product Car interior parts Mould material (Hardness 40 ~ 52 HRC): S136 8407 2083 (1.2083, X40Cr14) 2738 (1.2738, 40CrMnNiMo8-6-4) NAK80 PS, AS, PE, PP Nylon, PC, ABS, POM, PET, PBT.

Scene 20 (5m 19s)

Application and Industry. Mould & Die Plastic Mold TV Remote Controller Mold Material : S136 (52 HRC) Coolant : Dry cut with air blow.

Scene 21 (6m 7s)

Application and Industry. Mould & Die Plastic Mold Silicone & Rubber Molding Silicone & Rubber Molding Product Household product & Car interior parts Mold material : NAK80 P20 (1.2311, 40CrMnNiMo7) S45C (1.1191, CK45, some) S60C (1.1221, CK60, some).

Scene 22 (6m 21s)

Application and Industry. Mould & Die Plastic Mold Silicone & Rubber Molding Aluminium Die Casting.

Scene 23 (6m 47s)

Application and Industry. Mould & Die Plastic Mold Silicone & Rubber Molding Aluminium Mold Aluminium Die Casting Product Aluminium Aluminium magnesium Die material Main material is FDC, hardness not more than 48 HRC..

Scene 24 (7m 2s)

Application and Industry. Mould & Die Plastic Mold Silicone & Rubber Molding Aluminium Die Casting Automotive Mould Stamping process use die material Die material (56 ~ 62 HRC) : DC53 (improved ver. SKD11) SKD61 (1.2344, X40CrMoV5-1) SKD11 (1.2379, X153CrMo12) Cr12MoV (same as SKD11, 1.2601 X165CrMoV12) 1.2379 (SKD11, Cr12MoV, D2).

Scene 25 (7m 19s)

Application and Industry. Mould & Die Plastic Mold Silicone & Rubber Molding Aluminium Die Casting Automotive Mould Stamping process.

Scene 26 (7m 30s)

Application and Industry. Mould & Die Plastic Mold Silicone & Rubber Molding Aluminium Die Casting Automotive Mould Stamping process Automotive Headlamp Mould Translucent plastic mould material Mould material (52 ~ 56 HRC) : Maini focus on micro ballnose & taper neck ballnose R0.05 ~ R0.3 mm.

Scene 27 (7m 44s)

Application and Industry. Mould & Die Plastic Mould Silicone & Rubber Molding Aluminium Die Casting Automotive Mould Glass Mould.

Scene 28 (7m 53s)

Application and Industry. Mould & Die Plastic Mould Silicone & Rubber Molding Aluminium Die Casting Automotive Mould Glass Mould Spanner Forging Die.

Scene 29 (8m 3s)

Application and Industry. Mould & Die Plastic Mould Silicone & Rubber Molding Aluminium Die Casting Automotive Mould Glass Mould Spanner Forging Die Connector & Adaptor Mould Industry Telecommunication Automotive Precision industry Material Material requirement is 52 HRC above Mainly using small tool, deep groove cutting tool Very high precision requirement..

Scene 30 (8m 19s)

Application and Industry. PERFORMANCE SE 60X BN 60X DR S DR ALU AL SE BASIC SE 45 SE 60 SE GR BN 45 BN 60 BN GR DR 45 DR 60 TE 45.

Scene 31 (8m 36s)

Application and Industry. Aerospace Aerospace Product Made in Malaysia.

Scene 32 (8m 44s)

Application and Industry. Aerospace Aerospace Product Made in Malaysia Airplane Engine, Engine Fan Case, turbine blade.

Scene 33 (8m 54s)

Application and Industry. Aerospace Aerospace Product Made in Malaysia Airplane Engine, Engine Fan Case, turbine blade Turbine Blade Machining.

Scene 34 (9m 12s)

Application and Industry. Aerospace Aerospace Product Made in Malaysia Airplane Engine, Engine Fan Case, turbine blade Turbine Blade Machining Fan Case Machining.

Scene 35 (10m 7s)

Application and Industry. Aerospace Aerospace Product Made in Malaysia Airplane Engine, Engine Fan Case, turbine blade Turbine Blade Machining Fan Case Machining Spirit AeroSystems (In Malaysia).

Scene 36 (10m 24s)

Application and Industry. Aerospace Aerospace Product Made in Malaysia Airplane Engine, Engine Fan Case, turbine blade Turbine Blade Machining Fan Case Machining Spirit AeroSystems (Boeing).

Scene 37 (10m 35s)

Application and Industry. Aerospace Aerospace Product Made in Malaysia Airplane Engine, Engine Fan Case, turbine blade Turbine Blade Machining Fan Case Machining Spirit AeroSystems (Airbus).

Scene 38 (10m 46s)

Application and Industry. Aerospace Aerospace Product Made in Malaysia Airplane Engine, Engine Fan Case, turbine blade Turbine Blade Machining Fan Case Machining Spirit AeroSystems (Airbus) Others.

Scene 39 (11m 1s)

Application and Industry. Aerospace Aerospace Product Made in Malaysia Airplane Engine, Engine Fan Case, turbine blade Turbine Blade Machining Fan Case Machining Spirit AeroSystems Common material & Customer Tools.

Scene 40 (11m 18s)

Application and Industry. Automotive Turbocharger (Taper Ballnose).

Scene 41 (11m 25s)

Application and Industry. Automotive Turbocharger Impeller (Taper Ballnose).

Scene 42 (11m 46s)

Application and Industry. Automotive Turbocharger Impeller Engine Knuckle.

Scene 43 (11m 53s)

Application and Industry. Automotive Turbocharger Impeller Engine Connecting Rod (Step Drill).

Scene 44 (12m 2s)

Application and Industry. Automotive Turbocharger Impeller Engine Connecting Rod (Step Drill) Common material & Customer Tools.

Scene 45 (12m 16s)

Application and Industry. Medical & Dental Dental industry common material Cobalt Chrome / Titanium PMMA Zirconium Oxide.

Scene 46 (12m 31s)

Application and Industry. Medical & Dental Dental industry common material.

Scene 47 (12m 58s)

Application and Industry. Medical & Dental Dental implant.

Scene 48 (13m 4s)

Application and Industry. Medical & Dental Dental implant Crown Machining (Artificial Teeth).

Scene 49 (14m 4s)

Application and Industry. Medical & Dental Dental implant Crown Machining (Artificial Teeth) Common material & Customer Tools.

Scene 50 (14m 17s)

Application and Industry. Semiconductor Semiconductor products Effectors, jig fixtures, and other semiconductor manufacturing components Common material & customer tools Material Monocrystalline silicon (c-Si) Quartz and Fused Silica (SiO2) HRC45~60 hardened steel High precision Mostly are micro tools.
