廃棄物処理装置

Waste treatment equipment. High temperature / pressurized water decomposition plant with drying function.

[image]. Basic Business Concept (Concept). By introducing new environmental improvement technology, we will create a better global environment for our descendants.

-3-. What is organic matter and exposed matter. "Organic substances" mainly refer to substances (compounds) containing "carbon (C)". Substances made in the body of humans and living things are "organic matter", and things that are considered "living things" such as humans, fish, and animals are "organic matter". Substances made in the bodies of living organisms, including humans, fall under the category of “organic matter.” For example, carbohydrates, proteins, and fats are also “organic matter.” “Organic matter” exists even in non-living things. A good example of this is plastic. "Plastic" is a material made artificially and has nothing to do with living things, but it corresponds to "organic matter". Food waste, sludge, petroleum and coal are also examples of "organic matter".Typical examples of "inorganic substances" include water, carbon dioxide, and carbon monoxide. Carbon dioxide and carbon monoxide are substances that are classified as "inorganic substances" as exceptions among those containing carbon (C). There are also"inorganic substances" in the air, such as oxygen, nitrogen, and hydrogen. Glass, metals such as iron and aluminum, and stones are also a kind of "inorganic matter." Ores (minerals from which metals can be extracted) generally fall under the category of “inorganic substances,” but some “organic minerals” also exist..

35 30 25 20 I.d 15 10 iii(t upk i#U.g'L 100 374•c 400 500.

Effort to recycle easily by sorting and mixing processed products and you can expect profit on sales of processed products after hydrolysis treatment By decomposing and treating food residues and waste, it becomes a high quality product as feed and fertilizer. The sterilization technique by high temperature / high pressure treatment makes it possible to prevent transmission of mad cow disease · avian influenz In sewer sludge disposal, treatment turns it into high quality organic fertilizer.. With both mixing of treated matter and drying on the same machine the treated waste is reborn as fuel. It can also be used for condensation processing and concentration of foods, using only the drying process..

＊Conventional subcritical processor ＊ Clean Earth (subcritical processing machine, drying possibl.

テキスト, 地図 が含まれている画像 自動的に生成された説明. [image]. [image].

70. -8-. 1.Molecular state before substance treatment (pressure 1 kg/cm², room temperature).

incineration. Hydrolysis treatment. Comparison of general waste treatment and pressurized water decomposition drying treatment.

Salt damage caused by composting of food residue The challenge when using food residue as fertilizer is to remove salt contained in food. Because it can not be decomposed by microorganisms, there is a danger of accumulating salt damage caused by continued use of salt-containing fertilizer..

The goal is to introduce equipment cost, running cost and maintenance cost at a cheaper facility cost than incinerator method without imposing excessive burden It can decompose fungi, viruses and bacteria by pressurized water decomposition of organic matter, detoxify it, and produce a safe product.

処理物種別. solid fuel. ＊. List of objects to be processed.

1. Processable objects. Processed matter. organic matter.

＊Old model aircraft ssure vapor with high pressure steam of 2 to 2.5 Mpa is placed in the container As it blows directly, the moisture content of the treated matter rises with steam condensate in the vessel, and after being discharged as a slurry (sludge), separation process and drying process of liquid / granule are necessary. ＊New model (with drying function) Since steam is not contained in the vessel and heated by the medium oil heat from the outside, there is no increase in moisture content than the moisture content of the input material, and it is dried under reduced pressure by utilizing residual heat after treatment, so that the running cost can be reduced..

It is a compact fertilizer that can be done in a small facility, with no generation of dioxin, in only 40 minutes (not including drying stroke time). This volumetric fertilizing apparatus is equipped with general combustible waste, Fiber waste, waste paint, plastic bottle It is also possible to treat combustible materials such as sewage sludge and incineration ash Generate steam in the waste container, stirrer and container to humidify and pressurize It consists of boilers, etc., and reduces waste to volume fertilizer Steam generated is saturated steam.

Conventional technology is incineration in general. However, if incineration is carried out within the range of 400 to 800 ° C, a large amount of dioxin is generated, so, in the newly established incineration facility, we burn waste at a temperature above 800 C to prevent the generation of dioxin. Conventional incineration treatment is a waste of energy, capital expenditure, processing time and increased expense..

For this reason, a large amount of waste was mainly used in large facilities. This compact facility reduces the volume of waste fertilizer while preventing the generation of dioxins. We have developed a method for reducing volumetric fertilizer treatment. Waste is reduced in volume by pressure decomposition and hydrolysis, and special stirring. By doing so, electrostatic plasma is generated by steam friction. The static electricity generated by this friction and the static electricity accumulated from the floating water droplets as the plasma flows through the inside of the waste, further volume reduction treatment is incurred. (The rotation speed of the stirring means is 3 to 8 rpm / min.) In addition, if aerial discharge occurs due to static electricity generated, and in the case of a load on the apparatus, it is also possible to suppress the generation of static electricity by introducing a conductive substance such as carbon powder. If you add a water-absorbing substance such as sawdust, it will absorb wasteful moisture and further increase the generation of static electricity and promote processing. In about 40 minutes, 50 to 70% of the waste can be reduced to fertilizer. When static electricity generated is small, an insulating substance which easily generates static electricity with waste can promote it..

・Main body container ・Inverted stirrer ・Heat oil boiler ・Cradle ・Decelerator ・Axis of rotation ・Inlet ・Outlet ・Steam supply port ・Adjusting machine ・Pneumatic valve ・ Negative pressure pump for drying ・Steam exhaust pipe ・Deodorizer ・Tubes containing heat transfer oil ・Safety relief pipe ・Heat oil tank ・Support shaft ・Stirring blade.

[image] NII,NOV. · Resource reuse · Environment conservation · Stability of agriculture · Safety and peace of mind of agricultural products A society that can satisfy everything It will be realized..

Hotel. Local governments, citizens, industry,. The process of realizing a sustainable recycling-based society.

[image]. 【waste tire boiler】. 【A heavy oil boiler】.

①B-1Waste storage pit more input. ②(2) Magnetic material separated by magnetic separator.

キッチンの一角 低い精度で自動的に生成された説明. 屋内, 建物, テーブル, 座る が含まれている画像 自動的に生成された説明.
