[Virtual Presenter] Welcome everyone to our presentation about this revolutionary, high-performance 65’’ Frame Type Hydraulic Press. It provides users with advanced technology, making the process of container shaping easier and more efficient. Its two independent loader mechanisms, four squeezing cylinders per cavity, motorized mold height adjustment and maximum container/mold outside diameter of 1650mm will prove to be extremely useful for your operations. Let's take a closer look..

[Audio] This hydraulic press has a 65-inch frame type and is designed for efficiency and power. It is equipped with a control panel for the upper body loader, along with a lower body up-down cylinder, a squeeze cylinder, a side wall, and a centerpost valve group. An unloader is also included for quick and easy output. The combination of all these features results in optimal efficiency..

[Audio] The hydraulic press has a 65” frame type and is equipped with two independent loader mechanisms, one each on the right and left side. The chuck group of the loader has eight paddles, allowing a vertical movement range from 16” to 24.5”. It is actuated by a hydraulic cylinder and has an LVDT for precise positioning..

[Audio] This hydraulic press is equipped with two independent fork-type unloaders at the back for faster and easier operation. It has robust design and construction, making it suitable for heavy duty applications, and safety features like an emergency stop button to ensure maximum operator safety. It also has an intuitive control panel for precise operation, making it reliable, accurate and precise - an invaluable asset for any production line..

[Audio] Engineered with utmost precision, this 65’’ Frame Type Hydraulic Press delivers best system performance. It features a rib type or Bago-matic type centerpost mechanism, which is ready to work with steam or hot water. Additionally, the hydraulic cylinder of top clamp ring is equipped with an LVDT to precisely control the position of the bladder. This press can provide optimal system performance..

[Audio] This 65’’ Frame Type Hydraulic Press has four squeezing cylinders that enable it to generate up to 5000 kN of pressure per cavity. This makes it possible to provide consistent and uniform force distribution during the squeezing process, ensuring superior accuracy and quality..

[Audio] No matter what your requirements, this machine can easily adapt and deliver, offering versatility in terms of mold height adjustment with a range of 350mm to 650mm and a maximum container/mold outside diameter of 1650mm..

[Audio] Designed and constructed with the highest standards, the 65” Frame Type Hydraulic Press has been crafted with every detail taken into account during the design process. The main body has been tested with FEA under maximum load, and critical loading points have been determined and necessary points reinforced or redesigned according to FEA results. All welders involved in its manufacturing have been certified by TUV, and all steel plates used in its construction have passed the ultrasonic test before assembly, even if they already have certificates. We take great pride in this product and its quality..
