Scene 1 (0s)

Madhya Pradesh Metro Rail Co. Limited MPMRCL, Undertaking of GoMP 24 th March 2019.

Scene 2 (10s)

2. Bhopal Sanctioned Cost. Particulars Line 2 Line 5 Project Cost 1 Alignment & Formation 702.26 384.65 1,086.91 2 Station Building Including Civil Works, EM, ECS, TVS, Lift, Escalators & Architectural Finishes Etc. - Elevated (14 + 13 station) 375.93 349.07 725.00 3 Station Building Including Civil Works, EM, ECS, TVS, Lift, Escalators & Architectural Finishes Etc. - Underground (2 + 0 Stations) 370.37 0.00 370.37 4 Station Building Including Civil Works, EM, ECS, TVS, Lift, Escalators & Architectural Finishes Etc. - Type 1 (0 + 1 Station) 0.00 13.43 13.43 5 Depot including civil, EM, Machinery & Plants, General Works 178.70 0.00 178.70 6 Permanent Way (Track) 111.16 95.01 206.17 7 Traction & Power Supply 187.07 159.13 346.20 8 Signaling and Telecommunications Works (Communication +AFC +PSD) 378.39 325.48 703.87 9 Misc. (Including multimodal Cost of INR 30 crores) 86.34 73.44 159.78 10 Metro Office Building & Equipment 168.52 0.00 168.52 11 Rolling Stock 401.85 373.15 775.00 12 Total cost at March 2018 price level except land, Rehabilitation and Resettlement (R&R) and Central and State taxes 2,960.59 1,773.36 4,733.95 13 General Charges @ 5% on All Components 148.03 88.67 236.70 14 Contingency @ 3% on All Components 88.82 53.20 142.02 15 Total cost including General charges and contingencies (if any) (excluding Taxes, Land and R&R Cost) at March 2018 price level 3,197.44 1,915.23 5,112.67 16 Escalation @ 5% p.a. (Without Considering Contingency) 308.93 195.60 504.53 17 Total cost with escalation (excluding Taxes, Land and R&R Cost) 3,506.37 2,110.83 5,617.20 18 Central Taxes including custom duty at March 2018 price level 357.91 229.25 587.16 19 Central Taxes with escalation @ 5% 403.20 241.82 645.02 20 Total Cost with Central Taxes excluding Land, R&R and State taxes at March 2018 price level 3,555.35 2,144.48 5,699.83 21 Total cost with Central taxes with escalation @ 5% pa. excluding Land, R&R and State taxes 3,909.57 2,352.65 6,262.22 22 Land 261.92 50.31 312.23 23 R&R 0.00 0.00 0.00 24 General Charges @ 5% 0.00 0.00 0.00 25 Contingency @ 3% 7.86 1.51 9.37 26 Total of Land and R&R (excluding escalation) 269.78 51.82 321.60 27 Escalation@5%p.a. (wherever applicable) 0.00 0.00 0.00 28 Total of Land and R&R Hutments 269.78 51.82 321.60 29 State Taxes at March 18 price level 143.43 80.51 223.94 30 State taxes with escalation @ 5% p.a. 157.57 88.44 246.01 31 Total Cost with Central & State Taxes including Land and R&R costs at March 2018 price level 3,968.55 2,276.82 6,245.36 32 Interest During Construction 69.66 41.92 111.57 33 Total Cost with Central & State Taxes with 5% escalation including Land and R&R 4,406.57 2,534.83 6,941.39.

Scene 3 (1m 16s)

3. Bhopal Financing Plan. Source Amount (Rs. in Cr.) GoI Equity 841.93 GoI Subordinate Debt for Central Taxes (50% of Central taxes) 322.51 GoMP Equity 841.93 GoMP Subordinate Debt for Central Taxes (50% of Central taxes) 322.51 Loan from EIB 3493.34 Total Cost Excluding Land, R&R and PPP Components 5822.22 PPP Components 440.00 Total 6262.22 GoMP SD for Land and R&R 321.60 State Taxes (SGST) to be borne by GoMP 246.01 IDC to be borne by GoMP 111.57 Total Completion Cost 6941.40.

Scene 4 (1m 52s)

4. Bhopal Tender Packages. Contract Package NIT Date Construction Start Date Construction Completion Date Duration (Months) BH 01/01 AIIMS to Subhash Nagar Viaduct 23-May-18 15-Nov-18 14-Feb-21 27 BH 01/02 AIIMS to Subhash Nagar Stations 31-May-19 01-Oct-19 30-Sep-22 36 BH 01/03 Subhash Nagar to Karond Viaduct, Aishbagh to Karon Circle Stations 31-May-19 01-Oct-19 30-Sep-22 36 BI 01/01 Geotech Site Investigation UG & Depots (BH & IN) 25-Jan-19 15-Apr-19 15-Aug-19 4 BH 01/04 Aishbagh Ramp to Nawab Cemetery UG & Bhopal Railway St & Nandra Bus St Stations 15-Jun-19 15-Oct-19 15-Dec-22 38 BH 01/05 Bhadbhada Square to Ratnagiri Tiraha Viaduct & Stations 31-May-19 01-Jul-19 30-Jun-22 36 BI 01/04 Depot DDC (BH & IN) 01-Aug-19 15-Oct-19 15-Feb-20 4 BH 01/06 Depot Civil/MEP/Architecture 01-Mar-20 01-Jun-20 31-May-22 24 BH 01/07 Depot Equipment 01-Jun-20 01-Oct-20 31-Oct-22 25 BH 01/08 Track 01-Jul-19 01-Oct-19 30-Sep-22 36 BH 01/09 Signalling & Telecommunications 01-Aug-19 01-Nov-19 31-Oct-22 36 BI 01/05 Power Simulation Study (BH & IN) 01-Jun-19 31-Aug-19 19-Sep-19 3 BH 01/10 Traction Power 01-Oct-19 01-Jan-20 30-Sep-22 33 BH 01/11 Rolling Stock 02-Sep-19 01-Jan-20 31-Dec-22 36 BH 01/12 AFC 01-Oct-19 01-Jan-20 30-Sep-22 33 BH 01/13 PSD 01-Oct-19 01-Jan-20 30-Sep-22 33 BH 01/14 VHTS 01-Oct-19 01-Jan-20 30-Sep-22 33.

Scene 5 (2m 58s)

5. EIB Visit. A Fact Finding Mission was held with EIB on 6 th to 8 th March EIB confirmed they are willing to fund both Civil, Depot (civil and equipment) and Systems (Power & Track) packages providing there is no “Make in India” restriction. EIB are willing to finance 90% of Tender Package costs for civil and supply/fix & 100% where material supply all excluding GST. EIB are considering funding Rs 3,200 Cr..

Scene 6 (3m 19s)

6. EIB Visit – Package Funding as discussed by EIB.

Scene 7 (4m 27s)

7. EIB Visit - Documentation Requested. Document Status Ready By 1 Supplementary DPR Available 2 MPMRCL-GC presentation to EIB Available 3 MoU GoMP-GoI Draft 4 Alignment Map, KMZ file Available 5 Project Investment Cost Table 1 st Draft 31-Mar-19 6 Annual Project Expenditure 1 st Draft 31-Mar-19 7 Policy Cost Breakdown, Climate, Security & Gender 1 st Draft 31-Mar-19 8 Climate Change Adaptation 1 st Draft 31-Mar-19 9 Procurement Plan Table 1 st Draft 31-Mar-19 10 PIU-GC Org Chart, Tasks & Responsibilities 1 st Draft 31-Mar-19 11 PIU-GC Procurement Process & Manual 1 st Draft 31-Mar-19 12 RPF, Screening & Categorization 1 st Draft 31-Mar-19 13 RAP(s), SIA & Engagement Roadmap 1 st Draft 31-Mar-19 14 MPMRCL Gender Policy 1 st Draft 31-Mar-19 15 EIRR & FIRR 1 st Draft 31-Mar-19 16 Project Technical Description 1 st Draft 31-Mar-19.

Scene 8 (5m 1s)

8. EIB Visit – Procurement NIT to Award Timeline.

Scene 9 (5m 56s)

9. EIB Visit – Procurement NIT to Award Timeline.

Scene 10 (7m 1s)

10. Indore Sanctioned Cost. Particulars Project Cost 1 Alignment & Formation 1,206.61 2 Station Building Including Civil Works, EM, ECS, TVS, Lift, Escalators & Architectural Finishes Etc. - Elevated (14 + 13 station) 537.04 3 Station Building Including Civil Works, EM, ECS, TVS, Lift, Escalators & Architectural Finishes Etc. - Underground (2 + 0 Stations) 740.74 4 Station Building Including Civil Works, EM, ECS, TVS, Lift, Escalators & Architectural Finishes Etc. - Type 1 (0 + 1 Station) 122.22 5 Depot including civil, EM, Machinery & Plants, General Works 178.70 6 Permanent Way (Track) 225.63 7 Traction & Power Supply 379.69 8 Signaling and Telecommunications Works (Communication +AFC +PSD) 745.08 9 Misc. (Including multimodal Cost of INR 30 crores) 175.24 10 Metro Office Building & Equipment 101.11 11 Rolling Stock 717.59 12 Total cost at March 2018 price level except land, Rehabilitation and Resettlement (R&R) and Central and State taxes 5,129.66 13 General Charges @ 5% on All Components 256.48 14 Contingency @ 3% on All Components 153.90 15 Total cost including General charges and contingencies (if any) (excluding Taxes, Land and R&R Cost) at March 2018 price level 5,540.04 16 Escalation @ 5% p.a. (Without Considering Contingency) 542.75 17 Total cost with escalation (excluding Taxes, Land and R&R Cost) 6,082.79 18 Central Taxes including custom duty at March 2018 price level 673.07 19 Central Taxes with escalation @ 5% 739.04 20 Total Cost with Central Taxes excluding Land, R&R and State taxes at March 2018 price level 6,213.11 21 Total cost with Central taxes with escalation @ 5% pa. excluding Land, R&R and State taxes 6,821.83 22 Land 316.00 23 R&R 0.00 24 General Charges @ 5% 0.00 25 Contingency @ 3% 9.48 26 Total of Land and R&R (excluding escalation) 325.58 27 Escalation@5%p.a. (wherever applicable) 0.00 28 Total of Land and R&R Hutments 325.58 29 State Taxes at March 18 price level 228.05 30 State taxes with escalation @ 5% p.a. 250.40 31 Total Cost with Central & State Taxes including Land and R&R costs at March 2018 price level 6,766.74 32 Interest During Construction 102.99 33 Total Cost with Central & State Taxes with 5% escalation including Land and R&R 7,500.80.

Scene 11 (8m 7s)

11. Indore Financing Plan. # Source Amount in INR Crores % Contribution 1 GoI Equity 906.84 14.21% 2 GoI Subordinate Debt for CGST (50 % of Central Taxes) 369.52 5.79% 3 GoMP Equity 906.84 14.21% 4 GoMP Subordinate Debt for CGST (50 % of Central Taxes) 369.52 5.79% 5 Loan from Bilateral/ Multilateral agencies 3200.00 50.14% 6 Internal Borrowing / Bond by GoMP 629.11 9.86% 7 Total Cost Excluding Land, R&R and PPP Components 6381.83 100% 8 PPP Components 440.00 9 Total 6821.83 10 GoMP SD for Land and R&R (100%) 325.58 11 State Taxes (SGST) to be borne by GoMP 250.40 12 IDC to be borne by GoMP 102.99 Total Completion Cost 7500.80.

Scene 12 (8m 51s)

12. Indore Civil Packages. DEPOT. Package 1A (VIADUCT + 9 EL STN).

Scene 13 (9m 26s)

13. Indore Tender Packages. S.No. Contract Package EL/UG Proposed Packages As per Sanctioned Project Cost As per MOHUA GC Estimate Contract Value Remarks A CIVIL WORK PACKAGES 1 2A EL Design and Construction of Viaduct from ISBT/MR10 Flyover to Mumtaj Bag Colony (Length 5.29 Kms.) excluding stations 149.52 159.49 256.55 228.96 All Elevated in DPR and No Change 2 1C EL Design and Construction of Civil, Architectural and E&M Works for 7 Elevated Stations (for packages 2a) 202.01 246.53 316.92 All Elevated in DPR and No Change 3 1A EL Design and Construction of Viaduct from Gandhi Nagar to ISBT/MR10 Flyover (Length 11.76 Kms.) including 9 elevated stations 582.11 654.20 886.47 6 Stations & 6 Kms. from At Grade to Elevated 4 2B EL Design and Construction of Viaduct from High Court Residency to Mumtaj Bag Colony (Length 7.28 Kms.) including 7 elevated stations 371.59 424.81 570.15 1 Station from UG to EL + Stretch Kothari Market to Indian Railways 5 1B UG Design & Construction of Civil & Architectural Works for Underground Tunnels & Ramps (3.14 Kms.) and 2 Nos. Underground Stations from Gandhi Nagar to Ramchandra Nagar ( due to AAI Restrictions) 199.63 630.63 820.10 From 3 EL Stations and At Grade / Elevated Viaduct to 2 UG Stations and TBM Tunnels 6 3 UG Design & Construction of Civil & Architectural Works for Underground Tunnels & Ramps (3.80 Kms.) and 4 Nos. Underground Stations from Ramchandra Nagar to Rajwada 1,336.93 876.88 1,173.50 No Change TOTAL CIVIL WORKS PACKAGES 2,841.79 2,992.53 4,023.68.

Scene 14 (10m 32s)

14. Indore Tender Packages. . S.No. Contract Package EL/UG Proposed Packages As per Sanctioned Project Cost As per MOHUA GC Estimate Contract Value Remarks B SYSTEMS PACKAGES 7 3A UG Design, Manufacture, Supply, Installation, Testing and Commissioning of E&M Works (including Tunnel Ventilation & HVAC) for Underground Tunnels & 6 Nos. Underground Stations from Gandhi Nagar to Rajwada 147.20 275.49 424.80 Change from 4 UG Stations to 6 UG Stations and increase in Bored Tunnels from 3 to 6 Kms. 8 5 UG & EL Design, Manufacture, Supply, Installation, Testing and Commissioning of Elevators and Escalators for 29 stations - 122.56 175.80 No specific allowance made in the Sanctioned Cost 9 6 UG & EL Supply & Installation of Rails, Turnouts & Fasteners for Ballasted and Ballastless Track for Main Line and Depot 267.7 230.00 249.18 No change 10 7 UG & EL Design, Manufacture, Supply, Installation, Testing and Commissioning of Traction Power Supply, APS and Third Rail System incl. SCADA 458.41 419.75 547.65 No change 11 8 UG & EL Design, Manufacture, Supply, Installation, Testing and Commissioning of Signaling and Train Control System (CBTC) & Telecommunication System 573.29 330.08 496.87 No change 12 9 UG & EL Design, Manufacture, Supply, Installation, Testing and Commissioning of AFC System 204.47 101.50 124.70 No change 13 10 UG & EL Design, Manufacture, Supply, Installation, Testing and Commissioning of PSD 136.31 105.00 161.00 No change 14 11 UG & EL Design, Manufacture, Supply, Installation, Testing and Commissioning of Rolling Stock 821.92 600.00 775.00 No change 15 12 Depot Civil and E&M Works for Depot & Metro Office Building (incl. Depot Plant & Machinery) 318.79 170.00 322.99 No change TOTAL SYSTEMS PACKAGES 2,928.08 2,354.38 3,277.98.

Scene 15 (11m 38s)

15. Indore Tender Packages. . S.No. Contract Package EL/UG Proposed Packages As per Sanctioned Project Cost As per MOHUA GC Estimate Contract Value Remarks C TOTAL COST CIVIL & SYSTEM PACKAGES (A+B) 5,769.87 5,346.90 7,301.66 16 14 Miscellaneous 196.26 186.83 186.83 17 4 Geotechnical Site Investigation for Underground Tunnels & Stations incl. Depot - 2.43 2.43 18 7A Power Simulation Study - 7.00 7.00 19 General Charges 302.65 302.65 302.65 20 Contingencies 172.37 166.29 224.94 21 D Total Basic Project Construction Cost 6,441.15 6,012.11 8,025.51 22 Cost Escalation 325.58 303.89 405.66 23 Land Cost 631.08 631.08 631.08 24 Interest During Construction 102.99 102.99 102.99 E Total Project Cost 7,500.80 7,050.07 9,165.25.

Scene 16 (12m 26s)

16. Indore Tender Packages – Change due to Design & Escalation.

Scene 17 (12m 48s)

17. ADB & NDB Visit. A Fact Finding Mission was held with NDB & ADB on 6 th to 8 th March ADB & NDB agreed for the Tender documents as per ADB format and GCC as per FIDIC Yellow Book Prior approval of ADB is required before issue of NIT and post evaluation of bids (2-3 months) ADB prefer to fund the underground packages & they are ok with other part civil packages providing there is no Make in India policy NDB prefer to fund the Rolling Stock and Signalling packages, & they have no issue with the Make in India policy. However MoHUA does not permit external funding for Rolling Stock & Signalling. ADB is interested in funding the following packages; Package 3 – underground section consisting of 3.60 kms of underground tunnels and 4 nos. underground stations Package 3a – E&M works (incl. Tunnel ventilation & HVAC) for the above package NDB is interested in funding the following packages; Priority Package – 2A (Contract Awarded) – 70% Rolling Stock Signalling & Telecom Systems.

Scene 18 (13m 27s)

SN Deliverable Action By Remarks Due Date A. General 1 MoU between GoMP & GoI MPMRCL Draft 2 Approved Indore Metro Rail Yellow Line Alignment GC/MPMRCL 1 st Draft 3 KMZ file of the Yellow Line alignment GC/MPMRCL 1 st Draft 29-Mar-19 B. Finance/Commercial 1 Updated Project Cost GC/MPMRCL 1 st Draft 29-Mar-19 2 Updated EIRR & FIRR GC/MPMRCL Shared with ADB/NDB 29-Mar-19 3 Procurement plan for ADB GC/MPMRCL 1 st Draft 29-Mar-19 4 Procurement plan for NDB GC/MPMRCL 1 st Draft 29-Mar-19 5 Model used for arriving EIRR & FIRR GC/MPMRCL 1 st Draft 29-Mar-19.

Scene 19 (13m 56s)

C. Environmental & Social 1 Revised Enviromental Screening & Categorisation Report GC/MPMRCL Shared with ADB/NDB 28-Feb-19 2 Revised Social Screening & Categorisation Report GC/MPMRCL Shared with ADB/NDB 28-Feb-19 3 Revised Resettlement Policy Framework (RPF) GC/MPMRCL Shared with ADB/NDB 28-Feb-19 4 Revised draft EIA Report GC/MPMRCL Shared with ADB/NDB 28-Feb-19 5 Environmental Management Plan (Environmental Manual) GC/MPMRCL Shared with ADB/NDB 28-Feb-19 6 Social Impact Assessment Report & Resettlement Action plan and Stakeholder management plan GC/MPMRCL 1. Notification of alignment 2. Land plan (Digital Khasra maps) 3.It will be done after the Social survey ASAP 7 Appointment of Resettlement Implementation Supporting Agency (RISA) MPMRCL 8 MPMRCL EIA Cell details MPMRCL.

Scene 20 (14m 29s)

20. Make in India Policy. As per letter No .: K-14011/1/2018-UT II dated 27.07.2018 of MoHUA, GoI with subject “Mandatory Conditions/guidelines applicable to metro rail projects” addressed to The Chief Secretary GoMP and GoG . (V) (b): In order to promote “Make in India” initiative and as envisaged under Public Procurement Order 2017 mentioned above, MoHUA has rationalized minimum local content and purchase preference for procurement of metro rail system/equipment with a definitive plan for phased indigenization to the extent as detailed below: i) Minimum Local Content (as on date, increased subsequently): a. Rolling Stock – 40% b. Telecom – 40% c. Signalling – 30% d. Civil – 80% e. Electrical – 50% With the above condition tender document for any package will not be approved by the multilateral/ bilateral funding agencies including EIB and ADB..

Scene 21 (15m 5s)

21. Make in India Policy - EIB. EIB Procuremen t Guidelines: Local Preference for Goods: Except for operations in Candidate Countries, Borrowers may grant a 15% margin of preference for goods manufactured or produced in the country (defined as having at least a 30% local content ex-factory). Bidding documents must clearly indicate such preference. The comparison is then made between the price (net of taxes and duties at the place of delivery) of the imported good increased by 15% and the price (net of the value added tax or similar taxes) at the place of delivery of the locally manufactured good. The Bank does not allow for preference to be given to works (even if they include the supply of goods) or services originating in the beneficiary country..

Scene 22 (15m 37s)

The impact of Domestic Preference on a Project should be understood When considering applying domestic preference, it is vital that a thorough market assessment has been undertaken to ensure that giving preference to domestic contractors or locally made goods does not hurt competition. It is equally important to ensure that local suppliers and locally made goods adhere to the required technical, environmental, and labor standards. Wider social and economic impact should also be considered in providing domestic preference. For example, allowing domestic preference may support the development of the private sector in the borrower’s country by giving them preferences, hence a higher chance, to win procurement contracts. However, a poorly designed domestic preference scheme may result in lower quality of goods, works, or services provided by the eligible supplier or contractor. Alternately, when price preference is applied, the borrower will have to pay more for the same or similar goods or services. It can also be argued that the application of domestic preference schemes, over the long term, can reduce competition and remove competitive pressure on domestic industry to match the efficiencies of global best-in-class suppliers or contractors. The consumer bears these higher costs..

Scene 23 (16m 26s)

Figure 1: Domestic Preference in the ADB Procurement Cycle Feedback or Evaluation 7*-ct Rep;t Implementation and CO t Plan C tract A" Source. Asian Development Bank. Country Pattnership Strategy Camtry •rd "c Risa Asyssmot PROCUREMENT CYCLE gid Evaluation Project Conceptualization Transaction Techni Assistance &ocurement Risk Cat •ization Procurement manning Prc*ct Bidding & ddirw Daaments Domestic Preference.

Scene 24 (17m 11s)

24. Make in India Policy. (V) (c) Metro rolling stock should be funded through equity/ counterpart funding/ domestic funding and not from sovereign loan from multilateral/bilateral financing institutions. Only after exhausting the counterpart funding limit for procurement of rolling stock, funding of signalling and system components from remaining limit of counterpart funding should be done. As imported component is maximum in Rolling Stock and Signalling, this will ensure that “Make in India” objective are achieved to its utmost. NDB adopts a country system for procurement hence they are willing to finance Rolling Stock and Signalling even with a “Make in India” policy..

Scene 25 (17m 38s)

25. Thank You.
