Highest Biosecurity, Accuracy,  And Reliability Without a  Trade-Off

Scene 3

Innovatec  sets new standards when it comes  down to biosecurity and accuracy.

Our candling technologies are always the best  suitable solution. Manual or fully automation,  high or low production volumes, standard or  special egg -  we always have a solution.

Scene 4

We’ve come a long way with candling. Automated candling takes out the pain of accuracy and labor.  These technologies are about next level accuracy.  Because every egg counts.

. Biosecurity; avoid cross-contamination in all steps      of the process.   . Accuracy; never have a living embryo go to waste.   . Production capacity; as many as possible as      accurate as possible.

Scene 5

Innovatec’s Automatic Candling and  Transfer (ACT) system has a unique  concept specially designed to meet  standards in modern hatcheries.

After candling this system separates  infertile and fertile eggs. The fertile  eggs are placed in a hatcher basket.

Biosecurity, production quality and  production capacity are not a  trade-off in this system.

Scene 6

The combination of a very even candling quality,  the egg friendly process and the almost complete  absence of production stops makes the Innovatec  candling and transfer unit very reliable and  efficient.

.  Capacity: up to 90,000 eggs per hour .  Candling levels: 6 .  Accuracy: 99% .  Level of automation: Fully automated .  Exploder detection: No .  Candling day: From day 14

Scene 7

Automatic Candling &  Transfer (LEAN) (ACTL)

Not every hatchery needs a high  capacity system. Innovatec’s ACT(L)  is there to support smaller hatcheries  without sacrificing accuracy.

The system is equipped with an  extreme friendly egg removal setup,  and can be operated by two operators.

Scene 8

This non-contact method  provides unmatched accuracy

.  Capacity: up to 50,000 eggs per hour .  Candling levels: 5 .  Accuracy: 99% .  Level of automation: Semi-automatic .  Exploder detection: No .  Candling day: From day 14

Scene 9

The CLEANchick™ detects living embryos with   unmatched accuracy. The contact-free   methods accurately determines the presence   of an heartbeat as early as day 9. Making this   machine also suitable for early candling   applications.           The included traditional candling technology   is used to further improve the accuracy of the   identification of infertile eggs. Making it   possible to determine the presence of exploder   eggs very accurate.

Scene 10

The CLEANchick™ is the spill in Innovatec’s  biosecurity focus for her candling equipment.

Together with the Exploder Removal System  (ERS™) and the Ultimate In-Ovo™ Innovatec  reaches the highest levels of biosecurity.

. Capacity: up to 92,000 eggs per hour . Candling levels: 7 . Accuracy: 99,96% . Level of automation: Fully automated . Exploder detection: Yes . Candling day: From day 9

Scene 11

Once identified by the CLEANchick™,  the next step is to take out the exploder  eggs as quickly and as biosecure as  possible. No contamination should take  place. The Exploder Removal System (ERS™)  was developed to just do that. The ERS™  removes all exploders and stores the  eggs in a special waste system to  protect the biosecurity of the hatchery. The system comes with its own  disinfection system to disinfect the  affected area and improve hatchability.

Scene 12

To avoid being affected by the conditions in the  hatchery the system comes with its own suction  system. The removed exploders will be stored in  the waste collection system or in a disposal station  next to the machine. The ERS™ has unmatched biosecurity. Together with the CLEANchick™ the ERS™ has a  proven record of improving hatchability and  reducing First Week Mortality.

Scene 13

Handling equipment for trays and baskets needs to be as gentle as the candling  equipment itself.

Innovatec’s candling equipment can be  connected to a range of setter trolley  unloaders, empty hatcher baskets  destackers, and full hatcher basket stackers.

For every type of setter trolley and for every  type of setter tray Innovatec has a solution.

Scene 14

Innovatec’s unloaders, stackers, and destackers  are designed to keep up the production speed.  All handling automation is designed to limit the  impact on the product. The transfer stacker is designed to carefully place  flled hatcher baskets on top of its dolly, in order to  reduce the impact on operators and products.

Automatic dolly transport and connected walking  beams take out any need for operators to be  involved in the process.

Scene 15

. 24/7 service . Support in local languages . Remote and online support . Balanced spare parts  .  managementService :

. High reliability . High levels of biosecurity . Uniformities in technologies . Easy to maintenance . Simplicity of design . Dedicated designs only to     hatcheriesProduct :

. Ensure longest possible  . technical lifetime . Maximum productivity against  . minimal costs . Service provided by the specialist . You Hatch We  CareMaintenance  agreement:

Scene 16

.  Experts in hatchery automation    since 1991.

. Complete automation solution    for every hatchery.

. Animal welfare and chick health    are our focus.

. Supporting clients is second nature    to us.
